Page 2
About this Document ● This Document includes instructions for using and managing the Product. Pictures, charts, images and all other information hereinafter are for description and explanation only. ● The information contained in the Document is subject to change, without notice, due to firmware updates or other reasons.
Page 3
AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED. ● YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
Page 4
Network Video Recorder User Manual Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
Page 5
Network Video Recorder User Manual purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see: http://www.recyclethis.info . 2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union. See the product documentation for specific battery information.
Page 6
Network Video Recorder User Manual Applicable Model This manual is applicable to the following models. Table 1-1 Applicable Model Series Model NVR-E04MH-D HL-NVR-E04MH-D(SSD 1T) HL-NVR-E04MH-D(SSD 2T) NVR-E04MH-D/4P HL-NVR-E04MH-D/4P(SSD 1T) HL-NVR-E04MH-D/4P(SSD 2T) NVR-E08MH-D HL-NVR-E08MH-D(SSD 1T) HL-NVR-E08MH-D(SSD 2T) NVR-E08MH-D/8P HL-NVR-E08MH-D/8P(SSD 1T) HL-NVR-E08MH-D/8P(SSD 2T)
Page 7
Network Video Recorder User Manual Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Indicates a hazardous situation which, if not avoided, will or could Danger result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, could Caution result in equipment damage, data loss, performance degradation, or...
Page 8
Network Video Recorder User Manual Safety Instruction Proper configuration of all passwords and other security settings is the responsibility of the ● installer and/or end-user. In the use of the product, you must be in strict compliance with the electrical safety regulations ●...
Page 9
Network Video Recorder User Manual Preventive and Cautionary Tips Before connecting and operating your device, please be advised of the following tips: The device is designed for indoor use only. Install it in a well-ventilated, dust-free environment ● without liquids. Ensure recorder is properly secured to a rack or shelf.
Network Video Recorder User Manual Contents Chapter 1 Startup ........................1 1.1 Activate Your Device ......................1 1.2 Login ............................2 1.2.1 Set Unlock Pattern ......................2 1.2.2 Log in via Unlock Pattern ....................2 1.2.3 Log in via Password ....................... 3 Chapter 2 Live View ........................
Page 11
Network Video Recorder User Manual 5.2.1 General ........................17 5.2.2 HiLookVision ....................... 18 5.2.3 Email ........................... 19 5.3 Camera Management ......................20 5.3.1 Network Camera ......................20 5.3.2 OSD Settings ........................ 23 5.3.3 Smart Event ......................... 24 5.4 Recording Management ....................... 31 5.4.1 Storage Device ......................
Network Video Recorder User Manual Chapter 1 Startup 1.1 Activate Your Device For the first-time access, you need to activate the video recorder by setting an admin password. No operation is allowed before activation. You can also activate the video recorder via web browser, SADP or client software.
Network Video Recorder User Manual 1.2 Login 1.2.1 Set Unlock Pattern Admin user can use the unlock pattern to login. You can configure the unlock pattern after the device is activated. Steps 1. Use the mouse to draw a pattern among the 9 dots on the screen. Release the mouse when the pattern is done.
Network Video Recorder User Manual Figure 1-3 Draw the Unlock Pattern 2. Draw the pre-defined pattern to enter the menu operation. Note If you have forgotten your pattern, you click Forgot My Pattern or Switch User to log in via ●...
Page 17
Network Video Recorder User Manual Note When you forget the password of the admin, you can click Forgot Password to reset the ● password. If you enter the wrong password 7 times, the current user account will be locked for 60 ●...
Network Video Recorder User Manual Chapter 2 Live View 2.1 GUI Introduction Click to start/stop auto-switch. The screen will automatically switch to the next one. ● Right click a camera, or click to enter full screen mode. ● Double click a camera to view it in single-screen mode. Double click again to exit single-screen ●...
Page 19
Network Video Recorder User Manual Steps 1. Preview a camera in live view and click on shortcut menu. Figure 2-2 PTZ Settings 2. Click 3. Set the PTZ camera parameters. Note All parameters should be the same as the PTZ camera. 4.
Network Video Recorder User Manual 2.2.2 PTZ Control Panel Introduction Table 2-3 PTZ Panel Description Icon Description Direction buttons, and the auto-cycle button. The speed of the PTZ movement. Zoom -/+. Focus -/+. Iris -/+. 2.2.3 Customize Preset Set a preset location where the PTZ camera would point to when an event occurs. Steps 1.
Network Video Recorder User Manual 3. Click of a desired patrol. 4. Click 5. Configure key point parameters, such as the key point No., duration of staying for one key point and speed of patrol. The key point is corresponding to the preset. The preset number determines the order at which the PTZ will follow while cycling through the patrol.
Network Video Recorder User Manual Chapter 3 Playback 3.1 GUI Introduction Go to Playback . Figure 3-1 Playback Table 3-1 Playback Interface Description Button Operation Button Operation 30 s reverse. 30 s forward. Full screen. Start playback. Speed down. Speed up. Speed.
Page 23
Network Video Recorder User Manual Steps 1. Go to Playback . 2. Select a camera from the camera list. 3. Select a date on the calendar for playback. Note The blue triangle at the calendar date corner indicates there are available videos. For example, means video is available.
Network Video Recorder User Manual 3.3 Event Playback When you select the event playback mode, the system will analyze and mark videos that contain the motion detection, line crossing detection, or intrusion detection information, . Before You Start Ensure the camera has enabled Dual-VCA. You can enable it via the camera web browser ●...
Network Video Recorder User Manual If it is enabled, videos without smart information will not be played. Normal Video Set normal video playback speed. The option is only valid when Do not Play Normal Videos is unchecked. Play Speed of Smart/Custom Video Set playback speed of videos with smart information.
Network Video Recorder User Manual Chapter 4 Search File Steps 1. Go to Search . 2. Select a search type (video or event). 3. Set search conditions. 4. Click Search. - Click to play the video. - Select file(s), and click Export to export file(s) to backup device.
Network Video Recorder User Manual Chapter 5 Configuration (Easy Mode) Easy mode contains basic configurations. Go to Configuration , and click Easy Mode. 5.1 System Configuration 5.1.1 General You can configure the output resolution, system time, etc. Steps 1. Go to Configuration → System → General . Figure 5-1 General Settings 2.
Network Video Recorder User Manual Time interval between two time synchronization with NTP server. NTP Server IP address of the NTP server. 3. Click Apply. 5.1.2 User Add User There is a default account: Administrator. The administrator user name is admin. Administrator has the permission to add, delete, and edit user.
Network Video Recorder User Manual Set Password Resetting Email When you forget your login pattern and password, the device will send an email contains verification code to your email for password resetting. Steps 1. Go to Configuration → System → User . 2.
Network Video Recorder User Manual Figure 5-3 Exceptions 5. Click Apply. 5.2 Network Configuration 5.2.1 General You shall properly configure the network settings before operating the device over network. Steps 1. Go to Configuration → Network → General . Figure 5-4 Network 2.
Network Video Recorder User Manual If the DHCP server is available, you can enable DHCP to automatically obtain an IP address and other network settings from that server. Auto Obtain DNS If DHCP is enabled. You can enable Auto Obtain DNS to automatically obtain Preferred DNS Server and Alternate DNS Server.
Network Video Recorder User Manual Note If the device is already bound with an account, you should unbind with the current account. 8. Click Apply. What to do next You can access your video recorder via HiLookVision. 5.2.3 Email Set an email account to receive event notification. Before You Start Ensure SMTP service is available for your email.
Network Video Recorder User Manual Password The password of email sender for SMTP server authentication. SSL/TLS (Optional) Enable SSL/TLS if it is required by the SMTP server. Attached Picture (Optional) If events are triggered, it will send images as email attachment. Sender The sender name.
Page 34
Network Video Recorder User Manual Steps 1. Go to Configuration → Camera → IP Camera . The online cameras on the same network segment with your video recorder are displayed in Online Device List. Figure 5-7 IP Camera Management Interface 2.
Page 35
Network Video Recorder User Manual Figure 5-8 Add Network Camera Edit Connected Network Camera You can edit the IP address, protocol and other parameters of the added network cameras. Steps 1. Go to Configuration → Camera → IP Camera . 2.
Network Video Recorder User Manual 2. Click Sort Channel. 3. Drag a channel window to the channel number as your desire. 4. Click Apply. Note After sorting channels, the device will reconnect to network cameras. Upgrade Network Camera The Network camera can be remotely upgraded through the device. Before You Start Ensure you have inserted the USB flash drive to the device, and it contains the network camera ●...
Network Video Recorder User Manual Steps 1. Go to Configuration → Camera → OSD . 2. Select a camera. Figure 5-9 OSD 3. Set parameters as your desire. 4. Drag the text frames on the preview window to adjust the OSD position. 5.
Page 38
Network Video Recorder User Manual Figure 5-10 Motion Detection 2. Select a camera. 3. Turn on Enable. 4. Set the motion detection area. - Click Draw Area or Clear to draw or clear areas. The first area is set as full screen by default. - Click Full Screen to set the motion detection area as full screen.
Page 39
Network Video Recorder User Manual Figure 5-11 Line Crossing Detection 2. Select a camera. 3. Turn on Enable. 4. Set line crossing detection rules and detection areas. 1) Set Arming Area. Up to 4 arming areas are selectable. 2) Select Direction as A<->B, A->B, or A<-B. A<->B Only the arrow on the B side shows.
Page 40
Network Video Recorder User Manual Steps 1. Go to Configuration → Camera → Event → Intrusion . Figure 5-12 Intrusion Detection 2. Select a camera. 3. Turn on Enable. 4. Set detection rules and detection areas. 1) Set Arming Area. Up to 4 arming areas are selectable. 2) Set Sensitivity.
Page 41
Network Video Recorder User Manual Figure 5-13 Region Entrance Detection 2. Select a camera. 3. Turn on Enable. 4. Set detection rules and detection areas. 1) Set Arming Area. Up to 4 arming areas are selectable. 2) Set Sensitivity. The higher the value is, the easier the detection alarm can be triggered. Its range is [1-100].
Page 42
Network Video Recorder User Manual Figure 5-14 Region Exiting Detection 2. Select a camera. 3. Turn on Enable. 4. Set detection rules and detection areas. 1) Set Arming Area. Up to 4 arming areas are selectable. 2) Set Sensitivity. The higher the value is, the easier the detection alarm can be triggered. Its range is [1-100].
Page 43
Network Video Recorder User Manual Figure 5-15 Set Arming Schedule 3. Click Apply. Configure Alarm Linkage Action Alarm linkage actions will be activated when an alarm or exception occurs. Steps 1. Click Linkage Action. Figure 5-16 Linkage Actions 2. Set normal linkage actions, alarm output linkage actions, trigger channel, etc. Alarm Pop-up Window The local monitor will pop up the alarming channel image when an alarm is triggered.
Network Video Recorder User Manual It will trigger PTZ actions (e.g., call preset/patrol/pattern) when smart events occur. Audio and Light Alarm Linkage For certain network cameras, you can set the alarm linkage action as audio alarm or light alarm. Note Ensure your camera supports audio and light alarm linkage.
Network Video Recorder User Manual 2. Click Add. 3. Select NetHDD. 4. Set Type as NAS or IP SAN. 5. Enter NetHDD IP address. 6. Click to search the available disks. Figure 5-17 Add NetHDD 7. Select NAS disk from the list, or manually enter the directory in NetHDD Directory. 8.
Page 46
Network Video Recorder User Manual Steps 1. Go to Configuration → Event → Smart Event . 2. Configure the event detection and select the channels to trigger the recording when an event occurs. 3. Go to Configuration → Record → Parameter . 4.
Network Video Recorder User Manual Note Up to 8 periods can be configured for each day. And the time periods cannot be overlapped with each other. e. Click OK to save the settings and go back to upper level menu. Draw a.
Network Video Recorder User Manual Chapter 6 Configuration (Expert Mode) Go to Configuration , and click Expert Mode at the lower-left corner. 6.1 System Configuration 6.1.1 General Configure Basic Settings You can configure the language, system time, output resolution, mouse pointer speed, lock screen password, etc.
Page 49
Network Video Recorder User Manual Figure 6-1 Basic Settings Configure DST Settings DST (Daylight Saving Time) refers to the period of the year when clocks are moved one period ahead. In some areas worldwide, this has the effect of creating more sunlit hours in the evening during months when the weather is the warmest.
Network Video Recorder User Manual Device Name Edit the video recorder name. Device No. The number is required in the connection with remote control, network keyboard, etc. Edit the serial number of video recorder. The device number ranges from 1 to 255, and the default value is 255.
Page 51
Network Video Recorder User Manual Figure 6-4 Live View-General 2. Configure the Live View parameters. Window Division Select the live view window division. Auto Switch Interval The time to dwell in a camera before switching to next camera when auto-switch in live view is enabled.
Network Video Recorder User Manual 6.1.3 User Refer to User for details. 6.2 Network Configuration 6.2.1 TCP/IP TCP/IP must be properly configured before you operate video recorder over network. Steps 1. Go to Configuration → Network → General → TCP/IP . 2.
Network Video Recorder User Manual 6.2.2 DDNS Dynamic domain name server (DDNS) maps dynamic user IP addresses to a fixed domain name server. Before You Start Register DynDNS, PeanutHull and NO-IP services with your ISP. Steps 1. Go to Configuration → Network → General → DDNS . Figure 6-5 DDNS 2.
Network Video Recorder User Manual Steps 1. Go to Configuration → Network → General → NAT . Figure 6-6 NAT 2. Turn on Enable. 3. Select Mapping Type as Manual or Auto Auto The port mapping items are read-only, and the external ports are set by the router automatically.
Network Video Recorder User Manual 6.2.5 Log Server Settings Upload Logs to the Server You can upload system logs to the server for backup. Steps 1. Go to Configuration → Network → General → Log Server Settings . Figure 6-7 Log Server Settings 2.
Page 56
Network Video Recorder User Manual Figure 6-8 One-Way Authentication 2. Install the CA certificate in CA Certificate. 3. Optional: Click Test to test if the connection is valid. 4. Click Save. Two-Way Authentication You can install a CA certificate (from the server) to your device to authorize the server, and create a certificate (from your device) to authorize your device by the server.
Network Video Recorder User Manual Figure 6-9 Two-Way Authentication 2. Install the CA certificate in CA Certificate. 3. Click Create in Client Certificate, and follow the pop-up to create the certificate. 4. Click Download to download the certificate file to a desired location. 5.
Network Video Recorder User Manual For remote web browser access. The default value is 80. Multicast IP Multicast can be configured to enable live view for cameras that exceed the maximum number allowed through network. A multicast IP address covers Class-D IP ranging from 224.0.0.0 to 239.255.255.255 and it is recommended to use the IP address ranging from 239.252.0.0 to 239.255.255.255.
Network Video Recorder User Manual 6.2.8 Email Go to Configuration → Network → Email . Refer to Email for details. 6.3 Camera Management 6.3.1 Network Camera Add Automatically Searched Online Network Camera Add the network cameras to your video recorder. Before You Start Ensure your network camera is on the same network segment with your video recorder.
Page 60
Network Video Recorder User Manual Figure 6-12 Add IP Camera 3. Enter network camera parameters. Use Channel Default Password If it is enabled, the video recorder will add the camera by the set channel default password. 4. Click Add. Edit Connected Network Camera You can edit the IP address, protocol and other parameters of the added network cameras.
Page 61
Network Video Recorder User Manual Upgrade Network Camera The Network camera can be remotely upgraded through the device. Before You Start Ensure you have inserted the USB flash drive to the device, and it contains the network camera ● upgrade firmware. Ensure your network camera is on the same network segment with your video recorder.
Page 62
Network Video Recorder User Manual 2. Enable or disable long network cable mode by selecting Long Distance or Short Distance. Long Distance Long-distance (100 to 300 meters) network transmissions via PoE interface. Short Distance Short-distance (< 100 meters) network transmission via PoE interface. Note The PoE ports are enabled with the short distance mode by default.
Page 63
Network Video Recorder User Manual Steps 1. Go to Configuration → Camera → Camera → IP Channel . 2. Click of a channel with no linked network camera. 3. Select Adding Method as Manual. Plug-and-Play The camera is physically connected to the PoE interface. You can click in the added device list to edit its parameters.
Network Video Recorder User Manual Steps 1. Go to Configuration → Camera → Camera → IP Channel . 2. Click Export/Import to export/import configuration files to the connected backup device. 3. Set the storage device and folder path. 4. Click Export/Import. What to do next After the importing process is completed, you must restart the video recorder.
Network Video Recorder User Manual Customize the image parameters including the brightness, contrast, and saturation for the live view and recording effect. Exposure Set the camera exposure time (1/10000 to 1 sec). A larger exposure value results in a brighter image.
Network Video Recorder User Manual Figure 6-16 Privacy Mask 4. Drag to draw an area on the window. The frames of the areas will be marked with different colors. Note Up to 4 privacy mask areas can be configured. The size of each area can be adjusted. 5.
Page 67
Network Video Recorder User Manual Steps 1. Go to Configuration → Event → Normal Event → Video Tampering . Figure 6-17 Video Tampering 2. Set Camera. 3. Turn on Enable. 4. Adjust Sensitivity as your desire. The higher the value is, the more easily the video tampering can be triggered.
Page 68
Network Video Recorder User Manual Steps 1. Go to Configuration → Event → Normal Event → Alarm Input . Figure 6-18 Alarm Input Note Local alarm input: Local alarm input is triggered by the external device that connected to the video recorder's terminal block.
Page 69
Network Video Recorder User Manual Figure 6-21 Edit Alarm Output 5. Set Settings as Input to enable the function. 6. Set the arming schedule. Refer to Configure Arming Schedule for details. 7. Click Apply. Exception Exception events can be configured to take the event hint in the live view window and trigger alarm outputs and linkage actions.
Network Video Recorder User Manual Figure 6-22 Exceptions 4. Set the arming schedule. Refer to Configure Arming Schedule for details. 5. Click Apply. 6.4.2 Smart Event Line Crossing Detection Line crossing detection detects people, vehicles, and objects crossing a set virtual line. The detection direction can be set as bidirectional, from left to right or from right to left.
Page 71
Network Video Recorder User Manual 3) Optional: Set Target Detection as Human or Vehicle to discard alarms which are not triggered by human body or vehicle. Note This function is only available for certain models. 4) Click Draw Area and draw a quadrilateral in the preview window by specifying four vertexes of the detection region.
Page 72
Network Video Recorder User Manual Region Entrance Detection Region entrance detection function detects people, vehicles or other objects which enter a pre- defined virtual region from the outside place, and some certain actions can be taken when the alarm is triggered. Steps 1.
Network Video Recorder User Manual Note This function is only available for certain models. 4) Click Draw Area and draw a quadrilateral in the preview window by specifying four vertexes of the detection region. 6. Set the arming schedule. Refer to Configure Arming Schedule for details. 7.
Network Video Recorder User Manual Figure 6-23 Set Arming Schedule 3. Click Apply. 6.4.4 Configure Alarm Linkage Action Configure Full Screen Monitoring When an alarm is triggered, the local monitor displays in full screen the video image from the alarming channel configured for full screen monitoring. And when the alarm is triggered simultaneously in several channels, you must configure the auto-switch dwell time.
Page 75
Network Video Recorder User Manual Steps 1. Go to Configuration → System → Live View → General . 2. Turn on Audio, and set Volume. 3. Go to Linkage Action interface of the alarm detection. 4. Select Audio Warning alarm linkage action. Notify Surveillance Center The video recorder can send an exception or alarm signal to the remote alarm host when an event occurs.
Page 76
Network Video Recorder User Manual Configure PTZ Linkage Video recorder can trigger the PTZ actions (e.g., call preset/patrol/pattern) when the alarm event, or VCA detection events occur. Steps 1. Go to Linkage Action interface of the alarm input or VCA detection. 2.
Network Video Recorder User Manual 6.5 Recording Management 6.5.1 Configure Recording Schedule Video recorder will automatically start/stop recording according to the configured schedule. Configure Continuous Recording Steps 1. Go to Configuration → Record → Parameter . 2. Set the continuous main stream/sub-stream recording parameters for the camera. 3.
Page 78
Network Video Recorder User Manual Figure 6-25 Recording Schedule Continuous Continuous recording. Event Recording triggered by all event triggered alarms. 2. Select a camera in Camera No. 3. Turn on Enable. 4. Configure the recording schedule. 1) Click Edit. 2) Select a day to configure in Weekday. 3) To set an all-day recording schedule, check All Day and select schedule Type.
Network Video Recorder User Manual Post-Record The time you set to record after the event or the scheduled time. For example, when an alarm triggered recording ends at 11:00, and if you set the post-record time as 5 seconds, it records till 11:00:05.
Network Video Recorder User Manual often exclusively used by smartphone applications to view live video. Users with limited internet speeds may benefit most from this setting. Frame Rate Frame rate refers to how many frames are captured each second. A higher frame rate is advantageous when there is movement in the video stream, as it maintains image quality throughout.
Network Video Recorder User Manual Add Network Disk You can add the allocated NAS or IP SAN disk to the video recorder, and use it as a network HDD. Steps 1. Go to Configuration → Record → Storage . 2. Click Add. 3.
Page 82
Network Video Recorder User Manual Disable: When the HDD is full, video recorder will stop writing. ● Enable: When hard drive is full, video record will continue to write new files by deleting the ● oldest files. Save Camera VCA Data Camera VCA data will be saved so that you can search it.
Network Video Recorder User Manual Chapter 7 Maintenance 7.1 Restore Default Steps 1. Click at the upper-right corner. 2. Select the restoring type. Simple Restore Restore all parameters, except the network (including IP address, subnet mask, gateway, MTU, NIC working mode, default route, server port, etc.) and user account parameters, to the factory default settings.
Network Video Recorder User Manual RTSP Authentication Two authentication types are selectable, if you select digest, only the request with digest authentication can access the video stream by the RTSP protocol via the IP address. For security reasons, it is recommended to select digest as the authentication type. ISAPI ISAPI (Internet Server Application Programming Interface) is an open protocol based on HTTP, which can realize the communication between the system devices (e.g., network camera,...
Network Video Recorder User Manual 7.4.2 Online Upgrade Upgrade the device with the latest online firmware. Before You Start Ensure HiLookVision is enabled and properly configured. Refer to HiLookVision for details. Steps 1. Click at the upper-right corner. 2. Click 3.
Network Video Recorder User Manual Chapter 8 Alarm When events occur, you can view their details in alarm center. 8.1 Set Event Hint Select the events to hint in alarm center. Steps 1. Click at the upper-right corner. 2. Set Exception, Basic Event, or Smart Event as your desire. Figure 8-1 Alarm Center 3.
Network Video Recorder User Manual Chapter 9 Web Operation 9.1 Introduction You can get access to the video recorder via web browser. You may use one of the following listed web browsers: Internet Explorer 11.0, Apple Safari, Mozilla Firefox, and Google Chrome. The supported resolutions include 1024×768 and above. For certain models, you will have to download a web component plug-in, and install it.
Network Video Recorder User Manual 9.3 Live View After login, live view interface shows. Figure 9-2 Live View 9.4 Playback Click Playback to enter playback interface. Figure 9-3 Playback 9.5 Configuration Click Configuration to enter configuration interface.
Network Video Recorder User Manual Figure 9-4 Configuration 9.6 Log Steps 1. Go to Maintenance → System → Maintenance → Log . 2. Set the search conditions. 3. Click Search. Figure 9-5 Log...
Page 90
Network Video Recorder User Manual Chapter 10 Appendix 10.1 Glossary Dual-Stream Dual-stream is a technology used to record high resolution video locally while transmitting a lower resolution stream over the network. The two streams are generated by the DVR, with the main stream having a maximum resolution of 1080P and the sub-stream having a maximum resolution of CIF.
Page 91
Network Video Recorder User Manual NTSC Acronym for National Television System Committee. NTSC is an analog television standard used in such countries as the United States and Japan. Each frame of an NTSC signal contains 525 scan lines at 60Hz. Acronym for Network Video Recorder.
