FATEK P5102S Installation Manual

Thank you for purchasing FATEK HMI. Before installing or operating the unit, please
read this installation guide carefully to ensure correct use.
1. Safety Precaution s
1.1 General
Unpack and check the delivery for transportation damage. If any damage or
deformation is found, please notify the supplier.
The supplier is not responsible for the disassembled, altered or modified
device.
Never allow fluid or any conductive particles to enter into the HMI.
Otherwise, it may damage the HMI, cause fire or malfunction.
Only qualified personnel may install the HMI, perform maintenance and
inspection.
The liquid crystal inside the LCD panel is a hazardous substance. If the
panel is damaged, avoid contact with the leaked liquid crystal. If the liquid
crystal spills on clothing or skin, use soap and wash off thoroughly. In case
of eye contact the liquid, hold the eye open, flush with plenty water and get
medical attention as soon as possible.
Do not touch any terminals while the power is on. Otherwise, it may cause
injury due to electrical shock.
Disconnect the power supply before installing the HMI, do wiring operation,
perform maintenance or inspection. Otherwise, it may cause damage or
electrical shock.
1.2 Installation
The installation may be carried out by qualified personnel only.
Install the HMI according to the installation procedures.
Check the power source voltage is within the specified range and the
polarity is correct before connecting the HMI
Keep signal and power supply cables away from high-voltage, large-current
carrying cables.
R
P5102S/N/N1 HMI Installation Guide
1
(Read these precautions before use.)
.
