Seafloor HydroCat-180 TARANIS X7 Start-Up

AutoNav
Up: Manual Mode
Down: Auto Mode
AutoNav
Up: Arm
Down: Disarm
Power: ON/OFF
Start Up
Center all switches and joysticks.
1
Hold Power button until all four loading
2
process dots appear on the screen.
If Switch Warning appears, make sure all
3
switches are turned off or centered
(Winch Knob center), auto switch is set to
Manual and arming is set to Disarm.
Seafloor Systems, Inc.
TM
TARANIS X7 Controller
HydroCat-180™
info@seafloorsystems.com
Winch Control Knob
Left

Arm HydroCat-180

To arm the HydroCat's AutoNav move
1
arming switch to arming position then
hold arming toggle switch up for 3
seconds. You will hear the HydroCat
AutoNav chime when arming is complete.
To Disarm, switch the Arm switch to
2
Disarm and hold arming safety switch
for 3 seconds. The AutoNav will chime
when disarmed.
Arming Safety
Switch
Pole Actuator
Up: Recover
Down: Deploy
Forward
Right
Reverse
1 (530) 677 - 1019
