- Page 1 QUANTUM PRO Photocatalytic Pool Sanitiser Installation & Operating Manual QP-65 QP-130...
-
Page 2: Table Of Contents
CONTENTS IMPORTANT SAFETY INSTRUCTIONS ................... 3 PRODUCT OVERVIEW ........................3 GENERAL INSTALLATION INSTRUCTION ..................4 3.1 Mounting instructions ........................4 3.2 Pipe work ............................5 3.3 Flow direction ..........................6 3.4 Connection ............................. 8 3.5 Electrical connection ........................9 OPERATING INSTRUCTIONS ......................9 4.1 Flow requirements .......................... -
Page 3: Important Safety Instructions
Introduction Thank you for purchasing the Quantum pool sanitising system, the latest sanitisation technology, manufactured to the highest standards in England. To ensure years of trouble-free service, please read and follow these instructions for proper installation, maintenance and use. Incorrect installation will affect your warranty. Please retain this manual for future reference. -
Page 4: General Installation Instruction
Dimensions: 3. GENERAL INSTALLATION INSTRUCTION 3.1 Mounting instructions The Quantum should be either installed horizontally or vertically allowing enough space for the pipe connections, wiring and maintenance of lamps/quartz sleeve. It should be firmly secured, using the fixing kit provided, to a solid wall. NOTE: When mounting the UV, it is essential to leave a clearance space of at least 1 metre from one side of the unit to allow access to replace the lamp(s) and/or quartz... -
Page 5: Pipe Work
Fig.3 3.2 Pipe work The Quantum should be placed downstream (after) of any pumps, filters and heating devices but upstream (before) of any chemical dosing or similar water treatment (see Figs. 4 and 5). Fig. 4... -
Page 6: Flow Direction
Fig. 5 3.3 Flow direction The Quantum is factory set to accept input water flow entering on the left and exiting on the right, this can be reversed by rotating the flow switch 180 degrees (i.e. ½ turn - see Fig. 6). - Page 7 Fig. 6 WARNING! The flow switch paddle can be damaged when reversing the flow direction if it is lifted by more than 5mm from its housing and turned with force. If the flow switch has been rotated it is important to ensure that it is finally locked in the correct orientation perpendicular (at right angles) to the flow of water.
-
Page 8: Connection
3.4 Connection The unit is supplied with unions to allow connection to 2" or 63-mm rigid pipe. Reducers are also supplied to allow connection to 50-mm or 1½" rigid pipe - see Fig 7. For pipework 63-mm or 2” in diameter. For pipework 50-mm or 1½“... -
Page 9: Electrical Connection
3.5 Electrical connection • This device must be installed by a qualified Electrician following the WARNINGS: instructions provided in this manual. The manufacturer will not be liable for any issues caused by poor or improper installation. • Any alterations made to the unit (unless stated) will affect the warranty. This also applies if components are changed for non-standard components acquired anywhere other than direct from the manufacturer. -
Page 10: Lamp Life Indicator + Intelligent Dosing Pump (Digital)
4.3 Lamp life indicator + intelligent dosing pump (Digital) How to connect the suction tube to the dosing pump: This is how the completed assembly will look. STEP ONE Components required. STEP TWO Unscrew securing cap anti-clockwise. STEP THREE Thread tube through the securing cap (1) and component (2), then push the pipe onto component (3) - Page 11 STEP FOUR Once all components are looped through the tubing tighten securing cap. STEP FIVE Lastly unscrew the retaining gland and insert tube over the connection point. Tighten the retaining gland Place the Foot Valve Strainer into the chemical container. The language menu is displayed on each power up of the unit.
- Page 12 • No or low water flow (the UV lamp(s) cannot be switched on unless the unit is receiving sufficient flow) See page 9 for flow requirements. UV Lamp Life Whenever the UV lamp is ‘On’ a timer counts down from 14,000 hours and the remaining UV lamp life is displayed.
- Page 13 • Once the desired time has been selected press the ‘O.K.’ button and the display will then show ‘SAVED’. • If the dosing volume is set to 0.0 (ml) the peristaltic pump will remain off. • In the event of power loss: the programmed settings (dosing volume and dosing time) will remain stored.
-
Page 14: Maintenance
• The time must be entered in the 24-Hour format and the dosing will take place at this time every day (24-Hours). • The time selected must be at a time when the main filtration pump will be running. • It is recommended to keep the dosage volumes in equal halves, however should you need to adjust to have a larger proportion during the CL 1 or CL 2 periods then this can be programmed accordingly, if you only wish to use one of the dosing periods then this is also... -
Page 15: Essential Parts To Carry Out Annual Maintenance Including Our Reference Codes
• Changing of lamps(s) if necessary. Fig. 8. • Inspection and cleaning of quartz sleeve. Replace if any cracks are discovered. Fig. 9. • Replacing all O-rings. Fig. 10. • Replacing lamp connectors (white plastic insert inside the blue bulb cap) if corroded, wet, damaged or overheated. - Page 16 Unclamping the clip from body 1. Pull the clip in shown direction to Unscrew all the highlighted fasteners unlock from body 2. Pull the second side after unlocking the 1 side Remove Lamp holder Clip from Hard Unmount the Hard cap from Blue lamp Holder Gently slide the lamp out ensuring that no Carefully remove the blue lamp holder pressure is applied to the glass quartz sleeve...
- Page 17 Unscrew the blue quartz sleeve Slide the O-ring off the quartz sleeve locking nut anticlockwise. Both ends must be unscrewed before the quartz sleeve can be removed The quartz sleeve can now be removed. Cleaning the quartz sleeve Clean the sleeve and polish with a soft cloth or paper towel. If you live in a hard water area there may be some limescale on the quartz sleeve.
-
Page 18: Intelligent Dosing Pump Routine Maintenance
NOTE: Pinch the blue lamp holder shroud as you reassemble the unit to release any trapped air. Failure to release the trapped air may cause the lamp holder to disconnect from the lamp end. Turn on the water supply to check for leaks before reconnecting the electric supply. -
Page 19: Disposal Of Electrical/Electronic Equipment
STEP THREE Cut the two black securing ties at either end of the tube. This will then release the tube, which can be discarded. STEP FOUR Take replacement tube re-attach connection points. Loop securing ties in place in order to seal to the connection points. Once securely in place cut the excess tie and dispose of. -
Page 20: Warranty
7. WARRANTY This product is guaranteed from the date of purchase against faulty workmanship and materials for: – two years within Europe – one year outside Europe • The manufacturer will replace or repair, at its discretion, any faulty units or components returned to the Company for inspection •... - Page 21 Irregular Shapes For irregular shapes, calculating the area is less accurate. You will need to draw the pool accurately to scale on graph paper using one square on the graph paper to represent a metre (or foot) square of pool. When you have completed, count the squares.
- Page 22 Notes: ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ……………………………………………………………………………………………….
- Page 23 Elecro Engineering Ltd Repairs Department Unit 11 Gunnels Wood Park Gunnels Wood Road Stevenage Hertfordshire SG1 2BH United Kingdom __________________________________________________________________________________ Customer Information: (ATTACH TO THE PRODUCT) ………………………………………………………………………………. Company Name: ………………………………………………………………………………. Contact Name: Daytime Telephone Number: ………………………………………………………………………………. ……………………………………………………………………………….. Email Address: ………………………………………………………………………………..
- Page 24 Unit 11, Gunnels Wood Park, Stevenage, Herts SG1 2BH Sales@elecro.co.uk www.elecro.co.uk +44 (0) 1438 749474 © Copyright MANE166QP-EN-QUANTUM PRO Manual V2-31.12.2021-Elecro...
