Ice-making Water Puri er
( Hot / Cold / Ambient )
WPU-IAC302
Please read the safety precautions in this manual thoroughly before use to ensure safe operation.
•
Please store the manual in a safe location close to the appliance for future reference.
•
The structure and exterior of the appliance may be enhanced for quality improvement without prior notice.
•
M510300023 (REV.01)
Advertisement
Table of Contents
Related Manuals for SK magic WPU-IAC302
Summary of Contents for SK magic WPU-IAC302
- Page 1 Ice-making Water Puri er ( Hot / Cold / Ambient ) WPU-IAC302 Please read the safety precautions in this manual thoroughly before use to ensure safe operation. • Please store the manual in a safe location close to the appliance for future reference.
-
Page 2: Table Of Contents
Contents Safety Information Installation Features Product Description Control Panel How To Use Usage Cautions Operation Method Additional Functions Filter Replacement Water Flow Diagram Cleaning Method Product Exterior and Outlet Drip Tray Ice Outlet Ice Room Cooling Fan and Radiator Grill Troubleshooting Specifications Disposal Guidelines... -
Page 3: Safety Information
Safety Information The following precautions are for the safe and proper usage of this product. Be sure to • follow them to prevent unexpected risks and damage. If used incorrectly, safety-related precautions are classified according to the expected risk, the •... - Page 4 Do not install the product outdoors or in a place exposed to direct sunlight, in a place near the bathroom, or in front of an air conditioner or heater. Do not connect the power cord to any other cable or change the cord at your own discretion. Failure to do so may cause an electric shock or fire.
- Page 5 If the gas (refrigerant) leaks, do not touch the product or the power cord. Immediately open a window for complete ventilation. If water leaks out of the product or is found around the product, immediately close the source water supply valve and remove the power plug from the outlet. Then, contact the customer service center.
- Page 6 Do not use the water collector grill for any purpose other than water collection. To move the product, do not pull the power cord or connection hose or hold the ice spout. This may result in product damage. • Do not leave the product in subzero conditions. This may result in malfunction or product failure.
-
Page 7: Installation
Installation Where to Install Install the product on a solid and even surface at least 10 cm away • from the wall. 10cm After Installation When newly installed or relocated, connect the power only after 30 • minutes have elapsed. Drain Hose Connection When connecting the drain hose, ensure that the hose is not bent or •... -
Page 8: Features
Features Slim size (width 255mm) to maximise kitchen space. • Vast ice production, ice storage and water dispense volume despite its • slim size. Periodic water tab and ice room UV Care for hygienic usage and • maintenance. Tankless instant cooling method using ice thermal storage for cleaner •... -
Page 9: Product Description
Product Description Front Control Panel Ice Dispense Button Water Dispense Button Ice Outlet Water Tab Drip Tray Top Cover Side Cover... - Page 10 Back Rear Cover Power Socket Water Inlet Hose Faucet Inlet Hose Radiator Grill Drainage Outlet Hose Accessories User Manual Filter Connectors (4 PCS)
-
Page 11: Control Panel
Control Panel WPU-IAC302 UV Care Button Lock Button Hot Water Button Ambient Water Button Cold Water Button Volume Control Button Ice Full Display Ice Dispense Button Water Dispense Button Buttons and Indicators Name Description Displays the UV Care operation status. - Page 12 Name Description Use this button to select hot water temperature settings. • Each time the [Hot] button is pressed, the temperature will change in the following order : Hot Infant. Press and hold for 5 seconds to change the infant water temperature. •...
-
Page 13: How To Use
How To Use Usage Cautions CAUTION Close the lid of the ice room after cleaning. • If the lid of the ice room is not properly closed, insects such as ants may enter the ice room. If the touch button does not function when touched, try using your thumb to widen the •... - Page 14 Selecting water temperature Select the desired water temperature. If the indicator light is switched on for the • desired temperature, you do not need to press the button. The colour of the indicator light changes • according to the water temperature selected.
-
Page 15: Additional Functions
Additional Functions UV Care How to activate the Manual UV Care • function. Press the [UV Care] button once to activate manual UV Care when the [UV Care] button indicator light is OFF. The indicator light is ON when automatic or •... - Page 16 Adjusting brightness of water/Ice Dispense Button Press and hold the [Ambient] button for 5 seconds. The [Ambient] button indicator light blinks • with a beep sound. Each time the [Water Dispense] button is • pressed, the brightness will change in the following order : Off High Low.
- Page 17 Lock Function On/Off : Cold, Hot, Ice Press and hold the [Lock] button for 5 seconds. The indicator lights of the functions that • can be locked (Cold/Hot/Ice) starts blinking with a beep sound and indicator lights of the functions that are already locked switches OFF.
-
Page 18: Filter Replacement
Filter Replacement CAUTION Replace the filter according to the recommended replacement cycle. • The purification volume and effect may be reduced when filter is not replaced promptly. Ensure that the power plug is unplugged when replacing the filter. • There is a risk of electric shock if you touch the power plug with wet hands. 1. - Page 19 4. After removing the fittings from the filter to be replaced, replace the new filters. (use a proper tool for the separation) 5. Assemble the filters, fittings and filter cover in the reversed order. 6. Open the water supply valve and check the Open filter connectors for leaks.
-
Page 20: Water Flow Diagram
The water purification system is composed as shown in the illustration below. CAUTION Do not disassemble the product at your own discretion. • Failure to do so may cause fire or an electric shock. WPU-IAC302 Ice water 90° Water intake NOS Valve... -
Page 21: Cleaning Method
Cleaning Method Before Cleaning 1. Close the source water supply valve Open connected to the water supply pipe of the 90° sink or the ball valve on the back of the Lock product. Source Water Supply Valve Lock 90° Open Ball Valve 2. -
Page 22: Product Exterior And Outlet
Product Exterior and Outlet 1. Use a cleaning agent made exclusively for plastic products, or use a wet cloth, to clean the exterior. CAUTION Do not clean the product with thinners, • benzene, or alcohol. 2. After wiping the water outlet with a wet cloth, remove moisture with a dry cloth. -
Page 23: Ice Outlet
Ice Outlet 1. Pull out the ice outlet guide according to the direction of the arrow as shown in the image. 2. Wash the separated ice outlet guide with running water until there are no foreign substances left. 3. Remove the ice outlet cover in the order shown in the figure. -
Page 24: Ice Room
Ice Room 1. Remove the top case by pushing it in the direction of the arrow as shown in the image. 2. Remove the ice room cover by lifting the marked part in the direction of the arrow with a screwdriver or a long tool such as chopsticks. -
Page 25: Cooling Fan And Radiator Grill
Cooling Fan and Radiator Grill 1. Remove the dust filter for the cooling fan at the rear of the product by pulling the handle upwards. 2. Clean the front and back of the dust filter thoroughly under running water. Dry the dust filter before reassembly. •... -
Page 26: Troubleshooting
Troubleshooting If you encounter a problem with the appliance, first check the table below and try the suggestions. If the problem persists, please contact the Customer Service Center. Problem Action Cold water function is switched OFF • If the cold water indicator light is switched ON, press and hold the [Lock] button for 5 seconds to check whether the cold water function has been switched OFF. - Page 27 Problem Action Ice dispense sound I hear loud noises from • the product. This is a normal sound that occurs when the refrigerant circulates (Air leaking sound) to drop the produced ice to the ice room. Check whether the water supply valve or the middle valve (blue •...
- Page 28 Problem Action Excessive usage of ice • There may be no ice left in the ice room due to excessive usage of ice. Ice making function is switched OFF • If the lock indicator light is ON, press and hold the [Lock] button for 5 seconds to check whether the ice function is switched OFF.
- Page 29 Problem Action The voltage is too high (The product is not malfunctioning) • If the voltage is higher than the standard supply power of If steam is sprayed AC220-240V, hot water usage may not be suitable. while using hot water. If steam is continuously produced, contact the Customer Service Center.
-
Page 30: Specifications
512mm 492mm 255mm Electric Cold Water Dispenser Product Name (Instant Water Heater and Ice Maker combined) Model WPU-IAC302 Net Weight 18.5 kg Dimensions (W x D x H) 255 × 512 × 492 mm Rated Voltage AC 220-240V, 50 Hz... - Page 31 - step Sediment filter Filter - step Carbon Block filter - step Nanotech PAC filter Effective Capacity 1,200 L Purpose of Use Tap water purification Suited Usage For home use Ice Storage Capacity 0.75 kg Operating 117 – 785 kpa (1.2 – 7.0 bar) Pressure Conditions Operating...
-
Page 32: Disposal Guidelines
Charged Disposal 1. If you did not purchase a new SK magic product and want to dispose your existing product, you may contact your local waster management center for disposal. 2. SK magic provides chargeable product disassembly services for your convenience. - Page 33 Note...
- Page 34 Note...
- Page 35 Note...
