IXOM SolarBee SB7500LH Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SolarBee SB7500LH
(High Wave)
Owner's Manual
©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com
©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com
O&M_SB7500LH_10197_20221221

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SolarBee SB7500LH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IXOM SolarBee SB7500LH

Summary of Contents for IXOM SolarBee SB7500LH

  • Page 1 SolarBee SB7500LH (High Wave) Owner's Manual ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com O&M_SB7500LH_10197_20221221...

  • Page 2: Table Of Contents

    SolarBee SB7500LH (High Wave) Owner's Manual Safety Operation Features Assembly Maintenance Electrical Troubleshooting Parts Diagram Dimension Drawing Appendix Technical Specifications Warranty Service Program Customer Service ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10014_20221213 O&M_SB7500LH_10197_20221221...

  • Page 3: Safety

    Most accidents can be avoided by using common sense and concentration on the job being done. Carefully read safety information when you see any safety symbols. ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 1949_10036_20221213 O&M_SB7500LH_10197_20221221 - 1...
  • Page 4 CAUTION: EDGES MAY BE SHARP AND CAUSE WARNING: ICE SURROUNDING MACHINE MAY LACERATION IF PROPER CARE IS NOT USED. NOT SUPPORT WEIGHT, KEEP CLEAR OF THIN ICE. ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 1949_10036_20221213 O&M_SB7500LH_10197_20221221 - 2...
  • Page 5 "OFF" position. The On/Off switch is to be their own safety and health programs approved by OSHA. used as the emergency stop. ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 1949_10036_20221213 O&M_SB7500LH_10197_20221221 - 3...

  • Page 6: Operation

    In severe sunlight limited conditions, the machine may slow Flow Coming Off Distribution Dish down or stop temporarily to protect the battery from damage. ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10199_20221220 O&M_SB7500LH_10197_20221221 - 4...

  • Page 7: Features

    PV modules (following winter conditions, the PV modules 55 Degree should be returned to their original position to maximize solar energy collection). ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10258_20221220 O&M_SB7500LH_10197_20221221 - 5...
  • Page 8 Battery Compartment Onboard Battery ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10258_20221220 O&M_SB7500LH_10197_20221221 - 6...
  • Page 9 Left Side Face Of Digital Controller ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10258_20221220 O&M_SB7500LH_10197_20221221 - 7...
  • Page 10 The connectors are indexed to prevent Durable Wiring And Connectors improper wiring. A general electrical schematic can be found in the Maintenance and Field Adjustment section. ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10267_20221220 O&M_SB7500LH_10197_20221221 - 8...
  • Page 11 The upper Lower Coupling coupling remains attached to the brushless motor while the lower coupling and coupling sleeve remain on the impeller shaft. ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10267_20221220 O&M_SB7500LH_10197_20221221 - 9...
  • Page 12 The impeller bushing aligns and centers the impeller shaft within the machine. Impeller Hub Impeller Bushing Block ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10267_20221220 O&M_SB7500LH_10197_20221221 - 10...
  • Page 13 2 in to 2 1/2 in (5.1 cm to 6.4 cm) 10000 2 in to 2 1/2 in (5.1 cm to 6.4 cm) ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10267_20221220 O&M_SB7500LH_10197_20221221 - 11...
  • Page 14 Hose and Strainer Configuration - MODEL MAY VARY SB2500 SB5000 SB7500 SB10000 GF2500 GF5000 GF7500 GF10000 ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10267_20221220 O&M_SB7500LH_10197_20221221 - 12...
  • Page 15 2 in to 2 1/2 in (5.1 cm to 6.4 cm) 10000 2 in to 2 1/2 in (5.1 cm to 6.4 cm) ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10267_20221220 O&M_SB7500LH_10197_20221221 - 13...
  • Page 16 • Avoid being crushed by ice pressure. • Provide extra buoyancy when needed without going much deeper into the water. Float ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10267_20221220 O&M_SB7500LH_10197_20221221 - 14...

  • Page 17: Assembly

    THE GROUND OR SAFELY SUPPORTED TO RELIEVE THE FORCES ON THE FLOAT ARM AND TURNBUCKLE STRUCTURES PRIOR TO DISASSEMBLY! FAILURE TO FOLLOW THIS WARNING COULD LEAD TO SINKING THE SOLARBEE, OR CAUSE SERIOUS INJURY! ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10207_20221220 O&M_SB7500LH_10197_20221221 - 15...
  • Page 18 ALL SB2500 ALL SB2500 ALL POTABLE WATER UNITS ALL POTABLE WATER UNITS ALL HIGH SALINITY (SALTWATER) APPLICATIONS ALL HIGH SALINITY (SALTWATER) APPLICATIONS ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10207_20221220 O&M_SB7500LH_10197_20221221 - 16...
  • Page 19 Be certain that the float and chain are orientated as shown. STEP 6: Repeat Steps 1 through 5 for the other two floats. ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10207_20221220 O&M_SB7500LH_10197_20221221 - 17...
  • Page 20 M12 90mm Bolt and tighten the Nylok nut. STEP 6: Repeat steps 2 through 5 for each turnbuckle assembly. ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10207_20221220 O&M_SB7500LH_10197_20221221 - 18...
  • Page 21 13mm wrenches. STEP 5: Repeat steps 3 and 4 for the other 2 chain brackets. Applying Anti-Seize To The Bolts ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10207_20221220 O&M_SB7500LH_10197_20221221 - 19...
  • Page 22 Machine can rest on. Securing Clevis Pins Secured with Hair Pins ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10207_20221220 O&M_SB7500LH_10197_20221221 - 20...
  • Page 23 STEP 6: Repeat steps 2 through 5 for each Marker chain slipped into chain bracket slot. marker chain. Machine equpped with 3 marker chains. ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10207_20221220 O&M_SB7500LH_10197_20221221 - 21...

  • Page 24: Maintenance

    To completely power down the digital controller, remove all power sources in the proper sequence. DIGITAL CONTROLLER ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10139_20221220 O&M_SB7500LH_10197_20221221 - 22...
  • Page 25 Once the air is released, the hose WARNING COULD LEAD TO SINKING THE will lower down into place. MACHINE, OR CAUSE SERIOUS INJURY! ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10263_20221220 O&M_SB7500LH_10197_20221221 - 23...
  • Page 26 STEP 4: Double check dish level at all three locations and fine tune as necessary. Dish Depths For Different Models of machines ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10422_20221220 O&M_SB7500LH_10197_20221221 - 24...
  • Page 27 Minute (RPM) # Seconds Expired RPM = (30 revolutions X 60) / (30 seconds) = 60 Impeller Rotational Speed = 60 RPMs ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10413_20221220 O&M_SB7500LH_10197_20221221 - 25...
  • Page 28 If there is buildup below the impeller, then see directions for impeller removal on the next page. Impeller Removal For Buildup Below Impeller ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 2090_10257_20221220 O&M_SB7500LH_10197_20221221 - 26...
  • Page 29 STEP 6: Place clevis pin back through upper shaft coupling and secure with hair pin. STEP 7: Close PV module gate and turn Machine back Impeller Assembly Removed ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 2090_10257_20221220 O&M_SB7500LH_10197_20221221 - 27...
  • Page 30 (The steep angle will help prevent STEP 4: Repeat steps 1 through 3 for other two snow from building up on the panels). solar panels ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 2091_10265_20221220 O&M_SB7500LH_10197_20221221 - 28...
  • Page 31 STEP 3: Remove any streaks or films using glass cleaner and paper towel/wash cloth. STEP 4: Repeat Steps 1 through 3 for each solar panel. ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10412_20221220 O&M_SB7500LH_10197_20221221 - 29...
  • Page 32 STEP 5: Lift the chain up until the strainer is at the desired setting and tie off to the float plate. Strainer Chained Up, Not Free Floating ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 2059_10262_20221220 O&M_SB7500LH_10197_20221221 - 30...
  • Page 33 Vary on the amount of garbage and debris you find. Strainer STEP 5: Turn Mixer back on. Strainer Hose And Chain ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 2059_10262_20221220 O&M_SB7500LH_10197_20221221 - 31...
  • Page 34 Close panel gate, and reset dish depth. * * Failure to follow these steps could result in component damage. * * Battery Lid Down, Battery Lead Out ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 2087_10268_20221220 O&M_SB7500LH_10197_20221221 - 32...
  • Page 35 Stay clear of sinking anchor chain! RESULT IN SERIOUS INJURY OR DEATH BY DROWNING! STEP 6: Lower the strainer back down. ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 2080_10247_20221220 O&M_SB7500LH_10197_20221221 - 33...
  • Page 36 SolarBee Completely Froze In ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 2080_10247_20221220 O&M_SB7500LH_10197_20221221 - 34...

  • Page 37: Electrical

    Outside of Reservoir Outside of Reservoir (Inside Low Profile) (Inside Low Profile) Motor Inside of Reservoir Motor Power and SCADA Signals Motor Controller ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 1148_10154_20221220 O&M_SB7500LH_10197_20221221 - 35...
  • Page 38 Please refer to the provided owners manual for normal operation led blink codes. SD Card Slot Blinking LED’s Blue Blue YELLOW YELLOW GREEN GREEN SCADA Serial Connection Brain Board Serial Number Figure 1: Brainboard ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 866_10042_20221213 O&M_SB7500LH_10197_20221221 - 36...
  • Page 39 STEP 5: Connect all available PV module leads into the front face of the digital controller. STEP 6: Turn the On/Off switch to On position. MOTOR CONTROLLER ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 2057_10138_20221220 O&M_SB7500LH_10197_20221221 - 37...

  • Page 40: Troubleshooting

    SolarBee's various SCADA kits. Contact Ixom Watercare, Inc. Customer Service for more information. 12 VDC+ 12 VDC- ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 2053_10238_20221220 O&M_SB7500LH_10197_20221221 - 38...
  • Page 41 Check and record battery voltage if possible, then contact SolarBee Customer DIGITAL CONTROLLER Service. For all other blink codes, please contact SolarBee Customer Service. ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 2053_10238_20221220 O&M_SB7500LH_10197_20221221 - 39...
  • Page 42 Below is the detailed Fallback RPM chart, based on battery voltage and percentage of commanded or scheduled run speed, typically programmed for full speed of 80rpm. ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10441_20221220...
  • Page 43 Zahn Board Green LED 12 VDC to Zahn No Power to Zahn PV Panel Motor MCC Connection PV Panel Battery Connection Connections ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10575_20221220 O&M_SB7500LH_10197_20221221 - 41...

  • Page 44: Parts Diagram

    PN: 20014500 14” Brushless Motor PN: 24240105 Float PN: 14285212 Battery Assembly PN: 26012420 24” x 20’ Hose PN: 26284024 Intake Strainer Assembly ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 2037_10205_20221220 O&M_SB7500LH_10197_20221221 - 42...

  • Page 45: Dimension Drawing

    Dimension Drawing SB7500LH Dimension Drawing High Wave ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 2038_10209_20221220 O&M_SB7500LH_10197_20221221 - 43...

  • Page 46: Appendix

    Appendices Appendix Additional Component Information Technical Data Sheets ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10576_20221220 O&M_SB7500LH_10197_20221221 - 44...

  • Page 47: Technical Specifications

    • Crate - 87in x 87in x 65in (2.2m x 2.2m x 1.7m) / 1500lbs (680kg) Exact weight and dimensions varies dependent on machine configuration. Maintenance / Warranty - Minimal maintenance. Limited 2-year parts and labor warranty. Patent Pending Subject to change without notice. ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 2036_10204_20221220 O&M_SB7500LH_10197_20221221 - 45...
  • Page 48 16 inch X 13 inch X 11 inch, 16 lbs Figure 2: SB A-Series Control Panel, Internal Warranty Reference SB Limited Replacement Warranty. ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 2139_10473_20221220 O&M_SB7500LH_10197_20221221 - 46...
  • Page 49 Electrical Technical Data Sheet SB Series A-Box Wiring Schematic ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 2139_10473_20221220 O&M_SB7500LH_10197_20221221 - 47...
  • Page 50 20 Amp Aux. Out Aux. Out SCADA SCADA 36 VDC 36 VDC Converter Converter +36VDC 5 Amp -36VDC 5 Amp -36VDC +36VDC ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 1936_10519_20221220 O&M_SB7500LH_10197_20221221 - 48...
  • Page 51 Figure 2: SB B-Series Control Panel, Internal 16 inch X 13 inch X 11 inch, 16 lbs Warranty Reference SB Limited Replacement Warranty. ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 2140_10474_20221220 O&M_SB7500LH_10197_20221221 - 49...
  • Page 52 Electrical Technical Data Sheet SB Series B-Box Wiring Schematic ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 2140_10474_20221220 O&M_SB7500LH_10197_20221221 - 50...
  • Page 53 36VDC Power Supply 6 Amp + 120VAC (L) -120VAC (N) 85 ~ 264VAC 85 ~ 264VAC 47 ~ 63Hz 47 ~ 63Hz ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 10593_20221220 O&M_SB7500LH_10197_20221221 - 51...
  • Page 54 SolarBee Monitoring Setup Information The SolarBee is a modbus RTU slave device with a factory programmable slave ID. The ID can be changed in the field with a properly programmed SD card. Contact Ixom Watercare, Inc. Customer Service for assistance. Serial Interface...
  • Page 55 The current that is input to the controller via the solar array or shore power connections. The unit for this value is Amps. The value is scaled using this formula: value / 10. ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 803_10196_20221220 O&M_SB7500LH_10197_20221221 - 53...
  • Page 56 Technical Data Sheet SolarBee Standard SCADA Output Requires Attention: Refer to SolarBee O&M Troubleshooting section or call Ixom Watercare, Inc. Customer Service at 866-437-8076 ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 803_10196_20221220 O&M_SB7500LH_10197_20221221 - 54...
  • Page 57 GPS Comm, Charge Controller Comm, Motor Comm, and Analog OOR Error For Customer Service, contact Ixom Watercare, Inc. Main Office and Service Center at 866-437-8076. ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 2075_10326_20221220...
  • Page 58 5V supply < Analog 5V Monitor Lower Limit (4.5V) or 5V supply < Analog 5V Monitor Upper Limit (5.5V) Priority 10 5X Yellow GPS Unit not communicating properly ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 2076_10325_20221220 O&M_SB7500LH_10197_20221221 - 56...
  • Page 59 Environment -40 to 140 F, freeze resistant, 100% humidity, splash and condensation resistant Shipping Size/Weight • 16” x 16” x 9”, 80lbs. Maintenance / Warranty - No routine maintenance. Limited 2-year parts and labor warranty. ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 1255_10063_20221214 O&M_SB7500LH_10197_20221221 - 57...
  • Page 60 @ 25° C (77° F) to 1.75 Volts per cell 24 Hr Rate: 212Ah 48 Hr Rate: 235Ah 72 Hr Rate: 244Ah ©2023 IXOM Watercare Inc. | www.ixomwatercare.com | 866 - 437 - 8076 | watercare@ixom.com 1566_10065_20221214 O&M_SB7500LH_10197_20221221 - 58...

  • Page 61: Warranty

    Where labor is included, in lieu of sending a factory service crew to the site for minor repairs, Ixom may choose to send the replacement parts to the owner postage-paid and may pay the owner a reasonable labor allowance, as determined solely by Ixom, to install the parts.

  • Page 62: Service Program

    Protect Your Investment With The Ixom Service Program Comprehensive Damage Repair Damage which occurs to your Ixom manufactured equipment in the normal course of operation will be repaired or replaced including supply and installation of structural repairs and replacement parts in accordance with Ixom’s standard terms &...

  • Page 63: Customer Service

    © Distribution Treatment, Wastewater Treatment and Lakes & Source Water Reservoirs. Ixom has thousands of installations and is an industry-leader solving water quality problems across the United States, Canada and the world. Contact us today to discuss your water quality and service needs.
