SK Magic
Hot & Cold Water Purifier
Water Purifier
WPUA900C/WPUA800C
WPUA900F/WPUA800F
Before using the product, please thoroughly read the safety precautions in this manual
•
to ensure proper use.
After reading this manual, keep it somewhere where users can readily access it.
•
This product is intended for domestic use only. This product cannot be used in other
•
countries with different power supply and voltage requirements.
The design and appearance of this product are subject to change without prior notice.
•
Cold Water Purifier/
P.N: M510300006 (REV.00)
Advertisement
Table of Contents
Related Manuals for SK magic WPUA900C
Summary of Contents for SK magic WPUA900C
- Page 1 SK Magic Cold Water Purifier/ 수기 Hot & Cold Water Purifier Water Purifier WPUA900C/WPUA800C WPUA900F/WPUA800F Before using the product, please thoroughly read the safety precautions in this manual • to ensure proper use. After reading this manual, keep it somewhere where users can readily access it.
-
Page 2: Table Of Contents
Contents Safety Information Installation Product Features Product Description Control Panel How to Use Filter Replacement Water Purification System Cleaning Before Cleaning Cleaning the Water Collector Cleaning the Exterior Cleaning the Heat-dissipating Fan Cover and Heat-dissipating Fan Troubleshooting Technical Data... -
Page 3: Safety Information
Safety Information The following instructions are intended to provide information on using the product • safely in order to prevent injury or damage, and they must be followed. Safety-related precaution levels are classified as follows, depending on the expected • risk, the magnitude of the damage, and the urgency of the risk situation as a result of incorrect use. - Page 4 Multiple connections to a single power outlet may lead abnormal overheating, which may result in fire. A power outlet without a ground terminal may pose a risk of electric shock due to a • short circuit. Do not install the product outdoors or in a place exposed to direct sunlight, in a place near the bathroom, or in front of an air conditioner or heater.
- Page 5 Avoid allowing water to enter the product. Doing so may result in fire or electric shock. • Do not lean on or hang on the product. Doing so may result in product damage, product failure, or injury. • If the gas (town gas, propane, etc.) leaks, do not touch the product or the power cord. •...
- Page 6 (IH) microwave ovens and electric pressure cookers. Failure to do so may result in electromagnetic interference. • When installing the product, use genuine SK Magic components for installation. Failure to do so may result in water leakage or product damage. (water supply hose, •...
- Page 7 When dispensing hot water, maintain the correct position. Failure to do so may result in burn injuries. • Do not use hot water and auxiliary faucet water at the same time. If auxiliary faucet and hot water are used at the same time, the instant hot water will •...
-
Page 8: Installation
Installation When moving the product, do not tilt it at an angle of more than 45 degrees. Wait at least Wait at least 1 hour to connect the power plug after • 1 hour! transporting the product. Do not move the product while the water purifier is running. -
Page 9: Product Features
Product Features By adopting the direct water process without a water tank, • the product provides fresher, cleaner water. By adopting the instant cooling and heating processes, the Filter • product can continuously supply hot and cold water. Instant cooling Instant cooling module module... -
Page 10: Product Description
Product Description WPUA900C / WPUA800C Front Panel Display / Control Panel Water Dispenser Drip Tray Top Cover Condenser Heat-Dissipating Fan Rear Cover Power Cord Cover Water Supply Auxiliary Faucet Connector Connector NOTE Product images may differ depending on the model. - Page 11 WPUA900F / WPUA800F Front Panel Display / Control Panel Water Dispenser Drip Tray Lower Cover Top Cover Rear Cover Power Cord Water Supply Connector Auxiliary Faucet Condenser Connector...
-
Page 12: Control Panel
Control Panel WPUA900C / WPUA900F WPUA800C / WPUA800F Hot / Button UV Button Ambient Button Ambient Button Cold / Button Cold / Button UV Button 1000 ml Button 1000 ml Button 550 ml Button 120 ml Button 120 ml Button... -
Page 13: How To Use
How to Use Selecting the Amount of Water Select the desired water amount. If the LED over the button is on, no input is • required. After selecting 1000 ml or 550 ml, if there is • no operation for a certain period of time, the setting will automatically change to 120 ml. - Page 14 Dispenser UV Safe Care Function The Dispenser UV Safe Care function operates automatically and periodically, but it can be done manually when desired. How to manually use the Dispenser UV Safe • Care function. When the Dispenser UV Safe Care button is –...
-
Page 15: Filter Replacement
Filter Replacement CAUTION Replace the filter according to the filter replacement cycle. • If the filter replacement cycle is delayed, the amount of purified water or the purification effect will decrease. 1. Close the source water supply valve. 90° Open 90˚... - Page 16 4. After removing the fittings from the filters by using the tool for fitting separation, replace the filters. 5. Assemble the filters, fittings, and filter cover by reversing the removal order. 6. Open the source water supply valve and check for any water leaks in the filter connections.
-
Page 17: Water Purification System
• Doing so may result in fire or electric shock. – Be sure to use genuine SK Magic components (filters/fittings/tubing) and ask a professional • engineer to replace them. Failure to do so may result in product failure or reduce the product life. - Page 18 • Doing so may result in fire or electric shock. – Be sure to use genuine SK Magic components (filters/fittings/tubing) and ask a professional • engineer to replace them. Failure to do so may result in product failure or reduce the product life.
-
Page 19: Cleaning
Cleaning Before Cleaning 1. Close the source water supply valve connected to the water supply pipe of the sink or the ball valve on the back of the product. Lock Open 90° Lock Open 90° Source Water Ball Valve Supply Valve 2. -
Page 20: Cleaning The Exterior
Cleaning the Exterior 1. Use a cleaning agent made exclusively for plastic products, or use a wet cloth, to clean the exterior. (Do not clean the product with thinners, benzene, or alcohol.) Cleaning the Heat-dissipating Fan Cover and Heat-dissipating Fan 1. -
Page 21: Troubleshooting
Troubleshooting Before contacting the customer service center, please check possible cause of the malfunction and the solutions listed below. Malfunction Possible cause/solution There is low power. • Check if the supplied power is 220 - 240 V. If the power is low, adjust the power to 220 - 240 V. Too much water is coming out. - Page 22 (The product is not the customer service center. malfunctioning) The instant hot water is in operation (WPUA900C/WPUA900F). • When hot water is coming out, the cold water is instantly heated. Therefore, the hot water speed may be slower than that of the cold water or ambient temperature water.
- Page 23 The power supply voltage is higher than that of the standard power (AC 240 V) supply may not be appropriate for hot water. using hot water (WPUA900C/WPUA900F) If steam is continuously produced, contact the customer service center. Bubbles are in the instant hot water. (The product is not •...
-
Page 24: Technical Data
Technical Data 511 mm 1,230 mm 500 mm 500mm 465 mm 210 mm 210 mm Model Name WPUA800C WPUA900C WPUA800F WPUA900F Electric Water Electric Water Electric Water Cooler Electric Water Cooler Product Name Cooler (Instant Water Cooler (Instant Water Heater) - Page 25 Cold Water Direct Flow Ambient Tank Capacity Temperature Direct Flow Water Hot Water Direct Flow Step 1 Sediment Filter Filter Type Step 2 Block Carbon Composite Filter Step 3 Nanotech, PAC Filter Purpose of Use Tap Water Purification Usage Home Use Permitted Water 117 ~ 785 kPa (1.2 ~ 7.8 bar)
- Page 26 Note...
- Page 28 매직 냉정수기/냉온정수기 SK Magic Customer Service Center | 1800 18 7878 www.skmagic.com.my Customer Center provide the e-commerce and telephone order sales service for consumables and accessories including dishwasher detergents & conditioners / air cleaner filters / water purifier filters / bidet filters / water softener recycling solution / batteries, burner caps and heads, and tripods for gas cooking stoves and gas oven stoves / oven wares, steam wares, oven gloves, oven grills, and water containers for electric ovens as a part of the customer service.
