- Page 1 INSTALLATION AND OPERATING MANUAL 300W C-Band Hub-mount SOLID STATE POWER BLOCK UP-CONVERTER (SSPB) SSPB-C300 (SSPBMg-C300-CRE) PM GR0-31K1A0-3N0R, Rev. 1...
- Page 2 This Advantech Wireless product is warranted against defects in material and workmanship for a period of 2 years from date of shipment. During the warranty period, Advantech Wireless will, at its option, either repair or replace products that will prove to be defective.
-
Page 3: Table Of Contents
SSPB-C300 (SSPBMg-C300-CRE) CONTENTS SAFETY..........................6 GENERAL INFORMATION ...................8 INTRODUCTION ......................8 DESCRIPTION........................8 2.2.1 Power Supply .......................8 2.2.2 Up-Converter Assembly ....................9 2.2.3 10 MHz Reference Oscillator ..................9 2.2.4 HPA Assembly......................10 2.2.5 Controller Board ......................10 SSPB SPECIFICATIONS .....................13 UNPACKING AND INSTALLATION................17 INITIAL INSPECTION....................17 UNPACKING ........................17 INSTALLATION ......................17... - Page 4 SSPB-C300 (SSPBMg-C300-CRE) MAINTENANCE......................23 PREVENTIVE MAINTENANCE.................23 6.1.1 Mechanical Preventive Maintenance .................23 6.1.2 Checking the Cooling Fans..................23 RS-232 SERIAL COMMUNICATION .................24 HAND-HELD TERMINAL ..................24 RS-232 PC TERMINAL....................26 RS-485 SERIAL COMMUNICATION .................34 PACKING LIST.......................35 SAFETY AND EMC COMPLIANCE ................36 APPENDIX A: RS-485 SERIAL COMMUNICATION PROTOCOL.......37 11.1...
- Page 5 SSPB-C300 (SSPBMg-C300-CRE) FIGURES 1: P ...................... 11 IGURE RODUCT UTLINE 2: B ......................12 IGURE LOCK IAGRAM 3: C ....................... 15 IGURE ONNECTORS 4: H HELP M ................24 IGURE HELD ERMINAL 5: H STATUS M ..............25 IGURE HELD...
- Page 6 SSPB-C300 (SSPBMg-C300-CRE) TABLES TABLE 1: ELECTRICAL SPECIFICATIONS................13 TABLE 2: MECHANICAL SPECIFICATIONS ................ 14 TABLE 3: POWER REQUIREMENTS ..................14 TABLE 4: ENVIRONMENTAL CONDITIONS................ 14 TABLE 5: CONNECTORS ......................16 TABLE 6: AC LINE (J5) – PIN ASSIGNMENTS..............16 TABLE 7: SYSTEM CONTROL (RS232 RS485) – PIN ASSIGNMENTS ......20 TABLE 8: SERIAL INTERFACE RS-232 CONNECTION INFORMATION......
-
Page 7: Safety
SSPB-C300 (SSPBMg-C300-CRE) 1. SAFETY In addition to this section, included by reference are the following pertinent sections of the International Standard IEC-215, ‘Safety requirements for radio transmitting equipment’: Appendix D, ‘GUIDANCE ON ASSESSING THE COMPETENCE OF PERSONNEL FOR DESIGNATION AS SKILLED’ and also Sub-clause 3.1 of the Standard. - Page 8 The maximum permissible levels of exposure are quite low in comparison to the power levels produced by the equipment built by Advantech Wireless (e.g. less than 10 mW versus 4 to 700 W delivered by the different units). The maximum permissible levels are currently being studied by a number of organizations.
-
Page 9: General Information
For a safe and versatile operation, please read the information carefully BEFORE using the equipment. Advantech Wireless has prepared this manual for use as a guide for the proper installation, operation and maintenance of Advantech Wireless equipment and computer programs. The drawings, specifications and information contained herein are the property of Advantech Wireless. -
Page 10: Up-Converter Assembly
SSPB-C300 (SSPBMg-C300-CRE) 2.2.2 U ONVERTER SSEMBLY The L-Band signal arriving from a modem enters the Up-Converter Assembly through a ‘N-type’ connector, see Figure 3: Connectors (page 15). The L-Band signal (950 MHz to 1525 MHz) enters the high gain Low Noise Amplifier (LNA) and Medium Power Amplifier (MPA) stages that boost the RF power level sufficient for the transmission through the Up- Converter Assembly. -
Page 11: Hpa Assembly
SSPB-C300 (SSPBMg-C300-CRE) 2.2.4 HPA A SSEMBLY The HPA Assembly amplifies the RF signal from the Up-Converter Assembly to a power level sufficient for transmission. Integral to this module are three HPA stages and a power conditioner board. Other functionality includes internal power conditioning and overtemperature shutdown. -
Page 12: Figure 1: Product Outline
SSPB-C300 (SSPBMg-C300-CRE) Figure 1: Product Outline Page 11... -
Page 13: Figure 2: Block Diagram
SSPB-C300 (SSPBMg-C300-CRE) +45 V +12 V REDUND LEDS MUTE FAULT SHUT-DOWN_MON FWPWR C (temp info) -9 V TERM -9 V FWPWR SD_MON FAULT MUTE RS485 RS232 + 5 V -9 V +12 V +12 V (VAR) +12 V (VAR) +12V... -
Page 14: Sspb Specifications
SSPB-C300 (SSPBMg-C300-CRE) 2.3 SSPB SPECIFICATIONS TABLE 1: ELECTRICAL SPECIFICATIONS L-Band Input Frequency 950 – 1525 MHz RF Output Frequency Range 5.850 – 6.425 GHz Frequency Stability Based upon 10 MHz Internal Reference RF Saturated Output Power (P + 54.7 dBm, typical (300 W) Linear Output Power (P + 51.0 dBm, min... -
Page 15: Table 2: Mechanical Specifications
SSPB-C300 (SSPBMg-C300-CRE) TABLE 2: MECHANICAL SPECIFICATIONS Physical Dimensions See Figure 1: Product Outline (page 11) – white paint Approximate Weight 24.25 lbs (11 kg) Mounting holes (4) 1/4-20, 0.40” (6 places) and #10-32 0.250” (6.35 mm) deep (4 places both sides), see Figure 1: Product Outline (page 11) - Page 16 SSPB-C300 (SSPBMg-C300-CRE) Figure 3: Connectors Page 15...
-
Page 17: Table 5: Connectors
SSPB-C300 (SSPBMg-C300-CRE) TABLE 5: CONNECTORS Connector Function Description Mating Connector L-Band IN (J1) N-Type (F) N-Type (M) (Up-converter Input) &C Serial Interfaces (J2) MS 3112E12-10P (M) MS 3116G12-10S (F) RS-485 & RS-232 (J3) (not available for Relay Interface MS3112E10-6P (M) -
Page 18: Unpacking And Installation
SSPB-C300 (SSPBMg-C300-CRE) 3. UNPACKING AND INSTALLATION This Section contains instructions for the site preparation, unpacking and the installation of an SSPB. 3.1 INITIAL INSPECTION Inspect the shipping container for damage. If the container or cushioning material is damaged, immediately contact the carrier that delivered the equipment and submit a damage report. -
Page 19: Electrical Connections
The centre pins of the connectors used by Advantech Wireless have a precision tolerance measured in mils (1/1000 inch). The mating connectors of the various suppliers may not be of precision types. -
Page 20: Cooling Considerations
SSPB-C300 (SSPBMg-C300-CRE) 3.3.4 C OOLING ONSIDERATIONS The SSPB is forced-air cooled. The cooling fans are configured for 12 V DC operation, supplied by the main power supply of the unit. Depending on environmental conditions, the airflow opening may become obstructed by debris, reducing the efficiency of the cooling system. -
Page 21: Interfaces
SSPB-C300 (SSPBMg-C300-CRE) 4. INTERFACES 4.1 SYSTEM CONTROL CONNECTOR (RS-485 RS-232) The System Control interface connector is located at port (RS232 RS485) of the SSPB. This is a 10-pin MS3112E12-10P (male) connector with pin assignments as shown in TABLE 7 below. -
Page 22: Redundant Interface
SSPB-C300 (SSPBMg-C300-CRE) 4.2 REDUNDANT INTERFACE NOTE: This connector is not installed on these units and consequently this interface is not available. The Redundant Interface connections are made with a 10-pin circular connector mounted on the SSPB enclosure. The connector type is listed in TABLE 5 at page 16 and the location is shown in Figure 3 at page 15. -
Page 23: Pre Power And Checkout
SSPB-C300 (SSPBMg-C300-CRE) 5. PRE POWER AND CHECKOUT This Section contains the pre-power and checkout procedure for the SSPB model SSPB-C300 (SSPBMg-C300-CRE). WARNING! The information presented in this Section is addressed to the technicians who have specific training in, and knowledge of the Microwave Power Transmitters. -
Page 24: Maintenance
SSPB-C300 (SSPBMg-C300-CRE) 6. MAINTENANCE This Section describes the scheduled maintenance procedure for the SSPB. CAUTION! Improper maintenance of the SSPB may void the warranty. 6.1 PREVENTIVE MAINTENANCE This product requires minimum maintenance, which consists of visual inspection and cleaning. WARNING! Personnel performing maintenance on this system must have the proper training and become thoroughly familiar with the related safety requirements and issues. -
Page 25: Rs-232 Serial Communication
SSPB-C300 (SSPBMg-C300-CRE) 7. RS-232 SERIAL COMMUNICATION 7.1 HAND-HELD TERMINAL W a t t C - B a n d S S P B > ENTER ENTER ENTER ENTER L I S T C O M M A N D S... -
Page 26: Figure 5: Hand - Heldt
SSPB-C300 (SSPBMg-C300-CRE) > S T A ENTER S S P B S T A T U S P L L s t a t u s l o c k o u t p u t A t t e n u a t i o n 0 . -
Page 27: Rs-232 Pc Terminal
SSPB-C300 (SSPBMg-C300-CRE) 7.2 RS-232 PC TERMINAL For RS-232 VT communication, use the following communication parameters: - Bits per second: 9600 - Data Bits: 8 - Parity: None - Stop bits: 1 - Flow Control: None TABLE 8: SERIAL INTERFACE RS-232 CONNECTION INFORMATION... -
Page 28: Figure 6: Hyper Terminal
SSPB-C300 (SSPBMg-C300-CRE) Figure 6: HyperTerminal RS-232 Communication – help command and response Page 27... -
Page 29: Figure 7: Hyper Terminal
SSPB-C300 (SSPBMg-C300-CRE) Figure 7: HyperTerminal RS-232 Communication – status command and response Page 28... -
Page 30: Figure 8: Hyper Terminal
SSPB-C300 (SSPBMg-C300-CRE) Figure 8: HyperTerminal RS-232 Communication – help rf, rf and rf off commands and responses Page 29... -
Page 31: Figure 9: Hyper Terminal
SSPB-C300 (SSPBMg-C300-CRE) Figure 9: HyperTerminal RS-232 Communication – help att, att, gain and att <value> commands and responses Page 30... -
Page 32: Figure 10: Hyper Terminal
SSPB-C300 (SSPBMg-C300-CRE) Figure 10: HyperTerminal RS-232 Communication – help gain, gain, att and gain <value> commands and responses Page 31... -
Page 33: Figure 11: Hyper Terminal
SSPB-C300 (SSPBMg-C300-CRE) Figure 11: HyperTerminal RS-232 Communication – “help baud” and “baud rs232” commands and responses NOTE: The baud rate may be set only f or RS-232 seria l interface (to 9600 or to 19200 bauds). fter re-setting the baud rate, the communication program used (HyperTerminal or other VT ommunication programs) must be set for the new baud rate. -
Page 34: Figure 12: Hyper Terminal
SSPB-C300 (SSPBMg-C300-CRE) Figure 12: HyperTerminal RS-232 Communication – “help rs485”, “rs485 ascii” and “rs485 binary” commands and responses NOTE: The rs485 parameter may be set to ascii o binary, or to skywan. When this paramete r is set to ascii, the RS-485 seria... -
Page 35: Rs-485 Serial Communication
SSPB-C300 (SSPBMg-C300-CRE) 8. RS-48 5 SERIAL COMMUNICATION he RS-485 serial communication is based on the protocol in 11 APPENDIX A: RS-485 SERIAL COMMUNICATION PROTOCOL at page 37. Note that in order to connect the RS-485 of the unit to the RS-232 interface of a PC an adequate RS-485/RS-232 adapter should be used. -
Page 36: Packing List
Description Part # Installation and Operating Manual PM GR0-31K1A0-3N0R Rev. 1 C-Band 300 Watt SSPB, GR0-31K1A0-3N0R model SSPB-C300 (SSPBMg-C300-CRE) CWR137 Pressure Window Sub-assembly 230-160883-001 Connector Circular MIL C-5015, Straight Cable Plug, 16 Shell, 3 Socket MS3106F16- 631-310616-001 10S (connector for AC LINE connector J5) -
Page 37: Safety And Emc Compliance
SSPB-C300 (SSPBMg-C300-CRE) 10. SAFETY AND EMC COMPLIANCE Advantech Wireles s products are compliant with the following standards: SAFETY: IE 0950 -1 second edition 2005 MC: EN301489-1 2004 (EMC for radio equipm ent and services, common technical requirements) EN 5022: 1998 / A1: 2000 - Class A EN61000-4-4 Transient/burst 0.5kV Signal Lines, 1 kV Power Lines... -
Page 38: Appendix A: Rs-485 Serial Communication Protocol
0x55. After this start byte, each frame consists of 7 bytes. Firs t byte: ter (NMS) to Slave (Advantech Wireless unit): Address of correspo ndent Advantech Wireless unit (0x01 to 0x0F). Slave to Master: When Advantech Wireless unit sends the respond frame to NMS, it left shifts its unit address by 4. -
Page 39: Commands
SSPB-C300 (SSPBMg-C300-CRE) 11.3 COMMANDS These commands go only from master-slave direction. TABLE 10: COMMANDS Respond. 2,3,4,5,6 Description 2nd byte 3, 4, 5 &6 bytes bytes Request condition 0x01 or 0xAA AA AA AA See TABLE 11 status 0x2A Mute/Unmute 0x5A AA AA AA To mute... - Page 40 SSPB-C300 (SSPBMg-C300-CRE) TABLE 10: COMMANDS (continued) Respond. 2,3,4,5,6 Description 2nd byte 3, 4, 5 &6 bytes bytes. Byte 2, Read Hot Spot 0x12 0xAA AA AA AA Temperature temperature Byte 4,5,6: 0xAA Set operation m 0x5A– On (Auto) 0x1F See TABLE 11...
-
Page 41: Responses To Commands From Slave To Master
SSPB-C300 (SSPBMg-C300-CRE) 11.4 RESPONSES TO COMMANDS FROM SLAVE TO MASTER 11.4.1 C ONDITION TA TUS ESPONSE TABLE 11: COND ITION STATUS RESPONSE Bit No 2nd byte 3rd byte byte 5 byte byte Status 1-on, 0-off 1- Sum Alarm Output le... -
Page 42: Read Gain/Attenuation Range Response
SSPB-C300 (SSPBMg-C300-CRE) 11.4.3 R GAIN/ATTENUATION R ANGE ESPONSE TABLE 13: READ GAIN/ATTENUATION RANGE RESPONSE Bit No byte byte byte byte byte MS byte LS byte MS byte LS byte minimum minimum maxi m imum 0x5A value value value 11.4.4 R... -
Page 43: Appendix B: Rs-485 Skywan Serial Communication Protocol
SSPB-C300 (SSPBMg-C300-CRE) 12. APPENDIX B: RS-485 SKYWAN SERIAL COMMUNICATION ROTOCOL For rem ote operation, the SSPB is equipped with a monitor and control function. Th e M&C function contains all of the relevant data concerning the control and status signals of th e SSPB. -
Page 44: Transmission Interface
SSPB-C300 (SSPBMg-C300-CRE) 12.3.1 T RANSMISSION NTERFACE A request packet (see TABLE ) is sent by the IDU and the respective response packet (see TABLE ) by the SSPB. The IDU is the bus master. The SSPB is only allowed to respond if the first byte of the request packet matches its address and the checksum is consistent. -
Page 45: Command Message Structure (Idu To Sspb)
SSPB-C300 (SSPBMg-C300-CRE) 12.3.2 C (IDU SSPB) OMMAND ESSAGE TRUCTURE TABLE 15: COMMAND MESSAGE STRUCTURE Byte Name Description Value Address Address of SSPB 0x01 to 0x0F Command Request Status 0x01 Transmit ON/OFF 0x02 Change Address 0x03 Set Input Frequency 0x04 Not applicable for these units... -
Page 46: Response Message Structure (Sspb To Idu)
SSPB-C300 (SSPBMg-C300-CRE) 12.3.3 R (SSPB IDU) ESPONSE ESSAGE TRUCTURE TABLE 16: RESPONSE MESSAGE STRUCTURE Byte Name Description Value dress Address of SSPB shifted left by 4 0x10 to 0x Level Byte 1 MS byte of T x output power Level Byte 2...
