Air King Ak912 Specifications

• Grill

White, polymeric grill (flame retardant ABS UL rated 94-5V)
secured in place with torsion springs; easily removed if
neccessary, dimensions - 10" x 10".

• Heater Housing

23 gauge painted steel housing. Dimensions 8

• Lamping Information

1 - 250 watt maximum, type R40 bulb, medium base, 850 Btu.

• Duct Collar

Plastic collar for 4" duct connection, comes complete with built
in non-metallic back draft damper for quiet operation.

• Unit Mounting

The housing will mount in ceilings with at least 6" of clearance
and through drywall thickness up to
of 8 1 / 4 " x 8". Rated for ceilings insulated to R-40. The housing
will mount between 16" on center joists, using the 4 supplied
housing mounting rails.

• Single Pack Shipping Info

Box Dim: 14 1 / 2 " x 11" x 8"
UPC: 0-8316227021-4
Shipping Weight: 5 lbs.
PROJECT
LOCATION
CONTRACTOR
FAN MODEL
CFM
NUMBER NUMBER
C US
Specifications subject to change without notice.

Bulb Heat Lamp

120 Volts, 2.0 amps, 60 hz.
1 / 4 "x 8" x 5 7 / 8
3 / 4 ", with a rough-in opening
IN
RPM WATTS AMPS
W.G.
".
CUL - TYPE IC RATED
ARCHITECT
ENGINEER
SUBMITTED BY
SONES QTY
U.S.: 820 Lincoln Drive
West Chester, Pennsylvania 19380-4466
Tel: (877)-304-3785
Fax: (610) 696-8048
SPECIFICATIONS
AK912
EXHAUST FANS
DATE
OPTIONAL EQUIPMENT
& REMARKS
Canada: 110 Glidden Road
Brampton, Ontario L6T 2J3
Tel: (905) 456-2033
Fax: (905) 456-1015
Updated 1-06
