STEP
Choose Installation
1
Bathrooms
Water Heater
Basements
Laundry rooms
Sump Pumps
WBTX-319
Location
Kitchens
THIS IS A QUICK GUIDE FOR EXPERIENCED INSTALLERS ONLY. FOR DETAILED INSTALLATION
INSTRUCTION REFER TO DOCUMENTATION FOUND AT WWW.WINLAND.COM
Quick Start Guide
SPECIFICATIONS
• Transmitter:
• Tamper Switch: Included inside transmitter
• Probe Dimensions
• Cord length 6'
• Wireless signal range:
• Transmitter frequency:
• Unique code ID:
• RF Peak eld strength:
• Operating Temperature:
• Relative Humidity:
• Storage Temperature:
• Supervisory keep-alive interval:
• Code outputs: tamper, tamper restore, alarm, alarm
restore, low battery
Batteries: 2 – CR2032. Approximate Battery Life: 5 years
•
Replace Batteries: (2) Panasonic CRT2032, Energizer
CR2032, or Duracell DL2032
2.71" L x .95" W x .56" D
.7" W x 1.77" L x .38" D
600ft (200M), open air
319.5 MHz
typical 36000 uV/m at 3m
32° to 122°F (0° to 50°C)
5 - 95% Non-Condensing
-40° to 140°F (-40° to 60°C)
70 minutes
