Casio 2789 Operation Manual

MA0309-EA
About This Manual
General Guide
• Press C to change from mode to mode.
• In any mode, press B to illuminate the display.
Timekeeping Mode
Timekeeping
This watch features separate digital and analog timekeeping. The procedures for
setting the digital time and analog time are different.
• In the Timekeeping Mode, you can press D to change the display format as shown
below.
PM Day of week
indicator
Hour
Digital Time and Date
Use the Timekeeping Mode to set and view a digital display of the current time and date.
When setting the digital time, you can also configure settings for summer time
(Daylight Saving time or DST), your Home City code (the code for the city where you
normally use the watch), and the 12/24-hour format.
• This watch is preset with a number of city codes, each of which represents the time
zone where that city is located. When setting the digital time, it is important that you
select the correct city code for your Home City. If your location is not included in the
preset city codes, select the preset city code that is in the same time zone as your
location.
• Note that all of the times for the World Time Mode city codes are displayed in
accordance with the digital time and date settings you configure in the Timekeeping
Mode.
• After you correctly set your Home City time and date, you can set the watch up for
timekeeping with a different city code simply by changing the Home City code in the
Timekeeping Mode.
To set the digital time and date
3. Press C to move the flashing in the sequence shown below to select the other settings.
Seconds DST
Day Month
4. When the setting you want to change is flashing, use B and D to change it as
described below.
Screen To do this:
Reset the seconds to
Toggle between Daylight Saving Time (
Standard Time (
Change the Home City code
Change the hour or minutes
Toggle between 12-hour (
( ) timekeeping
24H
Change the year
Change the month or day
5. Press A to exit the setting screen.
• Resetting the seconds only (without changing the DST, Home City code, hour, or
minute setting) causes the analog minute hand setting to be adjusted automatically.
• See "Digital Time Daylight Saving Time (DST) Setting" below for details about the
DST setting.
Digital Time Daylight Saving Time (DST) Setting
Daylight Saving Time (summer time) advances the digital time setting by one hour
from Standard Time. Remember that not all countries or even local areas use Daylight
Saving Time.
Operation Guide 2789
• All of the displays in this manual show black-on-white.
• Button operations are indicated using the letters shown
in the illustration.
• Each section of this manual provides you with the
information you need to perform operations in each
mode. Further details and technical information can be
found in the "Reference" section.
World Time Mode Countdown Timer Mode
Press .
Month
Minutes
Press .
Seconds
1. In the Timekeeping Mode, hold down A until the
seconds start to flash, which indicates the setting
screen.
2. Press C twice to move the flashing to the Home City
code setting (see the illustration below), and then use
B and D to select the code you want.
• Make sure you select your Home City code before
changing any other setting.
• For full information on city codes, see the "City Code
Table".
Home City Code Hour
Year 12/24-Hour format
Do this:
Press D.
00
Press D.
ON ) and
OF )
Use D (east) and B (west).
Use D (+) and B (–).
Press D.
12H ) and 24-hour
Use D (+) and B (–).
Stopwatch Mode
To toggle the Timekeeping Mode digital time between DST and Standard Time
Day
Setting the Analog Time
Perform the procedure below when the time indicated by the analog hands does not
match the time of the digital display.
To adjust the analog time
Hour hand Minute hand
• If you need to advance the analog time setting a long way, hold down D until the
time starts advancing at high speed, and then press B. This locks the high-
speed hand movement, so you can release the two buttons. High-speed hand
movement continues until you press any button. It will also stop automatically
after the time advances 12 hours or if an alarm (daily alarm, Hourly Time Signal,
or countdown beeper) starts to sound.
4. Press A to exit the setting screen.
• The watch will automatically adjust the minute hand slightly to match its internal
second count when you exit the setting screen.
• To return to the Timekeeping Mode, press C.
World Time
City code
Minutes
Current time for the
selected city code
To toggle a city code time between Standard Time and Daylight Saving Time
• Note that the DST/Standard Time setting affects only the currently displayed city
code. Other city codes are not affected.
• Note that you cannot switch between Standard Time and Daylight Saving Time while
GMT is selected as the city code.
Alarm Mode Hand Setting Mode
1. In the Timekeeping Mode, hold down A until the seconds
start to flash, which indicates the setting screen.
2. Press C once to display the DST setting screen.
3. Press D to toggle between Daylight Saving Time (
displayed) and Standard Time ( displayed).
OF
4. Press A to exit the setting screen.
• The DST indicator appears on the Timekeeping and
Hand Setting Mode displays to indicate that Daylight
Saving Time is turned on.
1. In the Timekeeping Mode, press C five times to enter
the Hand Setting Mode.
2. Hold down A until the current digital time starts to
flash, which indicates the analog setting screen.
3. Press D to advance the analog time setting by
20 seconds.
• Holding down D advances the analog time setting at
high speed.
World Time digitally displays the current time in 27 cities
(29 time zones) around the world.
• All of the operations in this section are performed in the
World Time Mode, which you enter by pressing C.
To view the time in another city
In the World Time Mode, press D to scroll eastwardly
through city codes.
• For full information about city codes, see the "City Code
Table".
• If the current time shown for a city is wrong, it probably
means there is a problem with your Timekeeping Mode
time and/or Home City code settings. Go to the
Timekeeping Mode and make the necessary
adjustments.
1. In the World Time Mode, use D to display the city code
whose Standard Time/Daylight Saving Time setting you
want to change.
2. Hold down A for about two seconds to toggle between
Daylight Saving Time (DST displayed) and Standard
Time (DST not displayed).
• The DST indicator is on the display whenever you
display a city code for which Daylight Saving Time is
turned on.
ON
1
