3.2.2.3 User Agreement
1. Search the product which you will install.
2. Get the agreement of privacy policy for the customer.
3. If the customer agrees the privacy policy, have customer's personal information.
For the RMD's Wi-Fi direct connection, see below.
Search and access the SSID of the RMD AP from a device capable of supporting WLAN
Station functions (ex. smartphone).
RMD SSID has a structure of "RESU_(or RMD) + RMD WLAN STM MAC ADDRESS".
For the devices below, the SSID of the RMD SoftAP is "RESU_44CBXXXC14F(or
RMD44CBXXXC14F)". The password is 12345678(changeable).
When Wi-Fi connection is complete, click the "Next" button.
3.2.2.5 QR Code Scan
The QR code scanning method is as follows.
Select
Prime: Fixed at 2
FLEX: Select from 2 to 4
S/N of consecutive QR
codes are automatically
displayed(Maximun 5)
When the QR code registration is complete, click the "Next" button.
If the scanned serial number matches the actual serial number, it will proceed to the next
section.
There are three (3) QR codes: Battery Control Unit, Battery Module A, and Battery Module B.
Wall Wall
3.2.2.6 External Internet Connection
"Next" button.)
3.2.2.6.1 Ethernet Connection (primary)
Connect the ethernet cable to a router with internet access.
For Ethernet use, it is enough to connect the cable. Since you have already connected the
1. Battery Control Unit QR Code
2. Battery Module QR Code
