Qbic Technology TD-0350 - Panel PC Quick Start Guide

Contents

Indication

Device Overview

  1. Reset Button
  2. ADB
  3. DC 5V IN
  4. USB
  5. Speaker
  6. Touch screen
  7. LED indicator light
  8. NFC
  9. Microphone
  10. Bracket

Installation

Cable connection

Step 1
Plug USB cable into USB port
Cable connection - Step 1 - Plug USB cable

Step 2
Fix the screws to secure the USB cables.

Surface Bracket Mount Installation

Step 1
Install the bracket on surface
Screw specifications: KA4*14, diameter: 7 mm
(Screws are not provided)

Step 2
Assemble the panel PC to the bracket

Step 3
Tighten the screws. Locations are shown in above illustration.
Screw specifications: M2*5 (T6)
(screw pack)

Step 4
Cover the screws with rubber caps.

Adhesive Bracket Mount Installation

Step 1
Laminate adhesive to the back of bracket

Step 2
Install the bracket onto the panel PC bracket slot (at the back)

Step 3
Tighten the screws and cover them with rubber caps
Screw specifications: M2*5 (T6)
(screw pack)

Step 4
Peel off the adhesive and attach the panel PC on a smooth and clean surface

* Please install and use this product in strict accordance with the instructions.
Please visit this link for software installation manual.
http://www.qbictechnology.com/support

Qbic Technology Co.,Ltd.
26F-12, No.99.Sec.1, Xintai 5th Rd., Xizhi Dist., New Taipei City 221, Taiwan(R.O.C)
Tel: 886-2-2697-2000 FAX: 886-2-2697-2868
