Medifab Sharky Conversion Manual

Sharky Base

Size 1 to Size 2

Conversion Manual

You will need the following tools

and parts for this procedure:

•

1x Tilting Unit Sharky size 2 (Medifab code needed)

Hoggi code: 3402-1300E-022

Medifab code: 6082-0015-000

•

1x Sharky shower and toilet seat unit, size 2

Medifab code: 6082-0015-000

6x M6 x 28mm countersunk bolts.

•

Hoggi code:

Medifab code:

Table of Contents

Need help?

Do you have a question about the Sharky and is the answer not in the manual?

Page 1 Size 1 to Size 2 Conversion Manual You will need the following tools and parts for this procedure: • 1x Tilting Unit Sharky size 2 (Medifab code needed) Hoggi code: 3402-1300E-022 Medifab code: 6082-0015-000 • 1x Sharky shower and toilet seat unit, size 2 Medifab code: 6082-0015-000 6x M6 x 28mm countersunk bolts.
Page 2 Removing the Seat Unit Step 1: Start by removing the seat unit from your size 1 Sharky, release the seat unit by pressing down the red levers at the front on each side. Tilt the seat unit back and lift to remove.
Page 3 2 unit. Place these aside. The above image shows the original parts needed to refit to the size 1 Sharky base to convert it to a size 2, along with the new size 2 tilt mechanism and the 6x M6 x 28mm bolts.
Page 4 Now fit the original long bolts, washers, and nuts to the tilt mechanism to secure this to the main frame. Tighten the bolts and nuts to be firm, and not over tight which may impede the tilting mechanism. medifab.com solutions@medifab.com...
Page 5 Check the tilting mechanism slides smoothly and the locking pins engage in every position. If the guide plates bind you need to add a washer between the plate and the frame. This completes the procedure, and you can now fit the size 2 seat unit to the base frame. medifab.com solutions@medifab.com...
Page 6 32 Detroit Drive Rolleston 7675 New Zealand 0800 543 343 (NZ) solutions@medifab.com medifab.co.nz medifab.com solutions@medifab.com...
