- Page 1 Data Storage Unit Manual Ver. 1.7T Model: ETS-DSU-G01A01(0202PPCT02) Enviro Technologies S-12,Top class Enclave, Nr. Bhoidapada bus stop, Sativali Road, Vasai (E), Thane - 401208, Tel: +91 9222243764 Web: www.enviroworld.in...
-
Page 2: History
1. Manual prepare as per Temperature (ETS- DSU-G01A01) Model. 2. Removed Data Storage Type, our device dispatched with fixed data type. 3. Correction in troubleshooting chart. 1.7T 29-10-18 Akshada sanjay 1. Added PID selection menu ETS-DSU- G01A01(0202PPCT02) [ver. 1.7T] Page i... -
Page 3: Table Of Contents
SET STABILIZATION (Optional Factory setting) ..................12 ALARM ACKNOWLED. (Optional Factory setting) ................. 12 PID SELECTION ............................. 13 Printer Remarks ..........................14 ETS-DSU-G01A01(0202PPCT02) Connection Details ..............16 Printer Connection Details ......................16 System Connection Details ......................17 Installation Note ..........................18 Troubleshooting Chart:........................ -
Page 4: Product Selection (Model No.)
ETS-DSU-G01A01(0202PPCT02) (DSU + Display) unit is a new version of ETS-DSU 2.1 Hardware PC & Parallel Printer interface, where display is interfaced with ETS-DSU- G01A01(0202PPCT02) on RS 485 internally. Display consists of 128X64 GLCD display and 4 programming keys, which are used for programming of different display parameters, ETS-DSU- G01A01(0202PPCT02) parameters and also to display the controller parameters. -
Page 5: Operation Keys
2) Memory Alarm massage 3) Stabilization mode(Major enable, Minor enable and stabilization period) At the TOP Display header (settable.) Display Header This is ETS-DSU-G01A01(0202PPCT02) UNIT ID number. This is temperature unit. °C This symbol indicates for connection of Printer. ETS-DSU- G01A01(0202PPCT02) [ver. 1.7T]... -
Page 6: Product Specification And Features
Product Specification and Features Features and Specifications of ETS-DSU G01A01(0202PPCT02) Specifications Description Type : Microcontroller based Electronic device with Printer and 1PID controller Interface. Display : 128 X 64 Alphanumeric Graphical display Keypad : Total 4 Keys Function keys =>SEL, INC, DEC, ENT. -
Page 7: Keypad Functions
14/09/10 12:00 This is used to Access the various parameters of ETS-DSU G01A01(0202PPCT02). To Log In go to Admin Login menu using “SEL” Key and enter ID NO 10 and password value as 1. Now user will have access for setting parameters of ETS-DSU G01A01(0202PPCT02). To log out just go to Admin Login menu once again and press “ENT”... -
Page 8: Display Mode
Sub-Parameter function. Select sub parameter with the help of increment key and press Enter key, Pressing enter key twice will show message as “Select Function”. To exist parameter mode press SEL Key. ENVIRO TECHNOLOGY >> Print Control heck Printer 14/09/10 12:00 ETS-DSU- G01A01(0202PPCT02) [ver. 1.7T] Page 5... -
Page 9: Set Header Page For Print Start
This function is used to print the current values of controllers. “* Printed Current” message will be displayed after activating the parameter. To identify the print current data transaction “.” Dot will be printed after date and time of the transaction. ETS-DSU- G01A01(0202PPCT02) [ver. 1.7T] Page 6... -
Page 10: Reset
ETS-DSU- G01A01(0202PPCT02) Display unit GOTO “Print Control” and Reset all memory by selecting “Reset All Memory” Command and press ENTER. “Data will be lost” message will follow. This is to warn for USER about confirming deleting of all data. If user presses ENTER all data will be deleted, else not. -
Page 11: Print Last
No. OF Last Pages:000 14/09/10 12:00 This function is used for sending command to ETS-DSU-G01A01(0202PPCT02) unit to print old data from ETS-DSU-G01A01(0202PPCT02) transaction buffer. If you select value as zero it will print all available transaction data from ETS-DSU-G01A01(0202PPCT02) transaction buffer. Value more than 0 indicates that how many old pages you want to print. -
Page 12: Print Interval
This function is used to set and display the page length for printing in ETS-DSU- G01A01(0202PPCT02) unit. If page length is set to zero indicates that no page length set and print data continuous. User can set page length from 1 to 255. Press enter key to send page length to ETS-DSU-G01A01(0202PPCT02) unit. -
Page 13: Memory Used Status
ETS-DSU-G01A01(0202PPCT02) Displays Alarm Memory full % continuously whenever ETS-DSU- G01A01(0202PPCT02) is ideal for more then10 seconds. (That is unit Key is not pressed) Also Alx LED of front panel Flashes. To exist Parameter mode press SEL Key. -
Page 14: Setting Date Time
Set time date is used to set and display the time and date of ETS-DSU- G01A01(0202PPCT02) unit. Time and date of display unit is set from ETS-DSU- G01A01(0202PPCT02) unit once system is started. User can change the Time and Date in ETS-DSU-G01A01(0202PPCT02) unit from display unit. User has to use increment key to change the selected parameter of time and date. -
Page 15: Set Stabilization (Optional Factory Setting)
3) Door Open condition 4) Uncertain power failure ALARM ACKNOWLED. (Optional Factory setting) This command is implemented to select Alarm acknowledgment to user. Select the program by incrementing or decrementing key & press Enter key to set. ETS-DSU- G01A01(0202PPCT02) [ver. 1.7T] Page 12... -
Page 16: Pid Selection
Fuji PID PXF4 SET Fuji PID PXF4 14/09/10 12:00 14/09/10 12:00 ENVIRO TECHNOLOGY ENVIRO TECHNOLOGY Enter >> PID Selection… >> PID Selection… SET OMRON PID E5CC OMRON PID E5CC 14/09/10 12:00 14/09/10 12:00 ETS-DSU- G01A01(0202PPCT02) [ver. 1.7T] Page 13... -
Page 17: Printer Remarks
Power Resumed Remark (Unit Reset): Following transaction shows System Restarted because of Unit or Power Reset for Unit with Time –Date & Code 96. 14/09/10 16:09 |********** System Started 119 96 Power Resumed ********** ETS-DSU- G01A01(0202PPCT02) [ver. 1.7T] Page 14... - Page 18 Reset all memory & Delete all Data Those transactions are stored on User interface (Manual reset) using Enviro Keys. Programmable Whole Memory Delete on user demand. Following transactions show all data deleted by user with Time –Date & code 49.
-
Page 19: Ets-Dsu-G01A01(0202Ppct02) Connection Details
5) Connect Alarm to pin no 10 and 11 for Temperature alarm. Printer Connection Details Printer Settings: Printer with Parallel RS-232 Interface - Epson LX series. 1) RED +5V 2) ORNG Printer TX 4) BLK GND 3) BRWN Printer RX ETS-DSU- G01A01(0202PPCT02) [ver. 1.7T] Page 16... -
Page 20: System Connection Details
System Connection Details ENVIRO TECH 25.1 25.0 °C 14/09/10 12:00 25.1 25.0 RS485 Converter Temp ALARM ETS-DSU- G01A01(0202PPCT02) [ver. 1.7T] Page 17... -
Page 21: Installation Note
Installation Note While installing “ETS-DSU-G01A01(0202PPCT02) “, one must take care of following points. All cables connecting to “ETS-DSU-G01A01(0202PPCT02) “must lay separately, they should not mix up with high voltage & high current cables (like Motor; compressor; contactor; Heater etc) ... -
Page 22: Troubleshooting Chart
Following are few troubleshooting point which will guide for rectifying problem while dealing with Enviro Unit. Problem Solutions / Troubleshooting points Display Doesn’t show 1. Check blinking CTx (Enviro trans) and CRx(Enviro reply) for reply from unit to PID on Enviro unit. reading, Check PID unit. Data displays underline.
