- Page 1 INSTALLATION AND OPERATING MANUAL 400W C-Band Hub-mount SOLID STATE POWER BLOCK UP-CONVERTER (SSPB) SSPBMg–C400–BRE PM 1R0-3181A0-2N1, Rev. 1...
- Page 2 This Advantech Wireless product is warranted against defects in material and workmanship for a period of 2 years from date of shipment. During the warranty period, Advantech Wireless will, at its option, either repair or replace products that will prove to be defective.
-
Page 3: Table Of Contents
SSPBMg-C400-BRE CONTENTS SAFETY..........................6 GENERAL INFORMATION ...................8 INTRODUCTION ......................8 DESCRIPTION........................8 2.2.1 Power Supply .......................8 2.2.2 Up-Converter Assembly ....................9 2.2.3 10 MHz Reference Oscillator ..................9 2.2.4 HPA Assembly......................10 2.2.5 Controller Board ......................10 SSPB SPECIFICATIONS .....................14 UNPACKING AND INSTALLATION................18 INITIAL INSPECTION....................18 UNPACKING ........................18 INSTALLATION ......................18... - Page 4 SSPBMg-C400-BRE PRE-POWER PROCEDURES..................23 MAINTENANCE......................24 PREVENTIVE MAINTENANCE.................24 6.1.1 Mechanical Preventive Maintenance .................24 6.1.2 Checking the Cooling Fans..................24 RS-232 SERIAL COMMUNICATION .................25 HAND-HELD TERMINAL ..................25 RS-232 PC TERMINAL....................27 RS-485 SERIAL COMMUNICATION .................35 PACKING LIST.......................36 SAFETY AND EMC COMPLIANCE ................37 APPENDIX A: RS-485 SERIAL COMMUNICATION PROTOCOL.......38 11.1...
- Page 5 SSPBMg-C400-BRE FIGURES 1: P ...................... 11 IGURE RODUCT UTLINE 2: P ) ................12 IGURE RODUCT UTLINE FANS SIDE VIEW 3: B ......................13 IGURE LOCK IAGRAM 4: C ....................... 16 IGURE ONNECTORS 5: H HELP M ................25 IGURE...
- Page 6 SSPBMg-C400-BRE TABLES TABLE 1: ELECTRICAL SPECIFICATIONS................14 TABLE 2: MECHANICAL SPECIFICATIONS ................ 15 TABLE 3: POWER REQUIREMENTS ..................15 TABLE 4: ENVIRONMENTAL CONDITIONS................ 15 TABLE 5: CONNECTORS ......................17 TABLE 6: AC LINE (J5) – PIN ASSIGNMENTS..............17 TABLE 7: SYSTEM CONTROL (RS232 RS485) – PIN ASSIGNMENTS ......21 TABLE 8: SERIAL INTERFACE RS-232 CONNECTION INFORMATION......
-
Page 7: Safety
SSPBMg-C400-BRE 1. SAFETY In addition to this section, included by reference are the following pertinent sections of the International Standard IEC-215, ‘Safety requirements for radio transmitting equipment’: Appendix D, ‘GUIDANCE ON ASSESSING THE COMPETENCE OF PERSONNEL FOR DESIGNATION AS SKILLED’ and also Sub-clause 3.1 of the Standard. - Page 8 The maximum permissible levels of exposure are quite low in comparison to the power levels produced by the equipment built by Advantech Wireless (e.g. less than 10 mW versus 4 to 700 W delivered by the different units). The maximum permissible levels are currently being studied by a number of organizations.
-
Page 9: General Information
For a safe and versatile operation, please read the information carefully BEFORE using the equipment. Advantech Wireless has prepared this manual for use as a guide for the proper installation, operation and maintenance of Advantech Wireless equipment and computer programs. The drawings, specifications and information contained herein are the property of Advantech Wireless. -
Page 10: Up-Converter Assembly
SSPBMg-C400-BRE 2.2.2 U ONVERTER SSEMBLY The L-Band signal arriving from a modem enters the Up-Converter Assembly through a ‘N-type’ connector, see Figure 4: Connectors (page 16). The L-Band signal (950 MHz to 1525 MHz) enters the high gain Low Noise Amplifier (LNA) and Medium Power Amplifier (MPA) stages that boost the RF power level sufficient for the transmission through the Up- Converter Assembly. -
Page 11: Hpa Assembly
SSPBMg-C400-BRE 2.2.4 HPA A SSEMBLY The HPA Assembly amplifies the RF signal from the Up-Converter Assembly to a power level sufficient for transmission. Integral to this module are three HPA stages and a power conditioner board. Other functionality includes internal power conditioning and overtemperature shutdown. -
Page 12: Figure 1: Product Outline
SSPBMg-C400-BRE Figure 1: Product Outline Page 11... -
Page 13: Figure 2: Product Outline
SSPBMg-C400-BRE Figure 2: Product Outline (fans side view) Page 12... -
Page 14: Figure 3: Block Diagram
SSPBMg-C400-BRE RV_PWR FW_PWR +24 V +12 V MUTE FAULT SHUT-DOWN_MON C (temp info) -9 V TERM SD_MON FAULT MUTE LEDS REDUND RS485 RS232 + 5 V FW_PWR RV_PWR +12 V +48 V (VAR) +48 V (VAR) +12V Figure 3: Block Diagram... -
Page 15: Sspb Specifications
SSPBMg-C400-BRE 2.3 SSPB SPECIFICATIONS TABLE 1: ELECTRICAL SPECIFICATIONS L-Band Input Frequency 950 – 1525 MHz RF Output Frequency Range 5.850 – 6.425 GHz Frequency Stability Based upon 10 MHz Internal Reference RF Saturated Output Power (P + 56 dBm, typical (400 W) Linear Output Power (P + 52.0 dBm, min... -
Page 16: Table 2: Mechanical Specifications
SSPBMg-C400-BRE TABLE 2: MECHANICAL SPECIFICATIONS Physical Dimensions See Figure 1: Product Outline (page 11) – white paint Approximate Weight 66 lbs (30 kg) Mounting holes (4) ¼ - 20, 0.40” (10 mm) deep, see Figure 1: Product Outline (page 11) - Page 17 SSPBMg-C400-BRE Figure 4: Connectors Page 16...
-
Page 18: Table 5: Connectors
SSPBMg-C400-BRE TABLE 5: CONNECTORS Connector Function Description Mating Connector RF IN (J1) N-Type (F) N-Type (M) (Up-converter Input) M&C Serial Interfaces (J2) MS 3112E12-10P (M) MS 3116G12-10S (F) RS-485 & RS-232 AC Supply (J5) AC LINE MS3102R-10SL-3P (M) MS3106F-10SL-3S (F) -
Page 19: Unpacking And Installation
SSPBMg-C400-BRE 3. UNPACKING AND INSTALLATION This Section contains instructions for the site preparation, unpacking and the installation of an SSPB. 3.1 INITIAL INSPECTION Inspect the shipping container for damage. If the container or cushioning material is damaged, immediately contact the carrier that delivered the equipment and submit a damage report. -
Page 20: Electrical Connections
The centre pins of the connectors used by Advantech Wireless have a precision tolerance measured in mils (1/1000 inch). The mating connectors of the various suppliers may not be of precision types. -
Page 21: Cooling Considerations
SSPBMg-C400-BRE 3.3.4 C OOLING ONSIDERATIONS The SSPB is forced-air cooled. The cooling fans are configured for 12 V DC operation, supplied by the main power supply of the unit. Depending on environmental conditions, the airflow opening may become obstructed by debris, reducing the efficiency of the cooling system. -
Page 22: Interfaces
SSPBMg-C400-BRE 4. INTERFACES 4.1 SYSTEM CONTROL CONNECTOR (RS-485 RS-232) The System Control interface connector is located at port (RS232 RS485) of the SSPB. This is a 10-pin MS3112E12-10P (male) connector with pin assignments as shown in TABLE 7 below. Both RS-485 and RS-232 serial interfaces are for the serial interface communication link, allowing for the external monitoring and control of the SSPB. -
Page 23: Redundant Interface
SSPBMg-C400-BRE 4.2 REDUNDANT INTERFACE The Redundant Interface connections are made with a 10-pin circular connector mounted on the SSPB enclosure. The connector type is listed in TABLE 5 at page 17 and the location is shown in Figure 4 at page 16. A redundant system cable is provided with the redundancy kit that provides the interconnection between the two SSPB units and the waveguide switch in a redundant configuration. -
Page 24: Pre Power And Checkout
SSPBMg-C400-BRE 5. PRE POWER AND CHECKOUT This Section contains the pre-power and checkout procedure for the SSPB model SSPBMg-C400-BRE. WARNING! The information presented in this Section is addressed to the technicians who have specific training in, and knowledge of the Microwave Power Transmitters. -
Page 25: Maintenance
SSPBMg-C400-BRE 6. MAINTENANCE This Section describes the scheduled maintenance procedure for the SSPB. CAUTION! Improper maintenance of the SSPB may void the warranty. 6.1 PREVENTIVE MAINTENANCE This product requires minimum maintenance, which consists of visual inspection and cleaning. WARNING! Personnel performing maintenance on this system must have the proper training and become thoroughly familiar with the related safety requirements and issues. -
Page 26: Rs-232 Serial Communication
SSPBMg-C400-BRE 7. RS-232 SERIAL COMMUNICATION 7.1 HAND-HELD TERMINAL W a t t C - B a n d S S P B > ENTER ENTER ENTER ENTER L I S T C O M M A N D S S T A... -
Page 27: Figure 6: Hand - Heldt
SSPBMg-C400-BRE > S T A ENTER S S P B S T A T U S P L L s t a t u s l o c k o u t p u t A t t e n u a t i o n 0 . -
Page 28: Rs-232 Pc Terminal
SSPBMg-C400-BRE 7.2 RS-232 PC TERMINAL For RS-232 VT communication, use the following communication parameters: - Bits per second: 9600 - Data Bits: 8 - Parity: None - Stop bits: 1 - Flow Control: None TABLE 8: SERIAL INTERFACE RS-232 CONNECTION INFORMATION... -
Page 29: Figure 7: Hyper Terminal
SSPBMg-C400-BRE Figure 7: HyperTerminal RS-232 Communication – help command and response Page 28... -
Page 30: Figure 8: Hyper Terminal
SSPBMg-C400-BRE Figure 8: HyperTerminal RS-232 Communication – status command and response Page 29... -
Page 31: Figure 9: Hyper Terminal
SSPBMg-C400-BRE Figure 9: HyperTerminal RS-232 Communication – help rf, rf and rf off commands and responses Page 30... -
Page 32: Figure 10: Hyper Terminal
SSPBMg-C400-BRE Figure 10: HyperTerminal RS-232 Communication – help att, att, gain and att <value> commands and responses Page 31... -
Page 33: Figure 11: Hyper Terminal
SSPBMg-C400-BRE Figure 11: HyperTerminal RS-232 Communication – help gain, gain, att and gain <value> commands and responses Page 32... -
Page 34: Figure 12: Hyper Terminal
SSPBMg-C400-BRE Figure 12: HyperTerminal RS-232 Communication – “help baud” and “baud rs232” commands and responses NOTE: The baud rate may be set only f or RS-232 seria l interface (to 9600 or to 19200 bauds). fter re-setting the baud rate, the communication program used (HyperTerminal or other VT ommunication programs) must be set for the new baud rate. -
Page 35: Figure 13: Hyper Terminal
SSPBMg-C400-BRE Figure 13: HyperTerminal RS-232 Communication – “help rs485”, “rs485 ascii” and “rs485 binary” commands and responses NOTE: The rs485 parameter may be set to ascii, to binary, or to skywan. When this parameter is set to ascii, the RS-485 serial interface will work as a VT serial interface (the same windows as for RS-232 serial interface will be available o RS-485 interface). -
Page 36: Rs-485 Serial Communication
SSPBMg-C400-BRE 8. RS-485 SERIAL COMMUNICATION he RS-485 serial communication is based on the protocol in 11 APPENDIX A: RS-485 SERIAL COMMUNICATION PROTOCOL at page 38. Note that in order to connect the RS-485 of the unit to the RS-232 interface of a PC an adequate RS-485/RS-232 adapter should be used. -
Page 37: Packing List
Installation and Operating Manual PM 1R0-3181A0-2N1 Rev. 1 C-Band 400 Watt SSPB, 1R0-3181A0-2N1 model SSPBMg-C400-BRE Connector Circular MIL C-5015, Straight Cable Plug, 16 Shell, 3 Socket MS3106F16- 631-310616-001 10S (connector for AC LINE connector J5) Connector Circular 26482 Straight Plug 12... -
Page 38: Safety And Emc Compliance
SSPBMg-C400-BRE 10. SAFETY AND EMC COMPLIANCE Advantech Wireless produc ts are compliant with the following standards: SAFETY: IEC 60950-1 second edition 2005 EMC: EN301489-1 2004 (EMC for radio equipment and services, common technical requirements) EN 55022: 1998 / A1: 2000 - Class A EN 000-4 -4 Transient/burst 0.5kV Signal Lines, 1 kV... -
Page 39: Appendix A: Rs-485 Serial Communication Protocol
0x55. After this start byte, each frame consists of 7 bytes. Firs t byte: ter (NMS) to Slave (Advantech Wireless unit): Address of correspo ndent Advantech Wireless unit (0x01 to 0x0F). Slave to Master: When Advantech Wireless unit sends the respond frame to NMS, it left shifts its unit address by 4. -
Page 40: Commands
SSPBMg-C400-BRE 11.3 COMMANDS These commands go only from master-slave direction. TABLE 10: COMMANDS Respond. 2,3,4,5,6 Description 2nd byte 3, 4, 5 &6 bytes bytes. Request condition 0x01 or 0x2A 0xAA AA AA AA See TABLE 11 status Mute/Unmute 0x5A AA AA AA To mute... -
Page 41: Responses To Commands From Slave To Master
SSPBMg-C400-BRE 11.4 RESPONSES TO COMMANDS FROM SLAVE TO MASTER 11.4.1 C ONDITION TATUS ESPONSE TABLE 11: CON DITION STATUS RESPONSE Bit No 2nd byte 3rd byte byte byte byte Status 1-on, 0-off Sum Alarm Output level Output level 0x00 MS byte... -
Page 42: Read Identification Response
SSPBMg-C400-BRE 11.4.2 R DENTIFICATION ESPONSE TABLE 12: READ IDENTIFICATION RESPONSE Bit No byte byte byte byte byte 1- Rx spectrum inv 0x00 – N/A 1 – Up 0- not Rx spectrum inv 0x01 – 70 to L 1 – Down 0x02 –... -
Page 43: Appendix B: Rs-485 Skywan Serial Communication Protocol
SSPBMg-C400-BRE 12. APPENDIX B: RS-485 SKYWAN SERIAL COMMUNICATION ROTOCOL For remote oper ation, the SSPB is equipped with a monitor and control funct ion. The M&C function contain s all of the relevant data concerning the control and status sign als of the SSPB. -
Page 44: Transmission Interface
SSPBMg-C400-BRE 12.3.1 T RANSMISSION NTERFACE A request packet (see TABLE 14) is sent by the IDU and the respective response packet (see TABLE 15) by the SSPB. The IDU is the bus master. The SSPB is only allowed to respond if the first byte of the request packet matches its address and the checksum is consistent. -
Page 45: Command Message Structure (Idu To Sspb)
SSPBMg-C400-BRE 12.3.2 C (IDU SSPB) OMMAND ESSAGE TRUCTURE TABLE 14: COMMAND MESSAGE STRUCTURE Byte Name Description Value Address Address of SSPB 0x01 to 0x0F Command Request Status 0x01 Transmit ON/OFF 0x02 Change Address 0x03 Set Input Frequency 0x04 Not applicable for these units... -
Page 46: Response Message Structure (Sspb To Idu)
SSPBMg-C400-BRE 12.3.3 R (SSPB IDU) ESPONSE ESSAGE TRUCTURE TABLE 15: RESPONSE MESSAGE STRUCTURE Byte Name Description Value dress Address of SSPB shifted left by 4 0x10 to 0x Level Byte 1 MS byte of T x output power Level Byte 2...
