USERS MANUAL
RXT- 900 Recumbent Elliptical/Stepper & UBE
Healthcare International, Inc.
PO Box 1509, Langley, WA 98260
www.HCIFitness.com
p.360.321.7090
Exercise can present a health risk. Consult a physician before beginning any exercise program with this
equipment.
If you feel faint or dizzy, immediately discontinue use of this equipment. Serious bodily injury can occur if this
equipment is not assembled and used correctly. Serious bodily injury can also occur if all instructions are not
followed.
Keep children and pets away from equipment when in use. Always make sure all bolts and nuts are tightened
prior to each use. Follow all safety instructions in this manual.
CAUTION: WEIGHT ON THIS PRODUCT SHOULD NOT EXCEED 300LBS.
VERSION: II

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PhysioCycle RXT- 900 and is the answer not in the manual?

Questions and answers

Related Manuals for HealthCare International PhysioCycle RXT- 900

Summary of Contents for HealthCare International PhysioCycle RXT- 900

  • Page 1 USERS MANUAL RXT- 900 Recumbent Elliptical/Stepper & UBE Healthcare International, Inc. PO Box 1509, Langley, WA 98260 www.HCIFitness.com p.360.321.7090 Exercise can present a health risk. Consult a physician before beginning any exercise program with this equipment. If you feel faint or dizzy, immediately discontinue use of this equipment. Serious bodily injury can occur if this equipment is not assembled and used correctly.
  • Page 2 “S AFETY NSTRUCTION” WARNING: To reduce the risk of serious injury, read the following safety instructions before using the 2 in 1 Recumbent Elliptical and Stepper 1. Read all warnings posted on the equipment 2. Read this Owner's Manual and follow it carefully before using the equipment. Make sure that it is properly assembled and tightened before use 3.
  • Page 3 “A SSEMBLY ARTS” Unpack the box in a clear area. Follow the List of Assembly Parts below to check and make sure all assembly parts are present and in good condition. Do not dispose of the packing material until the assembly process is completed. Assembly tools and hardware kit have included for you to use when assembling the product Handlebar Assembly Connection Cover...
  • Page 4 “H ARDWARE DENTIFICATION HART” Unpack the box in a clear area. Follow the List of Hardware Kit below. This chart is provided to help identify the hardware used in the assembly process. Place the washers, the end of bolts, or screws on the circles to check for the correct diameter.
  • Page 5 Q’TY Part No. and Description HARDWARE KIT 58 Screw Cap 2 pcs 121 Lock Washer (M8) 14 pcs 123 Washer (8x16x2.0t) 14 pcs 131 Self-Tapping Screw, Truss Head (M4x20mm) 1 pcs 138 Screw, Round Head (M5xp0.8x15mm) 2 pcs 153 Bolt, Button Head (M8xp1.25x20mm) 4 pcs 155 Bolt, Button Head (M8xp1.25x40mm) 2 pcs...
  • Page 6 “B EFORE EGIN” Thank you for choosing the PhysioCycle RXT. We Too often, our busy lifestyles limit our time and take great pride in producing this quality product and opportunity to exercise. The equipment provides a hope it will provide many hours of quality exercise to convenient and simple method to begin your assault make you feel better, look better and enjoy life to its on getting your body in shape and achieving a...

  • Page 7: Step 1 - Front Stabilizer Assembly

    “A SSEMBLY NSTRUCTIONS” USE HARDWARE KIT – TEP 1 Front Stabilizer Assembly a. Identify the correct direction of the Front Stabilizer (7), there is an “R” decal on the right side of the Front Stabilizer b. Attach the Front Stabilizer (7) to the Main Frame (1) NOTE: “Small Tip: Attach all screws and bolts to the assembly parts first before secure”...

  • Page 8: Step 4 - Leveler Assembly

    “A SSEMBLY NSTRUCTIONS” USE HARDWARE KIT – TEP 3 Rear Stabilizer Assembly a. Attach the Rear Stabilizer (8) to the Rear Support Frame Assembly (2) NOTE: “Small Tip: Attach all screws and bolts to the assembly parts first before secure” To assemble the Rear Stabilizer (8) to the Rear Support Frame Assembly (2) with more efficient and easy way, it is suggested to attach two Carriage Bolt (M8xp1.25x90mm)(164) to the Rear Stabilizer (8) and the Rear Support Frame Assembly (2) first before fully secure.
  • Page 9 “A SSEMBLY NSTRUCTIONS” USE HARDWARE KIT – TEP 6 Seat Support Slider Assembly Slide the Seat Support Slider Assembly (5) into the Outer Seat Support Slider (4) and slightly attaches four Washers (8x16x2.0t)(123), four Lock Washers (M8)(121), four Bolts, Button Head (M8xp1.25x20mm)(153) to them NOTE: Please do not secure the above washers, lock washers and bolts until Step.
  • Page 10 “A SSEMBLY NSTRUCTIONS” USE HARDWARE KIT – TEP 8 Short Extension Pulse Wire & Rail Decoration Assembly a. Follow FIG.1 to plug the Short Extension Pulse Wire (183) into the connector located on the front bottom side of the Seat Rail (91) b.
  • Page 11 “A SSEMBLY NSTRUCTIONS” USE HARDWARE KIT – TEP 10 Seat and Seat Handlebar Assembly NOTE: Four Nylock Nuts (M8x1.25)(171) will be pre-attached on the Seat Carriage Assembly (9)’s Seat Fixed Stand as the figure shows on the right Remove four Nylock Nuts (M8x1.25)(171) from the Seat Fixed Stand first and place them in the safe place for the following assembly process c.
  • Page 12 “A SSEMBLY NSTRUCTIONS” USE HARDWARE KIT Please be sure that Bolt (157) would screw through the Shaft Sleeve (106) inside the rear end of the Right Pedal Support Arm Assembly (14) during assembly – TEP 11 Pedal Support Arm Assembly NOTE: Two Washers (6x19x2.0t)(122) and two Bolts, Hex Head (M8xp1.25x16mm)(146) will be pre-attached on the Rotation Stand (17) as the figure shows on the right...

  • Page 13: Step 13 - Ac Adaptor

    “A SSEMBLY NSTRUCTIONS” USE HARDWARE KIT After fully securing Bolt, Button Head (155) and Nylock Nut (M8)(171), slightly loosen the Bolt (155) with 1/4 circle in counter-clockwise direction in order to let Pedal Linkage function smoothly – TEP 12 Pedal Linkage and Pedal Assembly (19), there is an “R”...
  • Page 14 “O PERATION NSTRUCTIONS” OW TO ADJUST THE ADJUSTING ENDCAPS OF THE REAR STABILIZER a. After placing the equipment in the intended location for use, check the stability of the equipment b. If it’s the one of the Adjusting Rear Stabilizer EndCaps (37) on rear end of the Rear Stabilizer (8) causes a slight rocking motion.
  • Page 15 “O PERATION NSTRUCTIONS” NFORMATION ABOUT THE SEAT DISTANCE ADJUSTMENT a. To adjust the seat distance, it’s suggested to place your feet properly on each pedal b. Use your right hand to lift up the Adjusting Handle (A) while using your feet to slide the seat distance forward or backward until the seat reaches to the proper position c.
  • Page 16 “O PERATION NSTRUCTIONS” NFORMATION ABOUT EXCHANGE ELLIPITCAL MODE WITH STEPPER MODE STEPPER MODE:  The item can be used in the ELLIPTICAL mode or the STEPPER mode.  Refer to the following process to set up the ELLIPTICAL mode or the STEPPER mode. a.

  • Page 17: Console Buttons

    “C ONSOLE NSTRUCTIONS” ower a. Make sure the item’s adaptor is correctly plugged into the socket b. Pedaling or pressing any keys to active the console. The console display will then light up with a short beep sound, indicating the console will be ready for use ower...

  • Page 18: Program Descriptions

    “C ONSOLE NSTRUCTIONS” CONSOLE FUNCTIONS Automatically scans TIME, SPEED, CALORIE, PULSE, and DISTANCE in sequence with a SCAN change every five seconds. Press and release the MODE button until the arrow points to "SCAN” TIME TIME:  Count Up: If a target time was not selected, TIME will count up from 0:00 to maximum 99:59 minutes ...
  • Page 19 “C “ ONSOLE ROUBLE HOOTING UIDE PROBLEM POSSIBLE CAUSE SOLUTION 1. Motor Malfunction Replace Motor 2. Magnetic System Replace Magnetic System/Flywheel Malfunction or got stuck No Motor signal 3. Connection Wires are not Check whether the wires are well-connected or replace the well-connected or broken broke wires with the new wires 4.

  • Page 20: Troubleshooting Guide

    “C “ ONSOLE ROUBLE HOOTING UIDE PROBLEM POSSIBLE CAUSE SOLUTION The connection between the Circuit Board and the LCD Membrane is loose. Verify that the Circuit Board is securely fastened to the Computer Case. Retighten the Gently press Screws. Take care NOT to over tighten the Screws as this may destroy the Circuit down on the LCD Board.
  • Page 21 “C ONDITIONING UIDELINES” How you begin your exercise program depends on your physical condition. If you have been inactive for several years, or are severely overweight, you must slowly and increase your time on the 2 in 1 Elliptical / Stepper gradually: a few minutes per workout.
  • Page 22 “W ARM- P AND OOL- OWN” Warm-up The purpose of warming up is to prepare your body for exercise and to minimize injuries. Warm up for two to five minutes before strength-training or aerobic exercising. Perform activities that raise your heart rate and warm the working muscles.

  • Page 23: Parts Drawing

    “P RODUCT ARTS RAWING (A)”...
  • Page 24 “P RODUCT ARTS RAWING (B)”...
  • Page 25 “P IST” Item Name Q'TY Item Name Q'TY Main Frame 34 Bearing Housing Rear Support Frame 35 Transportation Wheel (L&R) Rail Pivot 36 Round EndCap Outer Seat Support Slider 37 Adjusting Rear Stabilizer EndCap Inner Seat Support Slider 38 leveler Handlebar (L&R) 39 Bushing (60x10mm) Front Stabilizer...
  • Page 26 IST” Item Name Q'TY Item Name Q'TY 67 Pivoting Arm Connector (L&R) 100 Spring for Fixing Pin 68 Locking Knob (L&R) 101 Spring for Adjusting Handle Stand 69 Bushing (25.4x12mm) 102 Bushing for Seat Wheel 70 Bushing (25.4x16.5mm) 103 Spacer (8×12×6.5mm) 71 Bushing (38.5x12mm) 104 Spacer (8×12×7.5mm) 72 Left Rail Connection Cap...
  • Page 27 IST” Item Name Q'TY Item Name Q'TY Self-Tapping Screw, Truss Head 159 Bolt, Socket Head (M8×p1.25×16mm) (M5×18mm) Self-Tapping Screw, Truss Head 160 Bolt, Socket Head (M8×p1.25×25mm) (M5×25mm) 161 Bolt, Socket Head (M8×p1.25×40mm) Self-Tapping Screw, Button Head (M4×15mm) 162 Bolt, Socket Head (M8×p1.25×70mm) 136 Screw, Pan Head (M5x12mm) 163 Carriage Bolt (M8×p1.25×50mm) 138 Screw, Round Head (M5×p0.8×15mm)
