PFP-38hpKHL-2D
Congratulation, you have just purchased a C.E.T. portable pump. If you follow the procedures in this
operation manual, it will give you years of use without any problems.
ENGINE SPECIFIC TIONS
• Kohler 38hp at 3600 RPM, air cooled engine.
• 3-cylinder, 4-stroke gasoline engine.
• 12V electric start.
• 6 gallon (22 l) capacity fuel tank.
PUMP UNIT SPECIFIC TIONS
• C.E.T. is using the new technology of a dual stage centrifugal pump.
• Pump body made from resistant aluminum alloy.
• Bronze impellers.
• Mechanical shaft seal.
• Stainless steel pump shaft.
• Exhaust priming system, guaranteed up to 20' (6 meter) lift.
• Two 2 1/2" (65 mm) delivery outlets.
• One 4" (100 mm) suction inlet.
• Dimensions : Length : 37" (940 mm); Width : 26" (660 mm); Height : 31" (787 mm).
• Weight : 275 lbs (125 kg).
CONTROL P NEL
• Engine start/stop button.
• Throttle control lever.
• Choke control lever.
• Oil control lamp.
• Operating panel light.
• Pressure gauge.
• Vacuum pressure gauge.
PERFORM NCE
600 GPM (2268 LPM)
@
480 GPM (1814 LPM)
@
375 GPM (1718 LPM)
@
300 GPM (1134 LPM)
@ 100 PSI
140 GPM (529 LPM)
@ 150 PSI (10.3 bar)
Your pump comes with a full year warranty on all mechanical components.
ACCEPT ONLY THE BEST
25 PSI
(1.7 bar)
50 PSI
(3.5 bar)
75 PSI
(5.2 bar)
(6.9 bar)
75 Hector St., P.O. Box 90, Pierreville (Québec) Canada J0G 1J0
A C E N T U R Y O F E N G I N E E R I N G F O R T H E B R AV E S T
INSTRUCTIONS M NU L
Telephone: 1-800-567-2719
Fax: 1-800-434-2613
www.fire-pump.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CET PFP-38hpKHL-2D
Summary of Contents for CET PFP-38hpKHL-2D
- Page 1 PFP-38hpKHL-2D INSTRUCTIONS M NU L Congratulation, you have just purchased a C.E.T. portable pump. If you follow the procedures in this operation manual, it will give you years of use without any problems. ENGINE SPECIFIC TIONS • Kohler 38hp at 3600 RPM, air cooled engine.
- Page 2 PFP-38hpKHL-2D INSTRUCTIONS M NU L ND DONTS Do… • Read your owner’s manual • Close your drain valve on the pump casing before starting the engine • Seal up any air that could leak into the suction side • Charge you battery at least once every three months •...
- Page 3 IMPORT NT NOTICE - FRESH W TER FLUSH FTER EVERY USE After Operating a CET Pump, it is critical to FRESH WATER FLUSH the pump at the end of use before restoring it as a good damage control practice. If the pump has been used to pump seawater, the seawater must be drained from the pump by opening the pump casing drain valve.
- Page 4 INTERPRETATION CET shall not be liable for transportation charges either in shipment to or by it and shall not be liable for loss of use, or consequential damage of any kind in connection with the sales, alteration, repair or replacement of any equipment or part thereof. Liability under this warranty is limited to replacement or repair and in any event shall not exceed the purchase price paid.
