- Page 1 User Manual HC Series Precision Balance Scan for video and FAQ's.
-
Page 2: Table Of Contents
Table of Contents Important Safety Information Operating Guidelines Installation and Use Location Product Specifications Display Controls Packing List Unpacking Installation Getting Started Calibration Zero Tare 7 - 8 Linear Calibration Unit Conversion Counting Function Overload Warning RS232 Printout Settings Cleaning Troubleshooting Factory Testing... -
Page 3: Important
Important Thank you for purchasing the Fristaden Lab Precision Balance. To ensure safe and reliable operation, please read the user manual carefully before use and follow all operating and safety instructions. Safety Information Use only 110V power supply. Disconnect the balance from the power supply when installing or moving the balance. -
Page 4: Product Specifications
Product Specifications HC Series Model 7.7” x 7.7” (195mm x 195mm) Pan size 110V Power supply Display g, ct, kg, oz, t, dwt, ozt Units of measurement 5 seconds Stabilization time Weighing/Tare/Counting/Printing Functions Strain gauge Sensor ABS body, stainless steel weighing pan... -
Page 5: Packing List
Button Short Press vs. Long Press Action Long press - Used to calibrate scale (CAL) CAL/PCS Short press/Long Press Short press – Used for counting function (PCS) Changes the unit between g, ct, oz, kg, oz, t, UNIT Short press dwt, ozt TARE Short press... -
Page 6: Getting Started
Getting Started Ensure the balance is level. The supports on the bottom of the balance can be screwed in or out as needed to level the instrument. Press the ON/OFF button to turn the balance on. When turning on, the display will fully illuminate for approximately 1.5 seconds. The balance will display numbers 1 through 9. -
Page 7: Linear Calibration
Linear Calibration IIn order to ensure the accuracy of the balance, it should be calibrated regularly and frequently. For routine calibration, the balance is normally calibrated to a single point. However, if the balance starts to experience inaccuracies, the balance requires linear calibration to remedy the issue. -
Page 8: Tare
Note: If you are conducting a 3-, 4-, or 5-point calibration, there is no need to press the TARE key in Step 7 above. You would instead follow this procedure: 1.Turn on the scale 2.Press the TARE key twice and the CAL/PCS key once immediately after. The display will show “-diu”... -
Page 9: Counting Function
Counting Function The counting function is used to count the number of parts by extrapolating values from the original sample. Press TARE. Press and hold the CAL/PCS key. The balance will cycle through 10, 20, 50, and 100. Press the CAL/PCS when the number corresponds to the number of objects you will place in the pan. -
Page 10: Cleaning
RS232 Output Parameter Settings Turn on the power. Press the TARE key twice, and press the CAL/PCS key once. When the display shows “01-dlU,” press the UNIT button until “08-bud” is displayed. Press the TARE button. If “9600” is not displayed, press the UNIT button until “9600”... -
Page 11: Troubleshooting
Troubleshooting Problem Cause Solution Damage or defects in The balance Replace the power cord. the power cord does not power up / display does One or both ends of the power cord not Ensure both ends of the power cord are securely connected. illuminate. -
Page 12: Factory Testing
Factory Testing Your balance has undergone extensive quality control (QC) testing at the laboratory prior to shipment. The following QC tests have been conducted: Margin of Error Testing is performed to verify that the margin of error is less than .03g for a .01g balance.
