Summary of Contents for Grundig GW7P682210W
- Page 1 Washing Machine User Manual GW7P682210W 2820529971/ EN/ / 28/01/2022 10:10...
-
Page 2: Table Of Contents
Auxiliary Function Selection.... 27 Table of Contents 6.8.1 Auxiliary Functions...... 28 6.8.2 Functions/Programmes Selec- 1 Safety Instructions ......ted by Pressing the Function Intended Use ........ Keys for 3 Seconds ....Safety of Children, Vulnerable Per- End Time ........30 sons and Pets ...... - Page 3 Please read this user manual first! Dear Customer, Thank you for choosing Grundig product. We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents care- fully before using the product.
-
Page 4: Safety Instructions
1 Safety Instructions This section includes the safety • The product must only be instructions necessary to pre- used for washing and rinsing vent the risk of personal injury or of laundry that are marked ac- material damage. cordingly • This appliance is intended to Our company shall not be held be used in household and responsible for damages that... -
Page 5: Electrical Safety
ing use of the appliance in a • Cut the power cable and the product safe way and the break and deactivate the lock- hazards involved. ing mechanism of the loading • Children under the age of 3 door before disposing of the should be kept away unless product for children’s safety. -
Page 6: Handling Safety
• When unplugging the appli- Installation Safety ance, don't hold the power • Check the information on the cord, but the plug. manual and installation in- • Make sure the plug is not wet, structions to prepare the dirty or dusty. product for installation and Handling Safety make sure the electrical... - Page 7 • Place the product on a level be running from the tap in a and hard surface and balance minute in order for the product with the adjustable legs. to function properly. If the wa- • Connect the product to a ter pressure is above 1 MPa grounding plug protected by a (10 Bars), a pressure-reducing...
-
Page 8: Operational Safety
• Make sure pets do not climb Operational Safety inside the product. Check in- • When you are using the appli- side the product before use. ances, use only detergents, • Do not force open the locked softeners and supplements loading door. -
Page 9: Maintenance And Cleaning Safety
charge hose is connected to • Do not use sharp or abrasive the tap. Do not touch the dis- tools to clean the product. Do charge water. not use household cleaners, • Take the following precautions soap, detergent, gas, gasol- to prevent formation of biofilm ine, thinner, alcohol, varnish, and malodours:... -
Page 10: Important Instructions For Environment
2 Important Instructions for Environment 2.1 Compliance with WEEE Directive This product complies with EU WEEE Directive (2012/19/EU). This product bears a classifica- tion symbol for waste electrical and electronic equipment (WEEE). This product has been manu- factured with high quality parts and materials which can be reused and are suitable for re- cycling. -
Page 11: Technical Specifications
3 Technical Specifications Supplier’s name or commercial brand Grundig GW7P682210W Model name 7131941600 Nominal Capacity (kg) Maximum spin speed (cycle/min) 1200 Built-In Height (cm) Width (cm) Depth (cm) Single Water inlet / Double Water inlet + / - Electrical input (V/Hz) -
Page 12: Installation
4 Installation 4.1 Appropriate Installation Please read the “Safety Instructions” Location section first! • Place the product on a hard and level Your washing machine automatically floor. Do not place it onto a carpet with detects the amount of laundry high pile or other similar surfaces. -
Page 13: Removing Transportation Safety
Tilt the machine back slightly. Rest the tabs 4.4 Connecting to Water Supply of Cover A against the lower panel. Com- plete the assembly by rotating the cover. NOTICE Models with a single water inlet shall 4.3 Removing Transportation not be connected to the hot water Safety Bolts tap. -
Page 14: Adjusting The Stands
b. Connect the drain hose to a minimum 4.6 Adjusting the Stands height of 40 cm and a maximum height of 100 cm. NOTICE In order to ensure that the product c. Installing the water draining hose at operates more silently and vibration- ground level or close to the floor (40 cm free, it must stand level and bal- below) and then raising it makes water... -
Page 15: Start Up
• Do not make connections via extension Cleaning programme. If this programme is cables or multi-plugs. Overheating and not available in your product, apply the burning may occur due to the connecting method which is described in section cable. "Cleaning the loading door and the drum". Damaged power cables should be replaced by the authorised service in order to prevent possible danger. -
Page 16: Loading The Laundry
• Wash slightly soiled laundry at low temper- 5.6 Using Detergent and Softener atures. • Use faster programmes for small quantit- NOTICE ies of lightly soiled laundry. Read the manufacturer instructions • Do not use prewash and high temperat- on the package while using deter- ures for laundry that is not heavily soiled or gents, softeners, starch, bleach and stained. - Page 17 • Do not select a programme with pre- Using Softeners washing if you are using a detergent pod Put the softener in the softener compartment or dispensing ball. Place the detergent of the detergent drawer. pod or the dispensing ball directly among •...
-
Page 18: Tips For Efficient Washing
• If the gel detergent is not fluid or is in a and add the bleach while the product is capsule liquid tablet, place directly inside receiving water to the detergent compart- the drum before washing. ment in the first rinsing step. •... -
Page 19: Displayed Programme Duration
It may be necessary to Powder and liquid deter- pre-treat the stains or per- gents recommended for form prewash. colours can be used at Prefer liquid deter- dosages recommended Liquid detergents Powder and liquid deter- gents produced for heavily soiled clothes. suitable for colours gents recommended for for delicate... -
Page 20: Control Panel
6.1 Control Panel 1 Programme Selection Button 2 Temperature Level Lights 3 Spin Level Indicator Lights 4 Display 5 Start/Pause Button 6 Remote Control Button 7 End Time Setting Button 8 Auxiliary Function Button 3 9 Auxiliary Function Button 2 10 Auxiliary Function Button 1 11 Spin Speed Adjustment Button 12 Temperature Setting Button... -
Page 21: Symbols On The Display
6.2 Symbols on the Display 1 Temperature Indicator 2 Spin Speed Indicator 3 Duration information 4 Door lock is engaged symbol 5 Programme follow-up indicator 6 No Water indicator 7 Add Garment Indicator 8 Bluetooth Connection Indicator 9 Remote Control Indicator 10 Delayed Start Enabled Indicator 11 Auxiliary Function Indicators 3 12 Child Lock Enabled symbol... -
Page 22: Programme And Consumption Table
6.3 Programme and Consumption Table Auxiliary Functions Programme Temperature °C 2,75 1200 • • • • • Cold - 90 Cottons 2,00 1200 • • • • • Cold - 90 1,10 1200 • • • • • Cold - 90 60** 1,04 1200... -
Page 23: Programme Selection
6.4 Programme Selection Please read Installation section of the manual before first use. a. Determine the programme suitable for the The auxiliary functions in the table type, quantity and soiling level of the may vary according to the model of laundry in accordance with "Programme your machine. -
Page 24: Synthetics
• Synthetics Allergy UK is the brand of the British You can wash your laundry (such as t-shirts, Allergy Association. Seal of Approval blouses, synthetic/cotton blended fabrics is created to guide people that re- etc.) in this programme. When the quick quire recommendation about a wash function button is pressed, programme product that the related product re-... -
Page 25: Gentlecare
• Shirts • Mix This programme is used to wash the shirts Use to wash your cotton and synthetic made from cotton, synthetic and synthetic clothes together without sorting them. blended fabrics altogether. It reduces • GentleCare wrinkles. Steam is applied at the end of the You can wash your delicate clothes such as programme to help the wrinkle reducing cotton/synthetic blended knitwear or hosiery... -
Page 26: Temperature Selection
special washing programme for which dura- to its delicate washing movements and spin- tion of rinse hold, washing action, washing ning profile, the soft toys programme pro- and rinsing duration are modified. tects the toys during washing. It is recom- mended to use liquid detergent. -
Page 27: Spin Speed Selection
If you want to drain the water at the end of If you scroll to cold wash option and the programme without spinning, use No press Temperature Adjustment but- Spin function. ton again, the recommended max- imum temperature for the selected No change can be made in pro- programme appears on the display. -
Page 28: Auxiliary Functions
Do not use Quick Wash adjustment button When an auxiliary function button when washing heavily soiled laundry for a that cannot be selected with the cur- better washing performance. rent programme is pressed, the Shorten the programme duration by using washing machine will make a warn- the Quick Wash key for Moderately and ing sound. -
Page 29: Functions/Programmes Selected By Pressing The Function Keys For 3 Seconds
6.8.2 Functions/Programmes • Soaking Selected by Pressing the This function can be selected by pressing Function Keys for 3 Seconds and holding the related auxiliary function but- ton for 3 seconds. • Drum Cleaning The Soaking in Water auxiliary function en- Press and hold the related auxiliary function sures that the stains that have penetrated button for 3 seconds to select the pro-... -
Page 30: End Time
To activate bluetooth connection: gramme's estimated ending time is dis- played. If the End Time is set, End Time in- Press and hold Remote Control function but- dicator is illuminated. ton for 3 seconds. Countdown “3-2-1” will be displayed, and then Bluetooth icon will appear on the display. -
Page 31: Starting The Programme
Additional laundry can be added into The door will be locked if Remote the machine during the End Time Control Function is selected. In order countdown. At the end of the count- to open the door you must deactiv- down, End Time indicator turns off, ate Remote Start Function by either washing cycle starts and the time of pressing the Remote Start button or... -
Page 32: Changing The Selections After Programme Has Started
Changing the programme selection after 6.12 Changing the Selections After programme has started: Programme has Started The programme change is not allowed when Adding laundry after the programme has the current programme is running. You can started select the new programme after switching the current programme to pause mode. -
Page 33: End Of Programme
6.14 End of Programme In order to use the HomeWhiz func- tion, the application must be in- End symbol appears on the display when the stalled on your smart appliance, and programme is completed. your washing machine must be If you do not press any button for 10 paired with your smart appliance via minutes, the machine will switch to OFF Bluetooth. - Page 34 Control Function button simultaneously If you cannot successfully perform for 3 seconds to switch your machine to the setup within 5 minutes, your HomeWhiz setup mode. washing machine will turn off auto- matically In this case, you will have to start over the setup procedure. If the problem persists contact the Au- thorised Service Agent.
-
Page 35: Setting Up A Washing Machine Connected To Someone Else's Account
6.15.3 Remote Control Function and Using It Bluetooth is automatically turned on after setting up HomeWhiz. To activate or deac- tivate the Bluetooth connection, please see Bluetooth 3’’’. If you turn off and on your machine while bluetooth is active, it will automatically re- HomeWhiz Application may require connect. -
Page 36: Troubleshooting
door. Once access is established to the When you activate this function in the wash- product, you will see a screen similar to the ing machine, this function remains active ex- one below. cept under certain circumstances and allows you to control your washing machine re- motely via Bluetooth. -
Page 37: Cleaning The Loading Door And The Drum
c. Rinse drawer and syphon in the sink with Use only a soft and damp cloth to clean the plenty of warm water. Use gloves or suit- control panel. Do not use cleaning products able brush to prevent contact of residues that contain bleach in the drawer with your skin. -
Page 38: Troubleshooting
In addition, prior to transporting the product c. Follow the below procedures in order to (e.g., when moving to another house) water drain water. should be drained completely. If the product has an emergency water draining hose, in order to drain the NOTICE: water: Foreign substances left in the pump... - Page 39 pending on the product model, select an- • Pump filter is clogged. >>> Clean the other program by turning the Program Se- pump filter. lection button or pressing and holding the Product stopped shortly after the On/Off button for 3 seconds to cancel the programme started.
- Page 40 • Input temperature of water is low. >>> Re- • Excessive foam has occurred and auto- quired time to heat up the water extends matic foam absorption system has been in cold seasons. Also, washing time can activated due to too much detergent us- be lengthened to avoid poor washing res- age.
- Page 41 • Excessive amount of detergent is used. • Pump filter is clogged. >>> Check the fil- >>> Put the detergent in the correct com- ter. partment. Do not mix the bleaching agent • Draining hose is folded. >>> Check the and the detergent with each other.
- Page 42 • The detergent in the main wash compart- the “Programme and consumption table”. ment got wet while taking in the prewash When you use additional chemicals (stain water. Holes of the detergent compart- removers, bleaches and etc.), reduce the ment are blocked. >>> Check the holes amount of detergent.
