- Page 1 ADA-7200 User manual ADA-7200 Multidrop Fiber Optic Repeater Copyright © 2001-2020 CEL-MAR sp.j. io_ada-7200_v3.17_en...
- Page 2 ADA-7200 Contents 1. GENERAL INFORMATION..................................3 1.1. WARRANTED INFORMATION............................... 3 1.2. GENERAL CONDITIONS FOR SAFE USE............................ 3 1.3. CE LABEL....................................... 3 1.4. ENVIRONMENTAL PRESERVATION............................3 1.5. SERVICE AND MAINTENANCE..............................3 1.6. PACK CONTENTS..................................3 2. PRODUCT INFORMATION..................................3 2.1. PROPERTIES....................................3 2.2.
- Page 3 1.1. WARRANTED INFORMATION ADA-7200 repeater is covered by a two year warranty from date of sale. In case of being damaged it will be repair or the damaged component will be replace. The warranty does not cover damage caused from improper use, materials consumption or any unauthorized changes.
- Page 4 2.2. DESCRIPTION Fiber Optic ADA-7200 repeater is a device that allows for extension of fiber optic networks to connect devices in places far away from each other such as halls, buildings and other objects. Optic signal regeneration there is without interference of data format. The use of fiber optics provides complete isolation between connected devices and resistance to interference on the transmission bus.
- Page 5 ADA-7200 3. INSTALLATION This chapter will show how to connect ADA-7200 to Fibre-Optic and power supply and how to use it. 3.1. CONNECTION FIBRE-OPTIC BUS The multimode Fibre-Optic with connectors type: ST®, SC or SMA, connect into their corresponding converter's connectors type: ST®, SC or SMA like on the figure below.
- Page 6 Power Supply ADA-7240 RS485 connector connector TX+/A TX-/B V (-) V (+) Power Supply ADA-7020 Controller Current loop Current loop connector connector Conn. V (-) V (-) V (+) V (+) Fig. 4. Example connection of ADA-7200 to fiber optic bus...
- Page 7 3.4. POWER SUPPLY CONNECTION The power supply to the ADA-7200 repeater should be DC (regulated) from 10 V= to 30V=. Nominal power is typically 3W, e.g. ZS- 12/250 or DR-15-24. Power cable from DC power supplies to device must not be longer than 3m.
- Page 8 Thank you for purchasing CEL-MAR Company products. We hope that this user manual helped connect and start up ADA-7200 repeater. We also wish to inform you that we are a manufacturer of the widest selections of data communications products in the world such as: data transmission converters with interface RS232, RS485, RS422, USB, Current Loop, Fibre-Optic Converters and Ethernet or Wi-Fi.
