- Page 1 OPERATING MANUAL STARK ..········ ....Indoor Wireless Acousto-Optlc Siren ST-6108W • This product is a networking accessory that needs to be used with the company's gateway...
- Page 3 > Brief Introduction The indoor wireless acousto-optic siren adopts 8 bit MCU as processing core, built-in 16 two-color LED lights and 1 high-decibel buzzer. It can be used as a standalone on-site alarm host. It is widely used in banks, shops, villas, etc. There are high-decibel sound output and flashing highlight when alamiing, causing the intruder to flee the scene in a panic, strengthening alarm deterrence and improving the safety of the protection environment.
- Page 4 > Siren Features ·2 colors of alarm indicator lights ·A strong deterrence with high-decibel alarm sound and flashing highlight ·Pair up with 16 remote controllers ·Pair up with 32 detectors (normal and doorbell zone) ·Pair up with 32 detectors (emergency zone) ·Adjustable light brightness on standby status ·Arm delay 30 seconds >...
-
Page 5: Remote Controller Diagram
> Remote Controller Diagram > Setu p 1.Remote Controller 1.1 Enroll Remote Controller On standby status, long press [setting) button for 3 seconds. When you hear one short •oi• along with the first group red lights on, it means entering the enrollment of first remote controller. The light flashes if the current one has not been enrolled, and then you can press any button on the remote controller to enroll. - Page 6 (If you want to delete the current one, please follow 1.2 Delete Remote Controller below). Short press [+] or [-] button to shift to the next/previous remote controller. 1.2 Delete Remote Controller If the current remote controller has already been enrolled and the light is long bright, long press[+] or (-1 button for 3 seconds.
- Page 7 2.2 Delete Detector If the current detector has already been enrolled and the light is long bright, long press (+) or [-I button for 3 seconds. When you hear two short ·Di. and the light turns to flash, it means that the deletion is successful.
- Page 8 and you can see the sensor's red light on to transmit a signal. Enroll successfully if you hear one short "Di• and meanwhile the light turns to be long bright. Notice: If you hear five short "Di•, it means that the detector has already been enrolled.
- Page 9 5.Alarm Volume On alarm time setup status, short press [setting) button once. When you hear one short "Di" along with the second group blue lights on, it means entering alarm volume setup status. Short press (+)or[-) button to set alarm volume. Light flashes quickly means that alarm volume is high, light flashes slowly means that alarm volume is low and long bright light means mute mode.
- Page 10 Instructions > Standby Light Prompt On standby status, short press siren's [setting] button twice continuously. When you hear two short �Di", it means opening or closing standby light prompt function. It is red light when press [arm) button on remote controller, blue light when press [disarm) button on remote controller and purple light when press [doorbell) button on remote controller.
- Page 11 Door/Window Detection Under anning status, the siren goes off immediately when sensor and magnet are separated, thus to prevent intruders attempting to infiltrate through doors, windows, etc. Alarming (Normal Alarming(Tamper Alarming/SOS Alarming) When detector is triggered, siren's red or blue light flashes quickly along with alarm sound of the buzzer.
- Page 12 Spaclng<lOmm Notice: 1.Door/Wlndow Type Avoid installing detector on objects with a lot of metal and wire. 2.lnstallatlon Method Suitable for a variety of installation methods. Please do a test before install sensor and magnet to ensure nonnal working of detector after installed them.
-
Page 13: Technical Parameter
siren goes off immediately. Notice: the detector's red light on only when operate both ·press down• and ·pull out" actions. Only "press down• action or only •release• action will not make detector's red light on. When testing detector's installation position, please avoid triggering tamper alarm and anti-moving alarm. -
Page 14: Maintenance
Standby Time: 3 years (always power on and operate 10 times everyday) 3.Ramota Controller Working Voltage: DV 3V (1'CR2032 Battery) Standby Current: <1uA Alarm Current: <20mA Wireless Frequency: 433.92MHz Wireless Transmitting Range: 100M (Open Area) ° ° Operating Temperature: -10 C-+60 Operating Humidity: <80% (without condensation) Housing Material: ABS Flame-resistant Material... - Page 15 Please replace the battery in time. 2.Remote Controller The reasons that remote controller can't work normally: 1/ It doesn't enroll successfully. Please enroll it. If it has already been enrolled, please operate the next step. 2/ It appears battery low power. Please replace the battery. -13-...
- Page 16 Indoor Wireless Acousto-Optic Siren User Manual Vl.0-20210126...
