LED MOVE STROBE 1000
LED Strobe Wash Outdoor Moving Light
This product manual contains important information about the safe installation and
use of this projector. Please read and follow these instructions carefully and keep
this manual in a safe place for future reference.
User manual
Please read the instructions carefully before use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LED MOVE STROBE 1000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Eco Stage LED MOVE STROBE 1000

  • Page 1 LED MOVE STROBE 1000 LED Strobe Wash Outdoor Moving Light This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Dimension ........................3 2. Safety Information ....................3 3. Preparing for installation ..................5 4. Installation ......................... 5 5. Connecting AC Power ....................6 6. Configuring the fixture .................... 7 7. Connecting to a DMX control device ..............8 8.
  • Page 3: Dimension

    1. Dimension 2. Safety Information WARNING! Read the safety precautions in this section before unpacking, installing, powering or operating this product. This luminaries are multi-environmental fixtures with an IP-rating of 65, intended for professional use only. They are not suitable for household use. Review the following safety precautions carefully before installing or operating the fixture.
  • Page 4 WARNING! Risk of electric shock. Always power off/unplug the fixture before removing any covers.  Ensure that the power is turned off when connecting the fixture to the AC  mains supply. Ensure that the fixture is electrically connected to earth (ground). ...
  • Page 5: Preparing For Installation

    Do not look directly at the light source from close range.  Take precautions to prevent injury due to falls when working at height.  For permanent installation, ensure that the fixture is securely fastened to a  load-bearing surface with suitable corrosion-resistant hardware. For temporary installation with clamps, ensure that the quarter-turn ...
  • Page 6: Connecting Ac Power

    normal operation the moisture will evaporate. However, in locations with high rainfall, you may wish to fabricate a rain shield above the fixture, or modify the position and orientation of the fixture to minimize pooling. Two quarter-turn brackets are supplied with the fixture if it is to be flown above the ground.
  • Page 7: Configuring The Fixture

    After connecting the fixture to power, run the on-board test, using the “Fixture Text” menu, to ensure that the fixture and each LED are functioning correctly. See “Control menu” on page 13. CAUTION: Do not open the fixture to replace the supplied power cable, or connect the fixture to an electrical dimmer system, as this can damage it.
  • Page 8: Connecting To A Dmx Control Device

    Using stand-alone operation Stand-alone operation is where the fixture is not connected to a control device, but is preprogrammed with 2 modes (Auto Color, Auto Fade), that play continuously in a loop, the run speed of “Auto Color”, “Auto Fade” are adjustable.
  • Page 9: Configuring The Fixture For Dmx Control

    8. Configuring the fixture for DMX control About DMX The fixture can be controlled using signals sent by a DMX controller on a number of channels (which varies depending on the DMX mode that has been set). The first channel used to receive data from a DMX control device is known as the DMX start address.
  • Page 10: Cleaning

    9. Cleaning To maintain optimal performance, regular cleaning is essential. Cleaning schedules will vary depending on the operating environment, and the installation should therefore be checked at frequent intervals within the first few weeks of operation to see whether cleaning is necessary. This procedure will allow you to assess cleaning requirements in your par- ticular situation.
  • Page 11 86-128 Strobe Mode 3 129-171 Strobe Mode 4 172-214 Strobe Mode 5 215-255 Strobe Mode 6 Plate Red 0-255 Plate Red Dimmer Plate Green 0-255 Plate Green Dimmer Plate Blue 0-255 Plate Blue Dimmer No Strobe Plate Strobe 10-255 Strobe from slow to fast 14 Channel mode Channel Name...
  • Page 12 142-183 Tube Macro 4 184-225 Tube Macro 5 226-255 Tube Macro 6 Plate Red 0-255 Plate Red Dimmer Plate Green 0-255 Plate Green Dimmer Plate Blue 0-255 Plate Blue Dimmer No Strobe Plate Strobe 10-255 Strobe from slow to fast Plate Macro Off Plate Macro 1 10-14...
  • Page 13 215-255 Strobe Mode 6 Beam Duration 0-255 Tube Flash Duration 0~3s 0-15 Tube Macro Off 16-57 Tube Macro 1 58-99 Tube Macro 2 Beam Macro 100-141 Tube Macro 3 142-183 Tube Macro 4 184-225 Tube Macro 5 226-255 Tube Macro 6 Plate Red 0-255 Plate Red Dimmer...
  • Page 14: Control Menu

    Plate Pixel 8 Green 0-255 Plate Pixel 8 Green Dimmer Plate Pixel 8 Blue 0-255 Plate Pixel 8 Blue Dimmer 11. Control menu Display: MENU To select the programming functions (press to unlock screen) DOWN To go backward in the selected functions To go forward in the selected functions ENTER To confirm the selected functions...
  • Page 15 Mode 42 Channel Mode 42 channels DMX mode Dimmer Mode 1 Dimmer Mode 2 Dimmer Dimmer Mode 3 Mode Dimmer Mode 4 Dimmer Mode 5 Dimmer Curve 1 Dimmer Dimmer Curve 2 Curve Dimmer Curve 3 Dimmer Curve 4 Tilt 000~255 Tilt Fine 000~255...
  • Page 16: Specification

    Factory Settings RDM UID RDM UID Version Software Version Number System DMX Channel Currently used mode Info Run Time 00:00:00 Total usage time User Time 00:00 The time of use Temperature Current Operating Temperature 12. Specification Strobe Panel LEDs LED Type: 5050 0.5W RGB 3in1 LEDs LED Count: 480 LED Colors: RGB LED Segments: 8 (2 x 4)
  • Page 17 Cooling: Temperature controlled, overheating protection Effects Dimmer: 0-100% electronic Shutter: electronic, max. 20 Hz Internal Effects: LED Macro Effects Connectors Signal connection: Seetronic IP65 XLR 5-Pin or 3-Pin In/Out Power Input: Seetronic powerCON TRUE1 In/Out Operating Condtions Mains voltage: 100-240V AC / 50-60Hz Power: 1000W Maximum ambient temperature: -30°C / 86°F, 50°C / 122°F Operating Position: any...
  • Page 18 Weight N.W: 10 kg G.W: 12.5 kg...
