Summary of Contents for fristadenlab Fristaden Lab Counting Scale
- Page 1 User Manual Counting Scale Scan for video and FAQ's.
- Page 2 Quick Start Guide Change Units (g, kg, oz, lb) Press and hold MC or UNITS for 3 seconds.* *Depending on the model. Counting Function Add at least 10 units to the pan. Enter the number of pieces placed on the pan on keypad. The number will be displayed next to 'g'.
-
Page 3: Table Of Contents
Table of Contents Important Safety Information Operating Guidelines Installation and Use Location Product Specifications Display Controls Packing List Unpacking Installation Getting Started Calibration Zero Unit Conversion Tare Counting Function Accumulation Function Checkweighing/Alarm LP50 Print Mode Setting RS232 Printout Settings Using ComTools RS232 Printout Parameter Setting Steps Adjusting Baud Rate... -
Page 4: Important
Important Thank you for purchasing the FRISTADEN LAB Counting Scale. To ensure safe and reliable operation, please read the user manual carefully before use and follow all operating and safety instructions. Safety Information The counting scale can be used with 110-240V. -
Page 5: Product Specifications
Product Specifications Fristaden Lab Counting Scale Model 10.8” x 9” (275mm x 230mm) Pan size 110-240V Power supply Display g, kg, oz, lb Units of measurement 5 seconds Stabilization time Weighing/Counting/Zero/Tare/Print Functions Load cell Sensor ABS body, stainless steel double-layer weighing pan... -
Page 6: Controls
Controls Button Short Press vs. Long Press Action POWER Short press Turns balance on or off Button Short Press vs. Long Press Action Numeric keys that are used for setting numeric Short press data such as sample number, sample weight, or limit number Used as: (1) decimal point, or (2) Press and hold •... -
Page 7: Packing List
Packing List Fristaden Lab Counting Scale Weighing pan Power cord User manual Unpacking After unpacking, please check the contents to ensure all of the components are present and there is no damage. If parts are missing or damaged, please contact customer support. -
Page 8: Zero
Zero Short press the ZERO button before weighing to ensure an accurate reading, (starting from 0). Unit Conversion Press and hold the MC button for 3 seconds to switch between the available units of measurement, (g, kg, oz, lb). Tare Place an empty container on the pan. -
Page 9: Accumulation Function
Accumulation Function Use M+ to find the cumulative weight and piece count of samples. For example, place a sample of 100 pcs (2kg) on the scale. Press M+ and remove the sample. Add 50 pcs (1kg), weigh, and remove. Press M+ and the total count (150 pcs) and weight (3kg) will be displayed. -
Page 10: Lp50 Print Mode Setting
General Print Mode Setting Choose between manual, stable and continuous print modes. Press 7, 8, 9 using the number keys. The display will cycle and then will show “diu.” Press the PCS/SET key until the display shows “bud”. If “9600” is not displayed, press the PCS/SET key until it is. Press Alarm to confirm. -
Page 11: Adjusting Baud Rate
Adjusting the Baud Rate The baud rate is the rate of data transfer to the PC. It indicates how many bits per second can be transferred. The default baud rate for the balance is 9600. The baud rate settings for the balance and receiving PC must match. To adjust the baud rate: Press 7, 8, 9 using the number keypad. -
Page 12: Troubleshooting
Troubleshooting Problem Cause Solution Damage or defects in The balance Replace the power cord. the power cord does not power up / display does One or both ends of the power cord not Ensure both ends of the power cord are securely connected. illuminate. -
Page 13: Factory Testing
Factory Testing Your balance has undergone extensive quality control (QC) testing at the laboratory prior to shipment. The following QC tests have been conducted: Margin of Error Testing is performed to verify that the margin of error is less than .03g for a .01g balance. -
Page 14: Company Information
Our products solve real problems for those involved in quality control, research and development, inventory management and a myriad of other applications. Contact Us Website: FristadenLab.com Customer Support: support@fristadenllc.com Owned and operated by: Fristaden & Company LLC Address: 401 Ryland Street, Suite 200-A, Reno, NV 89502 (USA)
