    Introduction Firstly, congratulations on your purchase of the ICON Pro Audio P1-M MIDI DAW controller! In these pages, you'll find a detailed description of the features of the P1-M and a full list of specifications. Please register the product on our website at the link below www.iconproaudio.com/registration...

  • Page 5: Register Your Icon Pro Audio Product To Your Personal Account

    Register your ICON Pro Audio product to your personal account 1. Check the serial number of your device Please go to http://iconproaudio.com/registration or scan the QR code below. Input your device’s serial number and the other information on the screen. Click “Submit”.

  • Page 6: Features Pt. 1

    PAN knobs. With the P1-M, you can now connect up to three DAWs at the same time! If your main project is in, say Pro Tools, but you need to quickly shoot back to Cubase - no problem! The P1-M will allow this to happen literally at the touch of a button without any delay or fuss, which means no interruption to you or your workflow.

  • Page 7: Features Pt.2

    Features Pt.2 ● 8x touch-sensitive motorized faders with 12-bit resolution ● Programmable 4 inch, 16 panel digital touch screen display showing DAW functions per 5 color modes - a potential total of 80 displayable and actionable functions per ● Organize DAW functions in the 16 panel touchscreen easily via 'drag and drop' in the iMAP - changes made in real time ●...
  • Page 8 ● iMap software included ● USB C high-speed connectivity ● Firmware upgrade available via USB C connection and iMap software ● User A & User B 1/4 inch inputs for connecting footswitch pedals ● Class-compliant with MacOS 10.15 or above & Windows 10 or above ●...

  • Page 9: Top Panel Layout

    Top Panel Layout NOTE: The P1-M is a universal DAW controller (i.e. not designed for one specific DAW). Functions will operate slightly differently between DAWs. Please refer to your DAW manual for each function. 1. Faders The eight ergonomically designed, motorized faders are generally used for controlling the track volume of the DAW.
  • Page 10 2b) Motorized fader control buttons section Fader left button - Shift “one” channel down for all faders Fader right button - Shift “one” channel up for all faders BANK left button - Shift “one” channel up for all faders BANK right button - Shift “one” channel up for all faders 3.
  • Page 11 Trim - Trim function enabled/disabled Off - Off function enabled/disabled As the P1-M is a universal controller, these will illuminate or not depending on your DAW. For example, in Cubase, the latter four buttons will not illuminate, whereas in Bitwig, the latter two will not illuminate. This is part of the intelligent...
  • Page 12 Select the DAW you would like to connect to, by selecting DAW buttons 1-3. The DAW must be set up and configured previously, (see Getting Started with the P1-M). You may change which DAWs you connect to in the iMAP, (see 'How to Allocate the DAWs to the DAW Buttons').
  • Page 13 12. Lock Pressing this button will ensure that the units faders do not change regardless of the movement of the physical fader. The user must press this button to 'unlock' the channel in order to affect a change. If using P1-X extenders, the Lock button will communicate in real time via the iMAP - which acts as a 'bridge' between the units - faders on the P1-X will be similarly affected.

  • Page 14: Rear Panel Layout

    DAW. 3. 12V/2.5A power adapter port Connect the power adaptor provided, here. (Note: the P1-M is not able to work without the provided power adaptor connected. USB bus power from a computer is insufficient). 4. D4T display unit connector Connect your optional D5 display module to this connector with the provided cable.

  • Page 15: Getting Started With The P1-M

    1. Connect the P1-M to your Mac/PC via the USB C port Choose a USB port on your Mac/PC and insert the USB C cable. Connect the cable’s other end to the P1-M. Switch on! Your Mac/PC should automatically “detect” 16 panel ke the new hardware.

  • Page 16: How To Allocate Daws To The Daw Buttons In The Imap

    So, you've downloaded, installed and opened the iMAP. You will see the three DAW buttons on top of the iMAP. These correspond to the three DAW buttons on the P1-M. Simply select the corresponding button of choice and select a DAW from the drop down list.
  • Page 17 P1-M, we will need to select 'MIDIIN2 (P1-M V1.02)' or whichever firmware version it is*) in the menu. When the P1-M is set up as a Mackie control device in Cubase, whenever we press '2' in the DAW Controller selection section, the P1-M will automatically select Cubase.
  • Page 18 Cubase's MIDI Remote Manager. Regardless of the supported DAWs you are using, the principle will be largely the same. Now, we've covered how we allocate DAWs to the P1-M DAW button of your choice (1- 3) in the iMAP and, in principle, how to configure the DAW to the corresponding MIDI port, (as depicted above), let's move on to configuring our DAW/s in the next section.
  • Page 19 On a day-to-day basis, Fernando uses Cubase as his 'go to' DAW to record. He has set up his template which he loads into Cubase and he has also set up the touchscreen on his P1-M to load all of his favorite Cubase commands when pressing DAW button #1, when recording and mixing.

  • Page 20: Launching The P1-M In Every Day Use

    - this ensures that the speed of communication is fast and unhampered by secondary factors. Additionally, the iMAP acts as a kind of 'bridge' between the P1-M main unit and any P1-X extenders you may be using and ensures cohesion. The 'Lock' function, when used in conjunction with a P1-X extender unit for example, will work as expected.

  • Page 21: Installing Imap For The Mac

    After you downloaded the file, please click it to start the installation process. The iMAP will also be available on the product page at www.iconproaudio.com Tip: By “dragging and dropping” the “P1-M” icon into the “Applications” folder, you can create an “iMap” shortcut on your Mac’s desktop. P1-M K7iK3rIE The latest iMap for MacOS V1.00...
  • Page 22 P1-M P1-X iMap P1-M P1-X iMap Installer 3. Click “Continue”. P1M_P1X_iMap P1-M P1-X iMap _Mac_Setup_V1.00. V1.00.pkg P1-M P1-X iMap P1-M P1-X iMap P1-M P1-X iMap Installer 4. Read the license P1-M P1-X iMap agreement. Click “Continue”. P1M_P1X_iMap P1-M P1-X iMap _Mac_Setup_V1.00.
  • Page 23 P1-M P1-X iMap P1-M P1-X iMap 7. Enter your username and password. Click P1-M P1-X iMap P1-M P1-X iMap “Install software” P1-M P1-X iMap 8. Click “Close” after P1-M P1-X iMap P1-M P1-X iMap installing your iMAP software. 9. Click on the shortcut to launch the...

  • Page 24: Installing Imap Tm For Windows

    User Center at www. iconproaudio.com After you download the file, please click it to start the installation process. P1-M P1-X iMap V1.00 Installation P1-M P1-X iMap V1.00 Installation 3. The Setup Wizard will appear M P1-X iMap. Setup wizard appears, please click “Next”...
  • Page 25 P1-M P1-X iMap V1.00 Installation M P1-X iMap. M P1-X iMap. Please uncheck the box if you do not P1-M P1-X iMap V1.00 Installation want to place a shortcut icon on your P1-M P1-X iMap M P1-X iMap M P1-X iMap. desktop for iMap ;...

  • Page 26: The Imap

    The iMAP The intelligent design of the new, highly advanced iMap means that users can make changes in real time - no need for 'sending data'. Users can load three DAWs of their choice via the three buttons at the top of the iMAP. Simply click and load the DAW of your choice via the drop down box for each of the three buttons 1, 2 and 3.
  • Page 27 Now, Bitwig mode has loaded along with all of it's functions. In the same way, let's load Cubase for button 2 and Logic for button 3. You will see these reflected in the buttons 1, 2 and 3 in the iMAP.
  • Page 28 This would usually require the use of a mouse to select the subsequent option. With the P1-M, however, you can use two buttons together. You can program the first required function in - let's say the first row in the iMAP in red mode.
  • Page 29 Hot Keys You can assign QWERTY keyboard 'hot keys' to the iMAP. First, lets select where we'd like our command to go. Click the button with your mouse so it is highlighted. Select 'HOTKEY' in the menu on the right side of the iMAP. Click to change the Type in the hot key you contents of a button.
  • Page 30 The results will appear in the iMAP and be transmitted to the P1-M instantaneously! Sending your own MIDI messages You may set up the touchscreen to display your own MIDI messages. The fader/ s and rotary encoder knobs on the device can also be mapped in this way, (buttons such as ‘solo’, and ‘mute’...
  • Page 31 Using Virtual Instruments Some users like to use DAW controllers to control the parameters of Virtual Instruments. It must be noted from the outset that this is entirely DAW and Virtual Instrument-dependent. Some Virtual Instruments have limited (and sometimes no) functionality.
  • Page 32 ‘On the iMAP, right-click the switchgear to ‘Reset to default’ values (i.e. the initial value of the current DAW mode you are in), if you decide you no longer wish to retain your MIDI mapping choices. The touchscreen can similarly be reset in this way. Please note that when using ‘Bitwig,’...
  • Page 33 Changing Transport functions with the iMAP You can set the transport functions with the iMAP to perform simultaneous actions in multiple DAWs. Let's say Femi has two projects, one in Cubase and one in Studio One. She wants to play both at the same time. She can instruct the iMAP to have both DAWs respond to PLAY in this way.

  • Page 34: Other Functions In Imap

    Other Functions in iMap 1. “Save file” button Click this button to save your current settings for the P1-M. The file is an. “ imap” file. 2. “Load file” button Click this button to load a previously saved “. imap” setting file for your P1-M.

  • Page 35: Firmware Upgrade

    Step1: Connect the P1-M using a USB C connection. Ensure the latest iMAP is downloaded from the website and installed, (check to make sure your iMAP is up to date!). Run the iMAP.
  • Page 36 Step 2: Read the warning notice. Step 3: Click the “Start” button.
  • Page 37 Step 4: Allow the firmware upgrade process to complete. Step 5: Press ‘ok’ once the firmware update has been completed...

  • Page 38: Ableton Live

    Ableton Live Mackie Control iCON P1-M V1.02 iCON P1-M V1.02 Input: MackieControl Input(iCON P1-M V1.02) Output: MackieControl Output(iCON P1-M V1.02) Output: Microsoft GS Wavetable Synth Automap Propellerhead Automap MIDI...

  • Page 39: Audition

    Audition Audition iCON P1-M V1.02 Port 1 iCON P1-M V1.02 Port 1...

  • Page 40: Bitwig

    Bitwig iCON P1-M V1.02 iCON P1-M V1.02...

  • Page 41: Cakewalk

    Cakewalk Cakewalk iCON P1-M V1.02 iCON P1-M V1.02 P1-M P1-M MIDIIN2(iCON V1.0 MIDIIN2(iCON P1-M P1-M MIDIIN3(iCON MIDIIN3(iCON V1.0 P1-M P1-M MIDIIN4(iCON V1.0 MIDIIN4(iCON iCON P1-M V1.02 iCON P1-M V1.02 P1-M P1-M V1 MIDIOUT2(iCON MIDIOUT2(iCON P1-M P1-M V1 MIDIOUT3(iCON MIDIOUT3(iCON P1-M...
  • Page 42 P1M V1.02 iCON P1-M V1.02 iCON P1-M V1.02 iCON P1-M V1.02...

  • Page 43: Cubase/Nuendo

    Cubase 12 Pro Cubase/Nuendo iCON P1-M V1.02 iCON P1-M V1.02...

  • Page 44: Digital Performer 11

    Digital Performer 11 Digital Performer iCON P1-M V1.02 iCON P1-M V1.02...

  • Page 45: Fl Studio

    FL Studio iCON P1-M V1.02 iCON P1-M V1.02...

  • Page 46: Logic Pro

    Logic Pro iCON P1-M V1.02 iCON P1-M V1.02 iCON P1-M V1.02...

  • Page 47: Luna

    Luna Luna iCON P1-M V1.02 iCON P1-X1 V1.02 (2) iCON P1-X2 V1.02 (2) iCON P1-X3 V1.02 (2) iCON P1-M V1.04 iCON P1-M V1.02 iCON P1-X1 V1.02 (2) iCON P1-X2 V1.02 (2) iCON P1-X3 V1.02 (2) iCON P1-M V1.02 iCON P1-M V1.02...

  • Page 48: Mixbus 32C

    Mixbus32 Mixbus 32C P1-M iCON P1-M iCON V1.02 P1-M iCON V1.02...

  • Page 49: Pro Tools

    Pro Tools Pro Tools P1M V1.02 P1M V1.02 P1M V1.02...

  • Page 50: Reaper

    Reaper Reaper MCU - Control Universal MCU - Control Universal +1 Extender...
  • Page 51 MCU - Control Universal MCU - Control Universal +1 Extender iCON P1- M V1.02 iCON P1- M V1.02...

  • Page 52: Reason

    Reason Reason iCON P1-M V1.02 iCON P1-M V1.02...

  • Page 53: Samplitude

    Samplitude Samplitude iCON P1-M V1.02 iCON P1-M V1.02 Microsoft GS Wavetable Synth iCON P1-M V1.02 iCON P1-M V1.02...

  • Page 54: Studio One

    Studio One Studio One iCON P1-M V1.02 iCON P1-M V1.02...

  • Page 55: Tracktion Waveform

    Tracktion Waveform Waveform iCON P1-M V1.02 iCON P1-X2 V1.01 iCON P1-M V1.02 iCON P1-X2 V1.01 <Na Devite 5elected> <Na Devite 5elected> <Na Devite 5elected> iCON P1-X2 V1.01 <Na Devite 5elected> iCON P1-M V1.02 iCON P1-X2 V1.01 2-Focusrite USB MIDI iCON P1-M V1.02 2-Focusrite USB MIDI iCON P1-M V1.02...

  • Page 56: Hardware Connections

    Currently, only a few DAWs support the use of a footswitch in DAW controllers such as the P1-M. Please check your DAW's user manual to see if your DAW has this functionality. If so, you can then choose commands specific to the DAW to program your footswitch.

  • Page 57: Expanding Your System

    Expanding your system D-4T Display Unit The P1-M's display capabilities are expandable with the D-4T display unit. ● Extremely compact and durable ● Extremely simple installation for the P1-M MIDI DAW controller with magnetic fixtures - simply slot in! ●...
  • Page 58 The P1-M is expandable, not only with the very fetching D-4T display unit, but with the P1-X expander unit! Each unit consists of 8 12 bit faders, 8 smooth-action endless rotary encoder knobs, and 4 buttons per channel including rec, mute and solo.

  • Page 59: Specifications

    Specifications Connector: To computer USB connector Power supply: 12V/2. 5A DC Current consumption: 2. 0A or less Weight: 1.916kg (4.23lb) Dimensions: 405(L) x 204(W) x 61(H)mm 15. 9”(L) x 8”(W) x 2. 4”(H)

  • Page 60: Services

    Pack the unit in its original packaging including end card and box. This is very important. If you have lost the packaging, please make sure you have packed the unit properly. ICON is not responsible for any damage that occurs due to non-factory packing.
