Page 1
PRINT Installation of Interface RS 232 Interface RS 422 BACK The interface box must include: 1 I/O Module 1 I/O Cover 2 Screws 1 Installation Guide T2240/9 T2240/24 T2340/9 T2340/24 QUIT...
Page 2
Module into the connector of the logic board correctly, it is keyed. - Insert the interface cover delivered with the module. - Switch printer power on („I“). - Select the serial I/O via the menu of the printer. See reference manual. BACK QUIT...
