- Page 1 Manual Data Storage Unit Ver. 1.5 Model: ETS-DSU- G02A02(0202PPCS02) Enviro Technologies S-12,Top class Enclave, Nr. Bhoidapada bus stop, Sativali Road, Vasai (E), Thane - 401208, Tel: +91 9222243764 Web: www.enviroworld.in...
- Page 2 History Manual Date Author Approved By Remarks Version 31/08/10 Yogesh Prashant 02/11/10 Yogesh / Prashant Set stabilization menu parameter added for Sanjay setting stabilization period acknowledgement alarm mentioned period of time. Fast key response auto increment and decrement Alarm acknowledgement sub menu item added as Major Stabilization and Minor stabilization.
-
Page 3: Table Of Contents
TABLE OF CONTENT History ..............................i Product Selection (Model No.): ......................1 Introduction ............................1 LED Indications ............................1 Operation Keys .............................. 2 Display Massage ............................2 Product Specification and Features ....................3 Keypad Functions ..........................4 ADMIN LOGIN ..............................4 DISPLAY MODE .............................. -
Page 4: Product Selection (Model No.)
ETS-DSU G02A02(0202PPCS02) Graphical/Stability/PID/2Channels Introduction ETS-DSU-G02A02(0202PPCS02)(DSU + Display) unit is a new version of ETS-DSU 2.1 Hardware PC & Parallel Printer interface, where display is interfaced with ETS-DSU- G02A02(0202PPCS02)on RS 485 internally. Display consists of 128X64 GLCD display and 4 programming keys, which are used for programming of different display parameters, ETS-DSU- G02A02(0202PPCS02)parameters and also to display the controller parameters. -
Page 5: Operation Keys
2) Memory Alarm massage 3) Stabilization mode(Major enable, Minor enable and stabilization period) Display Header At the TOP Display header (settable.) This is ETS-DSU-G02A02(0202PPCS02)UNIT ID number. This is temperature unit. °C This is humidity in percentage unit. This symbol indicates for connection of Printer. -
Page 6: Product Specification And Features
Set Decimal Point : To Remove/Set Decimal point Memory Used Status : Display Memory Used Status. Set DSU Number : Set ETS-DSU-G02A02(0202PPCS02) UNIT ID Set Date Time : Set Time and Date for unit. Contrast Control : Set contrast System Info. -
Page 7: Keypad Functions
>> Admin Login Admin User : 00010 Password: 00000 14/09/10 12:00 For any incorrect ID or Password entered, ETS-DSU-G02A02(0202PPCS02)display message “Admin Login Fail…” .If the ID and Password is correct then ETS-DSU- G02A02(0202PPCS02)display message “Admin Login OK” ETS-DSU- [ver. 1.5]... -
Page 8: Display Mode
DISPLAY MODE ENVIRO TECHNOLOGY >> Display Mode Controller No Print Control 14/09/10 12:00 Display Mode is used to select various display formats to display online data. User can use increment and decrement key to select the display mode. Once display mode is set user can press “ENT”... -
Page 9: Set Header Page For Print Start
4.1 Set Header Page For Print Start ENVIRO TECHNOLOGY >> Print Control Set Page Header 14/09/10 12:00 This function is used to set the page header for printing. Printer Header is printed as a beginning of the page. 4.2 Cancel Old Printing This function is used to stop the previous pages under printing. -
Page 10: Reset
4.4 Reset Page No This function is used to reset Page No to 01. ENVIRO TECHNOLOGY >> Print Control Reset Page No 14/09/10 12:00 4.5 Reset Print This function is used to reset stored print data. Warning: Please ensure before executing this function as it may result in losing the print data. -
Page 11: Print Last
PRINT LAST PAGES ENVIRO TECHNOLOGY >> Print Last Pages No. OF Last Pages:000 14/09/10 12:00 This function is used for sending command to ETS-DSU-G02A02(0202PPCS02)unit to print old data from ETS-DSU-G02A02(0202PPCS02)transaction buffer. If you select value as zero will print available... -
Page 12: Print Interval
1 to 255 minutes. Zero time intervals will not get set it will automatically set to 1 minute. Once required parameter is set user can press enter key to send this parameter to ETS-DSU-G02A02(0202PPCS02)unit. To exist Parameter mode press SEL Key. -
Page 13: Memory Used Status
ETS-DSU- G02A02(0202PPCS02)display Unit. This feature will eliminate the need to use adcom.exe to set ETS-DSU-G02A02(0202PPCS02)address from PC. This address can be set from 1 to 16. However you can still set the address using adcom.exe. ENVIRO TECHNOLOGY >> Set DSU Number... -
Page 14: Setting Date Time
G02A02(0202PPCS02)unit once system is started. User can change the Time and Date in ETS-DSU-G02A02(0202PPCS02)unit from display unit. User has to use increment key to change the selected parameter of time and date. Decrement (next) key is used to shift location of time and date parameter feeding. -
Page 15: Set Stabilization
Printer. Select this parameter when only PC-interface in use. SET STABILIZATION This command is implemented to set MAJOR and MINOR STABILIZATION period in minutes range from 0 to 255 minutes by increment or decrementing key. ENVIRO TECHNOLOGY >> Set Stabiliz Major Stabiliz 14/09/10... -
Page 16: Pid Selection
ENVIRO TECHNOLOGY >> Alarm Acknowled. Temperatures ALARM 14/09/10 12:00 PID SELECTION This Menu is implemented to select PID from given selection of 3 PIDS. Select PID with increment decrement key and press enter key to set. ENVIRO TECHNOLOGY ENVIRO TECHNOLOGY >>... -
Page 17: Printer Remarks
On selection of desired PID, set value and process value of corresponding PIDs will be visible on DSU. Two PIDs will be communicating as Temperature and RH respectively. Note: both pids should be of same type with different ID number. There are five setting: Temperatures Alarm This parameter is used to acknowledge and disable Temperature Alarm... - Page 18 ➔ 14/09/10 16:09 |********** System Started 119 96 Power Resumed ********** c) Reset all memory & Delete all Data Those transactions are stored on User interface (Manual reset) using Enviro Keys. Programmable Whole Memory Delete on user demand. Following transactions show all data deleted by user with Time –Date &...
- Page 19 20/12/10 14:14 .| 25.0 26.8 | 45.0 50.5 | Dot indicates “Print Current Data” function was used. Set data storage type To change or set data storage type of Enviro do following steps: 1. Open stability (7.1t or higher version) software. 2. Clicks configure settings.
-
Page 20: Printer Connection Details
8. Click on Update. 9. You will see message as “Enviro Settings Done Successfully!”. Click on OK Button. 10. Click “Set Enviro Type”. click ok. 11 Data type will be set in DSU unit configuration as per after setting data type reset all memory unit through keypad. -
Page 21: System Connection Details
System Connection Details ENVIRO TECH 25.1 25.0 °C 65.2 65.0 % 14/09/10 12:00 25.1 65.2 25.0 65.0 RS485 Converter Temp ETS-DSU- [ver. 1.5] Page 18 G02A02(0202PPCS02) -
Page 22: Installation Note
Installation Note While installing “ETS-DSU-G02A02(0202PPCS02)“ one must take care of following points. • All cables connecting to “ETS-DSU-G02A02(0202PPCS02)“must lay separately, they should not mix up with high voltage & high current cables (like Motor; compressor; contactor; Heater etc) • Use Solid state relay instead of Potential free contact Relay (this will minimizes noise generated during controlling compressor;... -
Page 23: Troubleshooting Chart
Following are few trouble shooting point which will guide for rectifying problem while dealing with Enviro Unit. Problem Probable solutions Display Doesn’t show 1. Check blinking CTx (Enviro trans) and CRx(Enviro reply) for reply reading, from unit to PID on Enviro unit. Data displays underline. Check PID unit.
