- Page 1 Refrigerator User manual RS58K*/RS62K* Free Standing Appliance Untitled-30 1 7/17/2017 5:03:56 PM...
-
Page 2: Table Of Contents
Contents Safety information Important safety symbols and precautions: Severe warning signs for transportation and site Critical installation warnings Installation cautions Critical usage warnings Usage cautions Cleaning cautions Critical disposal warnings Additional tips for proper usage Saving Energy Tips This appliance is intended to be used in household and similar applications such as Instructions about the WEEE Installation Refrigerator at a glance... -
Page 3: Safety Information
Safety information • Before using your new Samsung Refrigerator, please read this manual thoroughly to ensure that you know how to operate the features and functions that your new appliance offers safely and efficiently. • This appliance is not intended for use by persons (including... - Page 4 Safety information • In order to avoid the creation of a flammable gas-air mixture if a leak in the refrigerating circuit occurs, the size of the room in which the appliance may be sited depends on the amount of refrigerant used. •...
-
Page 5: Important Safety Symbols And Precautions
Important safety symbols and precautions: Please follow all safety instructions in this manual. This manual uses the following safety symbols. WARNING Hazards or unsafe practices that may result in severe personal injury, property damage, and/or death. CAUTION Hazards or unsafe practices that may result in severe personal injury and/or property damage. -
Page 6: Severe Warning Signs For Transportation And Site
Safety information Severe warning signs for transportation and site WARNING • When transporting and installing the appliance,care should be taken to ensure that no parts of the refrigerating circuit are damaged. - Refrigerant leaking from the pipe work could ignite or cause an eye injury. -
Page 7: Critical Installation Warnings
Critical installation warnings WARNING • Do not install the refrigerator in a damp location or place where it may come in contact with water. - Deteriorated insulation on electrical parts may cause an electric shock or fire. • Do not place this refrigerator in direct sunlight or expose it to the heat from stoves, room heaters, or other appliances. - Page 8 Safety information • Never unplug your refrigerator by pulling on the power cord. Always grip the plug firmly and pull straight out from the outlet. - Damage to the cord may cause a short-circuit, fire, and/or electric shock. • Do not use aerosols near the refrigerator. - Using aerosols near the refrigerator may cause an explosion or fire.
- Page 9 • If any dust or water is in the refrigerator, pull out power plug and contact your Samsung Electronics service center. - Otherwise there is a risk of fire. • Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.
-
Page 10: Installation Cautions
Safety information • If the power cord is damaged, have it replaced immediately by the manufacturer or one of its service agents. • The fuse on the refrigerator must be changed by a qualified technician or service company. - Failing to do so may result in an electric shock or personal injury. -
Page 11: Critical Usage Warnings
Critical usage warnings WARNING • Do not insert the power plug into a wall socket with wet hands. - This may result in an electric shock. • Do not store articles on the top of the appliance. - When you open or close the door, the articles may fall and cause personal injury and/or material damage. - Page 12 • If you smell pharmaceutical or smoke, pull out power plug immediately and contact your Samsung Electronics service center. • If any dust or water is in Refrigerator, pull out power plug and contact your Samsung Electronics service center.
- Page 13 • Never put fingers or other objects into the water dispenser hole, ice chute and ice maker bucket. - It may cause a personal injury or material damage. • Do not use or place any substances sensitive to temperature such as flammable sprays, flammable objects, dry ice, medicine, or chemicals near or inside of the refrigerator.
- Page 14 Safety information • Keep fingers out of “pinch point” areas. Clearances between the doors and cabinet are necessarily small. Be careful when you open the doors if children are in the area. • If a gas leak is detected, avoid any naked flames or potential sources of ignition, and air the room in which the appliance is standing for several minutes.
- Page 15 • If the refrigerator emits a burning smell or smoke, unplug the refrigerator immediately and contact your Samsung Electronics service center. - Failing to do so may result in an electric or fire hazards. • Pull the power plug out of the socket before changing the interior lamps of the refrigerator.
-
Page 16: Usage Cautions
Safety information Usage cautions CAUTION • Do not re-freeze frozen foods that have thawed completely. Do not place carbonated or fizzy drinks in the freezer compartment. Do not put bottles or glass containers in the freezer. - When the contents freeze, the glass may break and cause personal injury. - Page 17 - Any changes or modifications performed by a 3rd party on this finished appliance are not covered under Samsung warranty service, nor is Samsung responsible for safety issues that result from 3rd party modifications. • Do not block the air vents inside the refrigerator.
- Page 18 • When the refrigerator got wet by water, pull out the power plug and contact your Samsung Electronics service center. • Do not strike or apply excessive force to any glass surface.
-
Page 19: Cleaning Cautions
Cleaning cautions CAUTION • Do not spray water directly on the inside or outside the refrigerator. - There is a risk of fire or electric shock. • Do not use a hair dryer to dry the inside of the refrigerator. •... - Page 20 Safety information • Do not use abrasive or harsh cleansers such as window sprays, scouring cleansers, flammable fluids, muriatic acid, cleaning waxes, concentrated detergents, bleaches, or cleansers containing petroleum products on exterior surfaces (doors and cabinet), plastic parts, door and interior liners, and gaskets. - These can scratch or damage the material.
-
Page 21: Critical Disposal Warnings
Critical disposal warnings WARNING • Please dispose of the packaging material from this product in an environmentally friendly manner. • Ensure that none of the pipes on the back of the refrigerator are damaged prior to disposal. • R-600a or R-134a is used as a refrigerant. Check the compressor label on the rear of the appliance or the rating label inside the fridge to see which refrigerant is used for your refrigerator. -
Page 22: Additional Tips For Proper Usage
Safety information Additional tips for proper usage • In the event of a power failure, call the local office of your electric company and ask how long the failure is going to last. - Most power failures that are corrected in an hour or two will not affect your refrigerator temperatures. -
Page 23: Saving Energy Tips
Saving Energy Tips • Install the appliance in a cool, dry room with adequate ventilation. Ensure that it is not exposed to direct sunlight and never put it near a direct source of heat (a radiator, for example). • Not to block any vents and grilles is recommended for energy efficiency. -
Page 24: Instructions About The Weee
This product and its electronic accessories should not be mixed with other commercial wastes for disposal. For information on Samsung’s environmental commitments and product specific regulatory obligations e.g. REACH visit: samsung. com/uk/aboutsamsung/samsungelectronics/corporatecitizenship/ data_corner.html (For products sold in European countries only) -
Page 25: Installation
Installation Follow these instructions carefully to ensure a proper installation of this refrigerator and to prevent accidents before using it. WARNING • Use the refrigerator only for its intended purpose as described in this manual. • Any servicing must be performed by a qualified technician. •... - Page 26 Installation RS62* 01 Freezer shelves 02 Multipurpose freezer 03 Dried food and meat guard storage bin 04 Refrigerator guard 05 Refrigerator shelves 06 Vegetable bin 07 Multipurpose bin 08 Egg container 09 Ice maker bucket ** 10 Moving tray * 11 Anti-bacteria filter * 12 Water filter ** 13 Ice tray...
- Page 27 English 27 Untitled-30 27 7/17/2017 5:03:59 PM...
-
Page 28: Step-By-Step Installation
Installation Step-by-step installation STEP 1 Select a site Site requirements: • Solid, level surface without carpeting or flooring that may obstruct ventilation • Away from direct sunlight • Adequate room for opening and closing the door • Away from a heat source •... - Page 29 Clearance See the pictures and table below for space requirements for installation. Depth “A” Width “B” Height “C” 1796 Overall Height “D” 1825 (unit: mm) 01 50 mm 02 165° 03 519 mm 04 1742 mm 05 610 mm 06 908 mm 07 31 mm 08 1345 mm NOTE...
- Page 30 Installation STEP 2 Flooring • The surface to install the refrigerator must support a fully loaded refrigerator. • To protect the floor, put a large piece of cardboard on each leg of the refrigerator. • Once the refrigerator is in its final position, do not move it unless necessary to protect the floor.
- Page 31 STEP 3 Adjust the levelling feet CAUTION • The refrigerator must be levelled on a flat, solid floor. Failing to do so can cause damage to the refrigerator or physical injury. • Levelling must be performed with an empty refrigerator. Make sure no food items remain inside the refrigerator.
- Page 32 Installation STEP 4 Adjust the door height as well as the door gap To adjust the height of a door The height of a door can be adjusted using the clamp nut and the height nut on the front bottom of each door. 1.
- Page 33 To correct the gap between a door and the refrigerator unit The gap can be adjusted manually using the gap bolt on the top rear side of each door. 1. To adjust the gap, do the following: - To widen the gap, turn the gap bolt (A) clockwise.
- Page 34 • Samsung takes no responsibility for the water line installation. If water leaks occur, contact the installer of the water line.
- Page 35 CAUTION The waterline must be repaired by a qualified professional. If you encounter a water leak, contact a local Samsung service centre or the installer of the waterline. STEP 6 Initial settings By completing the following steps, the refrigerator should be fully functioning.
-
Page 36: Door Removal For Entrance
Installation Door removal for entrance If the refrigerator cannot pass through the entrance due to its size, follow these instructions: Tools required (not provided) These tools are used for removing the doors. Philips screwdriver Flat-heat Socket spanner Allen spanner screwdriver (10 mm) (5 mm) Disconnect the water line... - Page 37 Detach the doors CAUTION The door may fall off or over and damage itself during any of these steps. To prevent an accident, use extreme caution when performing these steps. 1. Use a Philips screwdriver to unscrew the hinge covers (A) on the top of each door.
- Page 38 Installation 5. Remove the hinges (C) on both sides. 6. Gently lift up the doors one by one to remove. Use caution as the door may fall off or over. Reconnect the water hoses Once the refrigerator has passed through the entrance, reconnect the water hoses and insert the provided clips (x2) to tighten the coupler.
- Page 39 Reattach the doors CAUTION • Before reattaching the doors, make sure all the electrical connectors are properly connected. • The freezer door must be reattached before the fridge door. 1. Hold the freezer door and hook to the hinge at the bottom of the refrigerator. 2.
- Page 40 Installation 4. Connect the electrical harness. 5. Insert the hinge covers with the front sides first, and then tighten the screws. Use a Philips screwdriver for this step. English Untitled-30 40 7/17/2017 5:04:04 PM...
-
Page 41: Operations
Operations Feature panel RS62* RS58* 01 Freezer / Power Freezer 02 Lighting / °C °F 03 Vacation 04 Fridge / Power Cool 05 Door Alarm 06 Filter * 07 Control Lock 08 Water / Filter Reset* 09 Cube/Crushed Ice / Ice Maker Off * Applicable models only English 41... - Page 42 Operations 01 Freezer / Power Freeze (3 sec) The Freezer button can be used to set the freezer temperature, or to Freezer activate Power Freeze. Available temperatures are between -15 °C (5 °F) and -23 °C (-8 °F). Power Freeze speeds up the freezing process at maximum fan speed. The freezer keeps running at full speed for several hours and then returns to the previous temperature.
- Page 43 04 Fridge / Power Cool (3 sec) The Fridge button can be used to set the fridge temperature, or to activate/deactivate Power Cool. You can manually adjust the cooling temperature for the fridge. Keep Fridge pressing Fridge to cycle through the temperature bar, and select a desired temperature between 1 °C (34 °F) and 7 °C (44 °F).
- Page 44 Operations 07 Control Lock (3 sec) To activate the Control Lock, press and hold Control Lock for 3 seconds. The controls on the display are disabled, and the dispenser Control Lock does not operate even if you push the lever. To deactivate, press and hold again for 3 seconds.
-
Page 45: Temperature Settings
Temperature settings To ensure optimal performance, we recommend setting the temperature to -19 °C (-2 °F) for the freezer, and 3 °C (37 °F) for the fridge. Freezer The freezer temperature can be adjusted between -23 °C (-9 °F) and -15 °C (5 °F). To change the temperature, keep pressing Freezer until a desired temperature is selected. -
Page 46: Special Features
Operations Special features The refrigerator features user-oriented devices that you can use to benefit from. Water dispenser (applicable models only) With the water dispenser, you can dispense water without opening the fridge door. Basically, the water dispenser offers 3 options: chilled water, cubed ice, and crushed ice. - Page 47 To fill the water tank For first-time use, clean the inner side of the water tank and dry well. 1. Hold both handgrips on the front of the tank, and slide out as shown. 2. Open the front lid (A) of the cover or the entire cover (B) and fill the tank with a max of 5 liters water.
- Page 48 5. You will hear another chime if the ice maker operates properly. NOTE If this symptom continues, contact the waterline installer or a local Samsung service centre. CAUTION • Do not press the button repeatedly after the ice tray is filled with ice or water. Water may overflow or ice may be jammed.
- Page 49 • When the refrigerator recovers power supply after a power failure, the icemaker bucket may contain a mix of melted and jammed ice cubes, resulting in a system failure. To prevent this, make sure to empty the icemaker bucket before using the refrigerator.
- Page 50 Operations To secure more storage space (applicable models only) If you do not use the ice maker and need more storage space, remove the icemaker bucket (A) and the snack bin. Then, insert the freezer guide (B) into the icemaker bucket’s place.
- Page 51 3. When done, turn the gear handle on the rear of the bucket by 90°, and then put the bucket back into position. Make sure the bucket is inserted properly until you hear a clicking sound. 4. Press and hold Ice Maker Off for 3 seconds to reset the icemaker.
- Page 52 Operations 1. Gently lift up the icemaker cover (A) to remove. 2. Press Test (B) on the side of the icemaker. Normally, the ice cube container fills with water in a few minutes. 3. If the water level is lower than expected, check the water pressure of the water supply line from the water source.
-
Page 53: Maintenance
Maintenance Handle and care Shelves (fridge/freezer) • To remove a shelf, fully open the corresponding door. Hold the front of the shelf and gently lift up and slide out. Rear • If the door cannot fully open, slide out the shelf half way to the front and turn it over to remove. - Page 54 Maintenance Door guard To remove a door guard, hold the front sides of the bin and gently lift up to remove. Drawers Gently lift up the front of the drawer and slide out. English Untitled-30 54 7/17/2017 5:04:09 PM...
- Page 55 Vegetable bin / Dry bins To remove the vegetable bin from the fridge or the dry bin from the freezer. 1. First, remove surrounding multipurpose bins if necessary. 2. If your refrigerator is provided with a cover (A) for the vegetable/dry bin, remove the cover.
- Page 56 Maintenance Sealing guard (applicable models only) To remove the sealing guard Gently lift up the guard, and then pull it to the front while holding the bottom side. To reinsert the sealing guard 1. Put the guard on the front of the housing.
-
Page 57: Cleaning
Icemaker bucket To remove the icemaker bucket, see the Diagnosis section on page 50. Cleaning Interior and exterior WARNING • Do not use benzene, thinner, or home/car detergent such as Clorox™ for cleaning purposes. They may damage the surface of the refrigerator and cause a fire. •... -
Page 58: Replacement
• Do not use third-party water filters. Use only Samsung-provided or -approved filters. • Unapproved filters may leak and damage the refrigerator, causing electric shock. Samsung holds no responsibility for any damage that may occur from use of third- party water filters. - Page 59 For more information or servicing, contact a licensed plumbing professional. Ordering a new filter To purchase a new water filter, contact a local Samsung service centre. Lamps and anti-bacteria filter Neither lamps nor the anti-bacteria filter are user-serviceable. Do not attempt to replace them yourself.
-
Page 60: Troubleshooting
Troubleshooting If you encounter an abnormal situation with the refrigerator, first check the table below and try the suggestions. General Symptom Action • Make sure the power cord is connected properly. • Make sure the temperature control is set correctly. Try setting to a lower temperature. - Page 61 Symptom Action • To prevent condensation from forming, the refrigerator has heat-proof piping in the front corners. If the ambient temperature rises, this equipment may not work effectively. The front corners This is not a system failure. and sides become •...
- Page 62 Troubleshooting Symptom Action Check the following: • Push the water dispenser lever to check the water supply. • Push the ice dispenser lever to check the operation of the auger motor in the ice maker assembly. • Check if there are any objects that obstruct the auger motor Ice maker does not from running.
- Page 63 Memo Untitled-30 63 7/17/2017 5:04:11 PM...
- Page 64 Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Country Contact Center Web Site NEW ZEALAND 0800 726 786 www.samsung.com/nz/support 1800 40 SAMSUNG (1800 40 7267864) INDIA www.samsung.com/in/support...
