Venturer CR8030i - Dual Alarm Clock Radio For IPod User Guide
![]()
ACCESSORIES
Please check and identify the included accessories.
- AC Adapter x 1
- iPod Dock Adaptor x 4
- Blue sleeve x 1, pink sleeve x 1, green sleeve x 1 & silver sleeve x 1
LOCATION OF CONTROLS
Front view
![Venturer - CR8030i - Front view Front view]()
- ALARM1
button - iPod Door
- iPod dock
- Function/
Clock button - STANDBY/ON
/
button - MEMORY/
PAUSE button - Left Speaker
- ALARM2
button - HOUR
SKIP/TUNING
button
Rear view
![Venturer - CR8030i - Rear view Rear view]()
- PRESET/SNOOZE button
- SKIP/TUNING
MIN
button - SLEEP
button - - VOLUME + button
- Right speaker
- LCD Display
- Earphone jack
- AUX IN jack
- DC IN jack
POWER SUPPLY
![Venturer - CR8030i - POWER SUPPLY POWER SUPPLY]()
Using an AC adapter other than the one supplied with the unit may damage the unit. This AC adapter operates on AC 100-240V~50/60Hz.
![]()
- Before use, make sure the rated voltage of the adapter matches your local voltage.
- The included AC adapter is for use with this unit only. Do not use it with other equipment.
- If you are not going to use the unit for a long time, disconnect the AC adapter from the wall outlet.
- Whenever the AC adapter is plugged in to a wall outlet, electricity is running through the unit, even when the power button on the unit is turned off.
POWER BACK-UP DURING POWER INTERRUPTION
![]()
Open the battery door at the bottom of the unit and insert two "1.5V UM3/AA size" batteries into the battery compartment. Be sure to install two optional "1.5V UM3/AA size" batteries for the power back-up function. If the AC power supply is interrupted, the batteries supply power to keep the clock operating and the alarm times set.
- During power interruption, the clock function is still maintained. The alarm sound will not come on.
- These batteries are for clock operation and alarm memory during power interruption. You can not listen to the radio/iPod/AUX with the batteries.
WHEN TO REPLACE THE BATTERIES
To check the batteries' condition, unplug the AC adapter from the wall outlet and plug it in again after a few minutes. If the displayed time is incorrect, replace the batteries with new ones.
![]()
- Danger of explosion if batteries are incorrectly replaced. Replace only with the same or equivalent type.
- Be sure to install the batteries before unplugging the AC adapter.
- When the unit is going to be left unplugged for a long time, remove the batteries to avoid undue battery discharge and unit damage from battery leakage.
- Do not dispose of battery in a fire; battery may explode or leak.
![]()
When discarding batteries, environmental problems must be considered and local rules or laws governing the disposal of these batteries must be strictly followed.
VOLUME ADJUSTMENT
TO ADJUST THE VOLUME
Adjust the VOLUME control to obtain the desired volume.
FOR PERSONAL LISTENING
Connect headphones (Ø3.5mm stereo mini plug) to the earphone jack. Adjust the VOLUME control to obtain the desired volume.
When headphones are connected, the speakers are automatically disconnected.
![]()
Excessive sound pressure from earphone and headphones can cause hearing loss, so start playback before putting on the earphones.
CLOCK SETTING
Setting the clock can only be done in STANDBY mode.
TIME DISPLAY INDICATOR
![]()
- Press the FUNCTION/
button, the hour and minute digits blink. - Press and hold MEMORY/
button for 1~3 seconds to choose 24hrs or 12hrs time display. - Press the HOUR/
button to adjust the hour digits.
![]()
- Press the MIN/
button to adjust the desired minutes then press the FUNCTION/
button once to confirm.
![]()
- In 12hrs time display, 12:00 PM=Noon. In 12hr mode, 'PM' is displayed between 12 noon and midnight.
![]()
Note: In RADIO/iPod/AUX IN mode, the current time is always shown on the display.
LISTENING TO THE RADIO
![]()
- Press the STANDBY/ON
/
button to turn the unit on. - Press the FUNCTION/
button to FM or AM band. - Press the
or
button to tune in to a station.
- Adjust the volume control to obtain the desired volume.
Searching for a Station Automatically
- Press and hold the
or
button until the tuner starts searching for a station, then release. After finding a clear station, the search stops automatically.
Note: The search may not stop at a station with a very weak signal.
Presetting Stations
The unit can store a total of 20 stations in memory (10 X FM, 10 X AM). Presetting allows you to tune in to a station directly.
- Tune in to a desired station(see previous section).
- Press and hold the MEMORY/
button. The preset number and the "MEM" indicator will blink on the display. - Press
or
button to select the preset number. - Press the MEMORY/
button again to store it in memory. - Repeat steps 1-4 to store other stations.
Tuning in to a Preset Station
Press the PRESET/SNOOZE button, and the preset number will show, then press the
or
button to select a preset number.
For Better Reception
FM: Place the unit in the position that sounds best.
Note: When the reception is good, the "STEREO" indicator will appear on the display. AM: Reposition the unit to get better AM reception.
Note: To prevent interference to the AM signal, please keep a certain distance (the AC adapter cable' length) away from the main unit.
LISTENING TO YOUR iPod
iPod Compatibility
The unit works with iPod mini (4GB, 6GB), iPod nano (1st generation) - 1GB, 2GB, 4GB, iPod 5th generation (video) - 30GB, 60GB, 80GB, iPod nano (2nd generation) - 2GB, 4GB, 8GB, iPod classic (80GB, 160GB), iPod nano 3rd generation (video) - 4GB, 8GB and iPod touch (8GB, 16GB, 32GB). Other iPod models are supported through the AUX IN jack on the unit's front panel (see "AUX IN CONNECTION" section).
iPod Dock Adaptor
Before connecting your iPod, you need to install the appropriate iPod Dock Adaptor in the dock of the unit. Four iPod Dock Adapters are included as shown below (if the adapter is not included, please use the adaptor that came with your Pod.):
iPod Adaptor No. | iPod Description | Capacity |
9 | iPod 5th generation (video) iPod classic | 30GB 80GB |
10 | iPod 5th generation (video) iPod classic | 60GB, 80GB 160GB |
13 | iPod nano 3rd generation (video) | 4GB, 8GB |
14 | iPod touch | 8GB, 16GB, 32GB |
Installing the iPod Dock Adapter
- Choose the iPod Dock Adapter that fits your iPod (if the adapter is not included, please use the adaptor that came with your iPod).
- Lift up the iPod Dock flap door to approximately 90 o.
![]()
- Insert your iPod Dock Adapter into the dock until it sits firmly in place.
![Venturer - CR8030i - Insert your iPod Dock Adapter into the dock. Insert your iPod Dock Adapter into the dock.]()
Removing the iPod Dock Adapter
![]()
Remove the Dock Adaptor by gripping the inside with your thumb, then lifting out the adaptor using the friction between your thumb and the adaptor.
Inserting Your iPod
![]()
- Ensure the appropriate iPod Docking Adapter is installed.
- Insert your iPod into the connector in the dock.
Start Playback
- Press the STANDBY/ON
/
button to turn on the unit. - Press the FUNCTION /
button repeatedly until the indicator "iPod" appears on the display. - Press the MEMORY/
button to start playing.
Notes:
- The iPod will charge automatically while docked in the cradle(except when you are listening to the radio.).
- To prevent interference to the AM signal, please turn off the iPod while the radio is playing.
Pausing Playback
- Press the MEMORY/
button. - To resume playback, press the MEMORY/
button again.
Skipping to a Another Track
- Press the
button to skip to the beginning of the current track or skip to previous track. Press the
button to skip to the next track.
Locating a Particular Point on a Track
- Keep either the
or
button pressed during playback, according to the desired direction, and release at the desired point.
Note: Please refer to the owner's manual that was supplied with your iPod for more details.
DUAL ALARM SETTING
- The unit should be in STANDBY mode to set alarm.
- The alarm can be set to activate twice a day by setting two different alarm times in ALARM1 and ALARM2.
- The unit can be set to "Buzzer", "Radio" or "iPod" alarm.
TO SET ALARM 1
![Venturer - CR8030i - TO SET ALARM 1 TO SET ALARM 1]()
- Press the
button, the "
" icon blinks on the display. - Press the
button once again, then the "
" icon, hour and minute digits blink on the display. - Press the HOUR/
button to adjust the hours. - Press the MIN/
button to adjust the minutes. - Press the FUNCTION/
button to select "Buzzer", "TUNER", "iPod".
Note: The shown "TUNER" icon presents Radio(FM/AM) mode. - Adjust the volume control to obtain the desired volume for the Alarm1.
- Press the
button again to confirm. - The alarm 1 indicator will light up.
Note: For the "Radio" Alarm, you should tune into your desired radio station before setting alarms- the alarm will turn on to the last station you tuned.
The clock radio will wake up to "Buzzer", "Radio", "iPod", when alarm timer reaches the preset time and then turns off automatically after 60 minutes.
TO SET ALARM 2
Setting the alarm for alarm2 is the same as setting alarm1 (Use the Alarm2 button instead of the Alarm1 button).
Note: If the Alarm1 & Alarm2 are set to the same time, the unit will activate once only.
TO TURN OFF ALARM
- Snooze (If you want to snooze a few more minutes)
Pressing the SNOOZE button will deactivate the sound for 9 minutes. You can repeat this function as many times as you like within 60 minutes from the preset alarm time. - To stop alarm sound
Press the STANDBY/ON
/
button to stop alarm sound, Alarm Mode will stay active-alarm will activate again in 24 hours.
TO CHANGE THE ALARM TIME
Set the alarm time again.
TO CANCEL ALARM MODE
After setting alarms, press and hold the
or
buttons for 2 seconds until the alarm1 or alarm2 indicator disappears.
SLEEP TIMER SETTING
The sleep timer turns the unit off automatically at a pre-selected time.
- While the unit is on, press the SLEEP button-the display will indicate "90".
- Press the SLEEP button repeatedly to select the desired sleep time (in minutes) as listed below:
Note: OFF" means the sleep mode is disabled.
- After setting a desired sleep time, the "
" icon will be shown in the display. - The unit will automatically turn off once it reaches the sleep time.
To clear the preset sleep time press the SLEEP button repeatedly until "
" disappears.
AUX IN CONNECTION
Connecting to AUX IN for Other Sound Sources
You can connect audio devices such as your iPod, CD players or MP3 players to the unit through the AUX IN jack. Use a standard 3.5mm-to-3.5mm audio cable (not supplied), connect the AUX IN jack on the back panel of this unit to the Line Out or Earphone jack of the other audio device.
Listening to the Connected Device
- Press the FUNCTION /
button to AUX IN mode and "AUX" is shown on the display. - Turn on the audio device you've attached to the AUX IN jack.
REPLACING COLOR SLEEVE
If you want to change your TOP CABINET color, use a new color sleeve to help you. Choose your desired color sleeve, then follow the below steps to replace it.
![Venturer - CR8030i - REPLACING COLOR SLEEVE REPLACING COLOR SLEEVE]()
STEP-1 | STEP-2 | STEP-3 |
Peel off the sheet from the color sleeve. ![]() | Align the centre window in the color sleeve with the unit's display window, then allow the sleeve to stick to the unit. ![]() | Align each edge of sheet, make sure it fits well with the unit's casing. ![]() |
NOTES:
- Before adding a new sleeve, please peel off the old sheet from the unit.
- The sleeves will not leave residue on the unit, so if you make a mistake, just carefully lift a corner, peel off and try again.
- Blue, pink, green, and silver sleeves are included in accessories.
MAINTENANCE
Cleaning the Unit
- Be sure to turn off the unit, disconnect the power adapter and remove all external connections before cleaning the unit.
- Wipe the unit with a dry soft cloth. If the surfaces are extremely dirty, wipe clean with a cloth that has been dipped in a weak soap-and-water solution and wrung out thoroughly, then wipe with a dry cloth.
- Never use alcohol, benzene, thinner, cleaning fluid or other chemicals. Do NOT use compressed air to remove dust.
TROUBLESHOOTING GUIDE
Problems | Solutions |
Clock Clock does not show the correct time. Alarm does not come on at the preset time. | - There has been an electrical power interruption. Reset the clock.
- Is the current time correctly set on the time display?
- Is the alarm time correctly set?
|
RADIO Poor FM reception Poor AM reception | - Electrical devices in your home can cause poor reception. Move the unit away from them (especially those with motors and transformers).
- Rotate the unit horizontally.
|
iPod iPod does not dock properly or does not install properly. iPod does not respond to the speaker system. | - Remove your iPod from the dock and check for obstruction on the connectors in the dock and on your iPod. Make sure you are using the appropriate adaptor for your model of iPod.
- Make sure that your iPod is working properly before docking into the unit. Please refer to your iPod manual for details.
|
SPECIFICATIONS
DC: 12V
1.25A EXTERNAL DC SUPPLY
BACKUP BATTERIES FOR CLOCK: 2x1.5V UM-3 OR AA SIZE
RADIO FREQUENCY:
AM 520 ~ 1710KHz
FM 87.5 ~ 108.0MHz
SAFETY PRECAUTIONS
![]()
The marking information is located at the bottom of the apparatus.
![]()
- The AC adaptor is used as disconnect device and it should remain readily operable during intended used. In order to disconnect the apparatus from the mains completely, the AC adaptor should be disconnected from the mains socket outlet completely.
- Minimum 10 cm (4 inches) distances around the apparatus for sufficient ventilation.
- Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
- The ventilation should not be impeded by covering the ventilation openings with items such as newspaper, table-cloths, curtains, etc.
- No naked flame sources such as lighted candles should be placed on the apparatus.
- The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on apparatus.
On Operation
Do not turn up the volume while listening to your iPod with no audio signals or very low level inputs. If you do so, the speakers may be damaged when the peak level of the sound is played.
On Use
Use the unit in moderate climates. Never use the unit where it would be subject to:
- Heat sources such as radiators or air ducts.
- Direct sunlight.
- Excessive dust.
- Moisture or rain.
- Mechanical vibration or shock.
- Uneven surface.
- Do not place any heavy objects on top of the unit.
- When the unit is used with an AC power adapter, do not wrap the unit in a cloth, blanket, etc.. If you do so, the temperature inside and outside the unit may rise considerably, resulting in malfunctioning of the unit.
- If the unit is brought directly from a cold to a warm location, or is placed in a very damp room, the moisture may condense on the lens inside the unit. Should this occur, the unit will not operate. In this case, remove the disc and leave the unit in a warm place for several hours until the moisture evaporates.
- For the unit to operate at its best, it should not be subject to temperatures below 41°F (5°C) or above 95°F (35°C).
LIMITED WARRANTY
To obtain warranty service in the Untied States, you must first call our Customer Support Center at
1- 866 - 444 - 6478,
1- 800 - 252 - 6123, during the hours listed in the box below.
In the event your product requires repair after the limited warranty period has expired, please contact our Customer Support Center at
1- 866 - 444 - 6478,
1- 800 - 252 - 6123
Hours: Monday-Thursday: 9-7, Friday: 9-5, Saturday: 9-12 EST
or www.venturer.com
For more information on other products and services, please visit our web site at: www.venturer.com
![]()
