  • Page 1 GD3 Display User’s Manual Display User‘s Manual 5/2023...
  • Page 2 Version 0.10, May 2023 Piktronik d.o.o. is the exclusive holder of the copyright of this document. No part or all of this document may be reproduced, stored, or presented in any form without the prior written consent of Piktronik d.o.o..

  • Page 3: Table Of Contents

    Foreword ......................4 Introduction ......................6 Explanation of symbols ..................6 Notifications ......................8 Technical Data ....................9 Mounting of GD3 ....................10 GPS antenna ....................11 GD3 connections ....................12 Driving mode and charging mode ..............14 Display ....................... 15 Main screen ....................

  • Page 4: Foreword

    1 Foreword Dear Customer, We are pleased that you have chosen our product, GD3 display. Your GD3 is a cutting- edge device, enabling the control of the power system with a simple touch. The design and manufacturing were performed carefully and the device was thoroughly tested.
  • Page 5 GD3 Display User’s Manual of the system without any problems. If this product is to be used in a new or existing system with other drives, there may be some differences between their software and the software in this product. These differences may cause this product to function differently.

  • Page 6: Introduction

    GD3 Display User’s Manual 2 Introduction These instructions describe the functions of the GD3 display. GD3 is a displaying (monitoring by user) device and not a control device. The touchscreen is used on order to enable the user to observe different parameters of the device and not to alter them.
  • Page 7 GD3 Display User’s Manual Touch screen (color is different based on direction or order of change) Touch screen and swipe down Touch the screen and swipe right Touch the screen and swipe left Touch the screen and swipe up...

  • Page 8: Notifications

    ▪ You must read and apply with the safety and warning information in this manual ▪ The data indicated on your GD3 device is within the precision required by relevant international standards and rules, but it is only the display and the measurement is performed on other devices.

  • Page 9: Technical Data

    GD3 Display User’s Manual Disconnect before service and repair! Do not try to service the broken or malfunctioning device yourself, there is nothing you can do! Contact the distributor. 5 Technical Data Model Display type IPS capacitive touch display Max. brightness 1000 cd/m2 9 –...

  • Page 10: Mounting Of Gd3

    GD3 Display User’s Manual 6 Mounting of GD3 The measures of the device are in the figure below. Please consider them when preparing the boat for mounting of GD3. Dimensions of the GD3 (for mounting)

  • Page 11: Gps Antenna

    GD3 Display User’s Manual The following instructions shall be taken into account at the mounting of the GD3: ▪ GD3 should be securely mounted on a flat surface where it can be clearly observed by the user. ▪ The position and orientation of the GD3 are not important, but it should be easily accessed and clearly visible for user.

  • Page 12: Gd3 Connections

    • GPS antenna – Connector for the active GPS antenna In Piktronik systems you only need to connect GD3 CAN connector, which must be connected to CAN network of your boat and GPS antenna for the GPS data. For faster...
  • Page 13 GD3 Display User’s Manual GPS positioning, it is recommended to connect the GD3 AUX connector as well to permanent 12V power. GD3 backside GD3 CAN, 5-pin connector cable, M12 1. SHLD; optional CAN shield, 2. CAN_V+, NET-S; positive power supply, 3.

  • Page 14: Driving Mode And Charging Mode

    GD3 Display User’s Manual GD3 AUX, 8-pin connector cable, M12 1. +12VBAT, +12V power supply, 2. +12VOUT, 12V output – switched, 3. ON-OFF input, 4. IO_ECO1, input / output (programmable), 5. IO_ECO2, input / output (programmable), 6. IO_AN1, analog input (programmable), 7.

  • Page 15: Display

    GD3 Display User’s Manual 9 Display There are five screens available for GD3 display. The first screen is what you see at the Start-up screen. It is displayed when you turn on the device. The picture below shows the Piktronik logo. The boat manufacturer’s logo may alternatively appear on the screen.
  • Page 16 GD3 Display User’s Manual You can move between screens by swiping them left and right. The settings of the display can be changed by touching the top of the screen and swiping down. The three main screens in Driving mode are:...

  • Page 17: Main Screen

    GD3 Display User’s Manual In addition to these screens there are also other screens, which indicate errors or warnings in the operation of your device. All screens will be described in details in the following text. 9.1 Main screen Main screen is used in the Driving mode, when the boat is in normal operation, either driving or at standstill.

  • Page 18: Gps Error - Speed Not Measured

    GD3 Display User’s Manual 12. Motor temperature gauge (in °C) 13. Power gauge (in kW) 9.1.1 GPS error – speed not measured If the antenna is not connected or the signal is obscured, the measurement of speed cannot be performed. This is indicated on the Main screen by exchanging of this icons...

  • Page 19: Battery Screen (Driving Mode)

    GD3 Display User’s Manual Speed display when the GPS data is not available (detail) Additionally, to the icon the error information is displayed. Error display in the case of missing GPS signal It is possible to exit the screen by clicking “BACK”, but the error remains.

  • Page 20: Battery Screen (Charging Mode)

    GD3 Display User’s Manual Battery screen in Driving mode – data 1. Charging indicator 2. State of Charge gauge (in percentage, %) 3. State of Charge value (in %) 4. Screen title (BATTERY) 5. Page indicator 6. Discharge indicator 7. INFO field – to be clicked for additional information 8.

  • Page 21: Power Screen (Driving Mode)

    GD3 Display User’s Manual Battery screen in Charging mode - data 1. Charging indicator 2. State of Charge gauge (in percentage, %) 3. State of Charge value (in %) 4. Screen title (BATTERY) 5. Page indicator 6. INFO field – to be clicked for additional information 7.

  • Page 22: Power Screen (Charging Mode)

    GD3 Display User’s Manual Power screen in Driving mode – data 1. Unit for the power indication (kW) 2. Screen title (SAC in Driving mode) 3. Power indicator (in kW) 4. Power gauge (indicating the power percentage in relation to maximal power) 5.
  • Page 23 GD3 Display User’s Manual If the power gauge is in the red area make sure that the motor and inverter do not overheat. Power screen in Charging mode – data 1. Unit for the power indication (kW) 2. Screen title (KOP in Charging mode) 3.

  • Page 24: Setting The Brightness Of Your Screen

    The setting of the brightness of your screen 9.7 Open the Settings screen GD3 has several options that can be set by the user. The setting is done in a special display, which can be opened by touching the icon on the right side of the screen.
  • Page 25 The example of Settings screen in the case of disabled sound and adaptive brightness is below. If sound is disabled, no sound alarms or warnings will be generated by your GD3. Sound alarms are described in manuals of other devices in the boat.

  • Page 26: Info Screen

    GD3 Display User’s Manual Settings screen – disabled sound and adaptive brightness 9.9 Info screen In the Info screen messages regarding the operation of your system are displayed. Check the Info screen from time to time to read the messages as the given information...

  • Page 27: Calibrate The Control Lever

    GD3 Display User’s Manual 5. Low battery indicator 6. Direction / Charging indicator 7. Economy mode indicator 8. Board battery (Low voltage battery, 12V battery) voltage (in V) 9.10 Calibrate the control lever Before use of the newly installed control lever, it needs to be calibrated. The procedure is presented in the figure below.

  • Page 28: Enabling High-Power Charging

    GD3 Display User’s Manual will show up. Touch the “Ok” button to finalize the procedure. After that wait for the system to reset. When finished you can use the control lever. Calibration of the control lever - procedure 9.11 Enabling high-power charging In some cases, the high-power charging is available.
  • Page 29 GD3 Display User’s Manual High power screen – data 1. Message 2. Cancel button 3. Ok button If Cancel button is touched, the high-power operation is cancelled and high-power charging will not be performed. Low power charging will continue. High power charging canceling If Ok button is touched, the high-power operation is approved and high-power charging will be performed.

  • Page 30: Dual System Operation

    See the charger manual! 9.12 Dual system operation When the GD3 is connected to a dual-system boat (dual motor, controller, batteries), two buttons with indicators are displayed at the top left to select the Starboard or Port side of the Battery screen and Power screen.
  • Page 31 GD3 Display User’s Manual Battery screen in case of dual system – starboard system values displayed 1. Port button 2. Starboard button 3. Port button indicator 4. Starboard button indicator The choice of the system to be displayed (Starboard or Port side system) is made by touching the PT (for Port) or SD (for Starboard) button.
  • Page 32 Po rpm value is green. Main screen in case of dual system Beware that the values indicated can be different for Port and Starboard system! Control lever calibration with GD3 is disabled in case of dual system (it is only possible via CAN Term)!

  • Page 33: Error / Warning Window Container

    9.13 Error / Warning window container In case of malfunctions, either faulty or dangerous operation, the Error container or Warning container is shown on your GD3. A warning ( ) or error ( ) indicator is shown in the bottom of the container (in place of the battery symbol), which remains active for as long as the error/warning is active.

  • Page 34: Display - List Of Errors

    GD3 Display User’s Manual Example of Error/Warning container data – Temperature high Read the Error and Warning messages on the display carefully. The result of disregarding them can result in serious damage and injuries! By closing the Error/Warning message you confirm that you read and understood its contents.
  • Page 35 GD3 Display User’s Manual Cause / Checking / Error code Description Description (DE) Correction Check the control lever. Potentiometer error Gashebel-Fehler im ERR_SAC_005 Drive to the shore. Contact during operation Betrieb your distributor. Gashebel nicht in Check the control lever.
  • Page 36 GD3 Display User’s Manual Cause / Checking / Error code Description Description (DE) Correction The motor has stalled. Check if the propeller is out ERR_SAC_023 Stall detected Motorstillstand of water. If the message reoccurs, contact your distributor. Motor speed has been exceeded.
  • Page 37 GD3 Display User’s Manual Cause / Checking / Error code Description Description (DE) Correction driving until it gets warmer. If error persists, contact your distributor. Low battery (state of Zustand der ERR_BMS_70 SOC low : error charge). Charge the Bateriekapazität niedrig battery.
  • Page 38 GD3 Display User’s Manual Cause / Checking / Error code Description Description (DE) Correction Voltage measurement Battery voltage Fehler bei der Messung ERR_BMS_92 error. Contact your measurement error der Batteriespannung distributor. A system reset occurred. If ERR_BMS_93 System reset Systemreset the error persists, contact your distributor.
  • Page 39 GD3 Display User’s Manual Cause / Checking / Error code Description Description (DE) Correction the problem persists, contact your distributor. Faulty data in the control Faulty parameters in Falsche Parameter im ERR_KOP_109 system. Contact your EEPROM EEPROM distributor. Faulty data in the control...
  • Page 40 GD3 Display User’s Manual Cause / Checking / Error code Description Description (DE) Correction Motor power needs to be Reduzierung der ERR_ECU_06 Reducing motor power reduced. Reduce the Motorleistung power. Check the cables. If the Communication Kommunikation PIKBAT1 ERR_ECU_08 problem persists, contact...

  • Page 41: Display - List Of Warnings

    GD3 Display User’s Manual Never try to repair your devices by yourself. There is nothing you can do in most cases. Contact your distributor in a case of error! 9.15 Display – list of warnings The list of warnings that can occur in the Warning container is given below, together with the possible cause and the actions to check or correct them.
  • Page 42 GD3 Display User’s Manual Cause / Checking / Warning code Description Beschreibung (DE) Correction Check the cables. If the WARN_BMS_16 Block voltage too high Blockspannung zu hoch problem persists, contact the distributor. Check the cables. If the WARN_BMS_17 Block voltage too low...
  • Page 43 GD3 Display User’s Manual Cause / Checking / Warning code Description Beschreibung (DE) Correction BMS does not allow BMS does not allow WAR_KOP_52 BMS erlaubt keine Ladung charging. Contact the charging distributor. Battery not connected Batterie nicht angeklemmt Check the cables. If the...

  • Page 44: Contained In The Box

    • User’s manual. 11 Maintenance Always take proper care of your GD3 and consider the deterioration that will occur over time and as a result of heavy use or misuse. Wash the device with water or mild solution of soap. Do not use abrasive equipment or aggressive liquids (e.g.

  • Page 45: Warnings

    Examine carefully and clean the connectors (sockets-inlets) before connecting the supply. Fuses The fuse in the GD3 is not sufficient protection for the boat electronics. An appropriate fuse must be installed in the immediate vicinity of the battery terminal.

  • Page 46: History

    28.11.2022 DK, MR Corrections and suggestions by Daniela Kopriva included. 29.11.2022 DK, MR Minor corrections by Daniela Kopriva (GPS) included. Included new figure “Dimensions of the GD3 (for montage)” 7.12.2022 MR, JK 14.12.2022 MR, MA Included photo of GPS antenna MŠ...
  • Page 47 GD3 Display User’s Manual Address: Piktronik d.o.o. Cesta k Tamu 17 SI-2000 Maribor Slovenia Phone: +386-2-460-2250 Internet: http://www.piktronik.com E-mail: info@piktronik.com...
