RADIOACTIVE-SERIES
SUBWOOFER
Anleitung / Owner´s Manual
GZRW 8XSPL
Ausstattungsmerkmale / Features
• Hochbelastbarer 20 cm SPL Subwoofer
• Klippel® optimiert
• Verstärkte Papier-Membrane
• 50 mm Kupfer-Schwingspule
• Langhub-Sicke
o High power 8" SPL subwoofer
o Klippel® optimized
o Reinforced paper cone
o 2" copper voice coil
o High-roll surround
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Ground Zero GZRW 8XSPL
Summary of Contents for Ground Zero GZRW 8XSPL
- Page 1 RADIOACTIVE-SERIES SUBWOOFER Anleitung / Owner´s Manual GZRW 8XSPL Ausstattungsmerkmale / Features • Hochbelastbarer 20 cm SPL Subwoofer • Klippel® optimiert • Verstärkte Papier-Membrane • 50 mm Kupfer-Schwingspule • Langhub-Sicke o High power 8” SPL subwoofer o Klippel® optimized o Reinforced paper cone o 2”...
- Page 2 Technische Daten / Specifications GZRW 8XSPL Voice Coil Diameter mm / inch 50 / 2" Impedance (ohms) 2 x 2 (in serial / ohms) 3.75 (Hz) 45.8 5.92 0.38 0.36 Vas (Liter / cu.ft.) 7.4 / 0.26 (gr) (mm / inch) 22 / 0.87"...
- Page 3 Gehäuseempfehlung / Enclosure recommendation Bassreflex / Vented 25 Liter netto / 0.883 cu.ft. net Medium size 1 x 8 cm / 1 x 3.15” Port 22.5 cm / 8.89” Portlänge / Length* 38 Hz Bassreflex / Vented 15 Liter netto / 0.53 cu.ft. net Small size 1 x 8 cm / 1 x 3.15”...
- Page 4 Verbesserungen an dem Produkt vorzunehmen, ohne den Kunden darüber zu informieren. Terms of warranty The limited warranty for this product is covered by Ground Zero´s local distribution partners and their terms and conditions. For further information contact your local retailer or distributor.
