TWO SPEED PRIMER • EXP8700-2
Installation and Service Manual
Series
Speed
EXP8700-2
High
EXP8700-2
Low
WARNING: Please read completely before you install or operate your new pump! This is an external "out-of-pond" pump!
It is NOT submersible! Do NOT allow this pump to become submerged! Never run dry!
Max. Flow
Inlet
Discharge
(GPH)
2"
2"
8700
2"
2"
4900
Reliability You Can Count On!
EASYPRO TWO SPEED SELF PRIMER
TYPE: SELF PRIMING CENTRIFUGAL
MOTOR: NEMA 56Y
HORSEPOWER: 1/3 (1750 RPM) 2 (3450 RPM)
TWO SPEED PRIMER: 2" FNPT INLET AND DISCHARGE
HARDWARE: STAINLESS STEEL HARDWARE
OPTIONS: SALTWATER SERVICE
Max. Head
Max. Power
(feet)
(watts)
83
2185
21
459
EasyPro
EXP8700-2
S/N: XXXX-XXXXXX
Please fill in for future reference:
MODEL: _____________________________
SERIAL NUMBER: ____________________
DATE PURCHASED: __________________
* Please fill out the warranty registration
card in this manual.
WITH 2" SLIP ADAPTERS
Max Current
Motor
(amps)
HP
Enclosure
9.6 @ 230v
2
3.65 @ 230v
1/3
© 2019 EasyPro, Inc
Motor
ODP
ODP
Pg. 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for EasyPro EXP8700-2 Series
Summary of Contents for EasyPro EXP8700-2 Series
- Page 1 SERIAL NUMBER: ____________________ DATE PURCHASED: __________________ * Please fill out the warranty registration card in this manual. EASYPRO TWO SPEED SELF PRIMER TYPE: SELF PRIMING CENTRIFUGAL MOTOR: NEMA 56Y HORSEPOWER: 1/3 (1750 RPM) 2 (3450 RPM) TWO SPEED PRIMER: 2" FNPT INLET AND DISCHARGE WITH 2"...
- Page 2 To insure proper performance, we urge you to carefully follow the instructions in this manual. If you have any questions, call your nearest distributor or EasyPro for assistance. INSTALLATION Please read carefully! When properly installed this primer pump will provide dependable trouble-free service.
- Page 3 8000.141 9. Remove seal from bracket by pressing out from the back (if replacing the seal). Do not dig out from the front! ADAPTER, UNION X 2” SLIP 8000.780 Reliability You Can Count On! © 2019 EasyPro, Inc Pg. 3...
- Page 4 The exclusive remedies provided hereunder shall, upon EasyPro’s inspection and option, be either repair or replacement of EasyPro shall not be held liable for any loss of fish, plants or any other livestock as a result of any failure or defect of this the Product or parts covered under this warranty.
