Document: 051022-034
Follow the steps below to convert your CR5020 HSRF-500 (USB) to a HSRF-502
(RS232).
Prerequisites
1. Login to Huzzard ABC Tech Support Portal
a.
2. Select the HSRF-500 USB Option
3. Select CR5020 Tab
4. Download Document 051022-03
a. Converting CR5020 HSRF-500 (USB) to HSRF-502 (RS232) – 051022-03
Resetting Scanner
5. Unlocking Scanner
a. If your HSRF-500 reader was purchased after August 2019, Scan this barcode to
b. If your presentation reader was purchased before August 2019, scan this barcode to
If the incorrect unlock code is scanned, the scanner will beep 5 times in error.
If this error is received, attempt scanning the other unlock code.
5517 Waterford Lane, Suite B
January 16, 2023
https://huzzard.com/tech-support/tech-support-500/
1) If you do not have access to the Tech Support portal, contact ABC Fitness
Tech Support for assistance
unlock:
unlock:
•
Appleton, WI 54913
Converting CR5020 HSRF-500
(USB) to HSRF-502 (RS232)
ABC Fitness Tech Support
•
PH 920.257.4357
•
www.Huzzard.com
1
Advertisement
Table of Contents
Related Manuals for Huzzard CR5020 HSRF-500
Summary of Contents for Huzzard CR5020 HSRF-500
- Page 1 Converting CR5020 HSRF-500 (USB) to HSRF-502 (RS232) January 16, 2023 ABC Fitness Tech Support Document: 051022-034 Follow the steps below to convert your CR5020 HSRF-500 (USB) to a HSRF-502 (RS232). Prerequisites 1. Login to Huzzard ABC Tech Support Portal https://huzzard.com/tech-support/tech-support-500/...
- Page 2 Converting CR5020 HSRF-500 (USB) to HSRF-502 (RS232) January 16, 2023 ABC Fitness Tech Support Document: 051022-034 6. Loading Factory Defaults a. Scan the following barcode to load factory defaults i. After scanning, the scanner will beep once, 8-10 second pause, then beep two more times i.
- Page 3 While applying slight pressure with the paperclip, pull the USB cable straight b. A RS232 cable and Power supply for HSRF Scanners is required. This cable and power supply can be purchased through ABC Fitness Procurement from Huzzard c. Plug the Power supply connector into the RS232 cable barrel connector d.
- Page 4 If data is outputting into the Putty Terminal and is comparable to the image above, you have successfully converted your CR5020 HSRF-500 (USB) to a HSRF-502 (RS232), and you are now ready to configure Hardware Services on the connected PC.
