OWNER'S MANUAL
WASHING MACHINE
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
FHT1415ZTM
MFL71917039
Rev.02_032723
Copyright © 2022-2023 LG Electronics Inc. All Rights Reserved.
www.lg.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for LG FHT1415ZTM
Summary of Contents for LG FHT1415ZTM
- Page 1 This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH FHT1415ZTM www.lg.com MFL71917039 Rev.02_032723 Copyright © 2022-2023 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
Control Panel ....................22 Preparing the Wash Load ................24 Adding Detergents and Softeners ..............24 Programme Table ....................27 Extra Options and Functions ................30 SMART FUNCTIONS LG ThinQ Application ..................33 Smart Diagnosis ....................35 MAINTENANCE Cleaning After Every Wash................37 Cleaning the Appliance Periodically ..............37 TROUBLESHOOTING... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. Safety Messages This symbol is displayed to indicate matters and operations that can cause risk. - Page 4 SAFETY INSTRUCTIONS • Children should be supervised to ensure that they do not play with the appliance. • If the power cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
- Page 5 SAFETY INSTRUCTIONS • This appliance is equipped with a power cord having an equipment- earthing / grounding conductor (earthing pin) and a grounding power plug. The power plug must be plugged into an appropriate outlet socket that is installed and earthed / grounded in accordance with all local codes and ordinances.
- Page 6 • Do not touch the door during a high temperature programme. • In case of a water leak from the appliance or flood, disconnect the power plug and contact the LG Electronics customer information centre. • Turn off water taps to relieve pressure on hoses and valves and to minimize leakage if a break or rupture should occur.
- Page 7 • Only qualified service personnel from LG Electronics service centre should disassemble, repair, or modify the appliance. Contact an LG Electronics customer information centre if you move and install the appliance in a different location.
-
Page 8: Caring For The Environment
• To locate a nearest collection centre or call for pick-up (limited area only) for disposal of this appliance, please contact No. 08069379999, Toll Free No. 1800-315-9999 for details. All collection centre and pick up facilities are done by third parties with LG Electronics India Pvt. - Page 9 SAFETY INSTRUCTIONS Ltd. Merely as a facilitator. For more detailed information, please visit : http://www.lg.com/in...
-
Page 10: Installation Parts And Specifications
INSTALLATION INSTALLATION Parts and Specifications NOTE • Appearance and specifications may change without notice to improve the quality of the appliance. Front View Rear View Power Plug Control Panel Transit Bolts Detergent Dispenser Drawer Drain Hose Drum Door Cover Cap Drain Pump Filter Drain Plug Levelling Feet... - Page 11 INSTALLATION Specifications Model FHT1415ZTM Power Supply 220-240 V~, 50 Hz Product Weight 77 kg Dimension(mm) D’ 1270...
- Page 12 INSTALLATION Accessories Cold Supply Hose Anti–slip Sheets*1 Spanner Elbow Bracket for Securing Drain Hose Caps for Covering Transit Bolt Holes Tie Strap*1 *1 The included accessories vary depending on the model you purchased.
-
Page 13: Installation Place Requirements
INSTALLATION Installation Place Index Clearance (mm) Requirements Before installing the appliance, check the following information to make sure that the appliance should be installed in a correct place. WARNING Installation Location • This appliance must only be used for domestic household purposes and should not be used in •... -
Page 14: Unpacking The Appliance
INSTALLATION grounded/earthed in accordance with all local NOTE codes and ordinances. • You can purchase rubber cups (part No. 4620ER4002B) from the LG service centre. Unpacking the Appliance Ventilation Lifting the Appliance Off the Foam Base • Make sure that air circulation around the... -
Page 15: Levelling The Appliance
INSTALLATION Levelling the Appliance Starting with the bottom two transit bolts use the spanner (included) to fully loosen all Checking the Level transit bolts by turning them counterclockwise. When pushing down the edges of the top plate diagonally, the appliance should not move up and down at all (check both directions). - Page 16 • Do not install the washing machine on a plinth, Failure to do so may cause vibration or noise. stand or elevated surface unless it is manufactured by LG Electronics for use with this model. Using Anti-Slip Sheets This feature may vary depending on the model Check if the appliance is perfectly level using a purchased.
-
Page 17: Connecting The Water Supply Hose
• Do not attach the adhesive side of anti- slip sheets to the feet of the appliance. NOTE • Additional anti-slip sheets are available at LG Electronics service centre. Connecting the Hose to the Water Tap Connecting Screw-Type Hose to Tap with Thread... - Page 18 INSTALLATION Connecting Screw-Type Hose to Tap Without Connecting One Touch Type Hose to Tap Thread Without Thread Loosen the 4 fixing screws Unscrew the adapter ring plate and loose the 4 fixing screws. Remove the guide plate if the tap is too large to fit the adapter.
-
Page 19: Installing The Drain Hose
INSTALLATION connector latch plate. Make sure the adapter • Make sure that the hose should not be kinked or locks into place. trapped. Installing the Drain Hose Installing the Drain Hose with the Elbow Bracket The drain hose should not be placed higher than 100 cm above the floor. - Page 20 INSTALLATION • When installing the drain hose to a sink, secure it tightly with string.
-
Page 21: Operation Operation Overview
OPERATION OPERATION Operation Overview Add cleaning products or detergent and softener. Using the Appliance • Add the proper amount of detergent to the detergent dispenser. If desired, add bleach Before the first wash, select the Cotton wash or fabric softener to the appropriate areas of programme and add a half amount of the the dispenser. -
Page 22: Control Panel
• This allows you to select an additional programmes and will light when selected. Remote Start With the LG ThinQ app, you can use a smartphone to control your appliance remotely. • In order to use this function, refer to SMART FUNCTIONS. - Page 23 OPERATION Description Customizing Washing Programme Buttons Use these buttons to adjust the water temperature, spin speed and soil level settings for the selected programme. • The current settings are shown in the display. • Press the button for that option to select other settings. Display •...
-
Page 24: Preparing The Wash Load
OPERATION Preparing the Wash Load NOTE Sort the wash load for best washing results, and • The dashes under the symbol give you then prepare the clothes according to the symbols information about the type of fabric and the on their care labels. maximum allowance of mechanical stress. - Page 25 OPERATION detergents that are suitable for Drum (front • Minimum load: 1/3 of full load. load) type washers. • If too many suds occur, reduce the detergent amount. Using the Dispenser • If too much detergent is used, too many suds can occur and this will result in poor washing To add detergent dosage to the dispenser: results or cause heavy load to the motor.
- Page 26 OPERATION rinse cycle. Either powdered or liquid fabric NOTE softener may be used. • Pour fabric softener to the maximum fill line. • Do not put tablets into the dispenser. Pouring excessive fabric softener over the maximum fill line can cause it to dispense too early, which may stain the clothes.
-
Page 27: Programme Table
OPERATION Programme Table Washing Programme Cotton 40 ℃ (Cold to 60 ℃) Max. Load: Rating Description Washes normally soiled clothes by combining various drum motions. Stain Care 60 ℃ (40 °C to 60 ℃) Max. Load: 5 kg Description Washes heavily soiled clothes by combining special drum motions. Baby Care Max. - Page 28 OPERATION Speed Wash 40 ℃ (Cold to 40 ℃) Max. Load: 5 kg Description Washes small loads of lightly soiled clothes in a short time. Rinse+Spin Max. Load: Rating Description Rinses and spins clothes. Use fabric softener if needed. Download Cycle Description This programme allows you to download a new and special washing programme to your appliance with a smartphone.
- Page 29 OPERATION Programme Steam TurboWash Crease Care Delicates Sportswear Duvet Speed Wash Rinse+Spin Selectable Maximum Spin Speed Programme Maximum Spin Speed Cotton Extra High Stain Care Extra High Baby Care Extra High Hygiene Extra High Allergy Care Extra High Delicates Sportswear Extra Low Duvet Medium...
-
Page 30: Extra Options And Functions
OPERATION Extra Options and Follow the next steps to customize a washing programme: Functions You can use the extra options and functions to Prepare the clothes and load the drum. customize the programmes. Customizing a Washing Press the Power button. Programme Each programme has default settings that are Add detergent. - Page 31 OPERATION Using Special Options You can customize washing programmes by adjusting options, if needed. You can customize the programmes by using the following special options: NOTE Steam • Washing method, number of rinses, spin Adding this option helps provide better cleaning intensity and water temperature etc.
- Page 32 OPERATION • Avoid using liquid detergent for this function. Press the Start/Pause button. Press the Add Item button as necessary. Settings Child Lock Open the door after it unlocks itself and add or Use this option to disable the controls. This remove necessary clothing items.
-
Page 33: Smart Functions
SMART FUNCTIONS SMART FUNCTIONS LG ThinQ Application notifications on a smartphone. The notifications are triggered even if the LG ThinQ application is off. The LG ThinQ application allows you to communicate with the appliance using a smartphone. NOTE LG ThinQ Application Features •... - Page 34 SMART FUNCTIONS • Smartphone user interface (UI) may vary Run the LG ThinQ application and sign in with depending on the mobile operating system (OS) your existing account or create an LG account and the manufacturer. to sign in. • If the security protocol of the router is set to WEP, you may fail to set up the network.
-
Page 35: Smart Diagnosis
LG ThinQ application. Disable this function manually When this function is activated, press and hold the • Launch the LG ThinQ application and select the Remote Start button for 3 seconds. Smart Diagnosis feature in the menu. Follow the instructions provided in the LG ThinQ application. - Page 36 SMART FUNCTIONS NOTE • For best results, do not move the smartphone while the tones are being transmitted.
-
Page 37: Maintenance
MAINTENANCE MAINTENANCE WARNING • Unplug the appliance before cleaning to avoid the risk of electric shock. Failure to follow this warning may result in serious injury, fire, electric shock, or death. • Never use harsh chemicals, abrasive cleaners, or solvents to clean the appliance. They may damage the finish. - Page 38 MAINTENANCE Cleaning the Water Inlet Filter Run this function once a month (or more often if needed) to reduce build-up of detergent and The water inlet filter collects lime or any sediment softener and other residue. that may be in water that is supplied to the •...
- Page 39 MAINTENANCE Allow the water to cool before cleaning the drain Unscrew the drain pump filter slowly to drain pump filter. Open the door in an emergency or the remaining water and then proceed to perform an emergency water evacuation. remove any debris or objects from the filter. Unplug the appliance.
- Page 40 MAINTENANCE check for build-up of cleaning products once or twice a month. Remove the detergent dispenser drawer by pulling the drawer straight out until the drawer stops. • Then gently pull the drawer outward while pressing hard the disengage button. Remove the build-up of detergent and softener.
-
Page 41: Troubleshooting
Operation of your appliance can lead to errors and malfunctions. The following tables contain possible causes and notes for resolving an error message or malfunction. It is recommended to read the tables carefully below in order to save your time and money that may cost for calling to LG Electronics service centre. - Page 42 • Check and clean the drain filter. Door sensor malfunctions. dE dE1 dEz dE4 DOOR ERROR • Please call LG service centre. You can find your local LG service centre phone number in the warranty card. This is a control error. CONTROL ERROR •...
- Page 43 TROUBLESHOOTING Symptoms Possible Cause & Solution Thumping sound The clothes may be out of balance. • Pause the programme and redistribute the clothes after the door unlocks. Vibrating noise Package materials are not removed. • Remove package materials. The clothes may be unevenly distributed in the drum. •...
- Page 44 TROUBLESHOOTING Symptoms Possible Cause & Solution Appliance does not Circuit breaker/fuse is tripped/blown. operate. • Check house circuit breakers/fuses. Replace fuses or reset breaker. The appliance should be on a dedicated branch circuit. The appliance will resume the programme where it stopped once power is restored. Control needs to be reset.
- Page 45 TROUBLESHOOTING Symptoms Possible Cause & Solution Appliance does not Drain located higher than 1 m above the floor. drain water. • Make sure that the drain hose is no higher than 1 m above the bottom of the appliance. Detergent is not Too much detergent is used.
- Page 46 • Find the Wi-Fi network connected to your smartphone and remove it, then not connected to the register your appliance on LG ThinQ. Wi-Fi network. Mobile data for your smartphone is turned on. • Turn off the Mobile data of your smartphone and register the appliance...
- Page 47 TROUBLESHOOTING Symptoms Possible Cause & Solution Your home appliance The wireless network name (SSID) is set incorrectly. and smartphone are • The wireless network name (SSID) should be a combination of English not connected to the letters and numbers. (Do not use special characters). Wi-Fi network.
