Air King Exhaust Fan AK960 Specifications

• Grill

White, polymeric grill (flame retardant ABS UL rated 94-5V)
secured in place using 2 philips head screws easily removed
if necessary, dimensions - 17

• Light Lens

Durable high impact polycarbonate lens. Secured in place using
integral tabs.

• Blower Wheel

Heater blower wheel - one piece metal electronically balanced,
3 11 / 16 " x 2" with 28 fins.

• Motor

Heater motor - Heavy duty, plug in 2 pole motor. Life time
lubrication, thermally protected. Rated 120 volts, 60 hz., 0.90
amps., 2400 rpm.

• Heater Housing

23 gauge galvanized steel housing.
Dimensions 14 1 / 2 " x 8 3 / 8

• Heating Element

Wire coil, secured in place by ceramic "J" shaped hooks and
terminated by bolt and nut in cylindrical standoffs. Housed in
an all metal enclosure. Rated 1500 watts - 5120 Btu.

• Lamping Information

Main Lighting: 100 watt maximum, type A19, Medium base bulb
Night Lighting: 7 watt maximum, type C7, Candelabra base bulb
PROJECT
LOCATION
CONTRACTOR
FAN MODEL
CFM
NUMBER NUMBER
C US
Specifications subject to change without notice.
Heat / Light Combination Unit
120 Volts, 14.1 amps, 60 hz.
1 / 8 " x 9 7 / 8 ".
" x 6 1 / 2 ".
IN
RPM WATTS
W.G.
6 "
1 / 2
9 7 / 8 "
CUL - TYPE IC RATED

• Unit Mounting

Designed for ceilings insulated to R-40. Designed to mount in
ceilings with at least 6.5" of clearance. The unit will mount
between joists (with 16" centers) or butted up against a joist.
The housing will mount through drywall thickness up to
with a rough in opening of 14

• Single Pack Shipping Info

Box Dim: 19" x 10
UPC: 0-8316229610-8
Shipping Weight: 13 lbs.
ARCHITECT
ENGINEER
SUBMITTED BY
AMPS SONES QTY
U.S.: 820 Lincoln Drive
West Chester, Pennsylvania 19380-4466
Tel: (877)-304-3785
Fax: (610) 696-8048
SPECIFICATIONS
AK960
EXHAUST FANS
14 1 / 2 "
8 3 / 8 "
17 1 / 8 "
3 / 4 " x 8 5 / 8 ".
1 / 2 " x 8 7 / 8 "
DATE
OPTIONAL EQUIPMENT
& REMARKS
Canada: 110 Glidden Road
Brampton, Ontario L6T 2J3
Tel: (905) 456-2033
Fax: (905) 456-1015
3 / 4 ",
Updated 5-06
