ASTRO ONYX THOR 1895 Manual

1/2" impact wrench

Advertisement

1895
1/2" THOR G2
IMPACT WRENCH
WARNING
Study, understand and follow all instructions provided with this product.
Read these instructions carefully before installing, operating, servicing or
repairing this tool. Keep these instructions in a safe accessible place.
• Astro Pneumatic Tool Co. warrants our products to the original user against defective material or workmanship for a
period of 1 year from the date of 1st use. Astro reserves the right to determine whether the product failed because of
defective material, workmanship or other causes and to charge back for missing parts. Astro Pneumatic Tool Co., at its
discretion, will repair products covered under this warranty free of charge. The original user is to return the product
(with the exceptions listed below) with the distributor's name, address, adequate proof of date of purchase or a copy of
warranty card, and a short note explaining the problem. Failures caused by accident, alteration, or misuse are not
covered by this warranty.
• Astro Pneumatic Tool Co. or its authorized service representatives must perform all warranty repairs. Any repair to the
product by unauthorized service representatives voids this warranty. The rights under this warranty are limited to the
original user and may not be transferred to subsequent owners.
• This warranty is in lieu of all other warranties, expressed or implied, including warranties of merchantability and fitness
for a particular purpose. Some states do not allow the exclusion of limitations of incidental or consequential damages
so the above limitations may not apply to you.
PLEASE DO NOT RETURN ANY PRODUCT WITHOUT CALLING 1-800-221-9705 FOR INSTRUCTIONS
1 YEAR LIMITED WARRANTY
106

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ONYX THOR 1895 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ASTRO ONYX THOR 1895

  • Page 1 • Astro Pneumatic Tool Co. warrants our products to the original user against defective material or workmanship for a period of 1 year from the date of 1st use. Astro reserves the right to determine whether the product failed because of defective material, workmanship or other causes and to charge back for missing parts.
  • Page 2: Before Use

    • Generation 2 THOR designed to be the highest performing 1/2" impact wrench on the market. • Maintains a short length like the original Astro THOR impact wrench but with several improvements. • Rated 1,020 ft-lbs traditional Max Torque (compare to 1650 nut-busting) thanks to a larger motor and greatly increased air passageways in the handle and trigger feeding it.
  • Page 3: Maintenance Instruction

    1895 1/2" THOR G2 Impact Wrench WARNING • The tool shall not be used in potentially explosive atmospheres. • Disconnect the air hose before changing or adjusting any inserted tools. • Before using tool, please confirm all couplings and plugs are fixed securely. An air hose that is under pressure may lash out when disconnected and could lead to serious injuries.
  • Page 4 1895 1/2" THOR G2 Impact Wrench SUGGESTED AIR LINE CONNECTION The oil and water extractor should not be mounted on or near the air compressor. The temperature of air is greatly increased during compression. As the air cools down to room temperature, in the air line, on its way to the Air Power Tool, the moisture contained in it condenses.
  • Page 5: Parts Breakdown

    1895 1/2" THOR G2 Impact Wrench INSTRUCTIONS Push back and forth to select FWD or REV 3 power selection settings 1 - High 3/8" NPT inlet 2 - Higher 1/4" NPT adapter included if 3 - Thor, God of Thunder HI-FLOW 1/4"...
  • Page 6: Parts List

    1895 1/2" THOR G2 Impact Wrench PARTS LIST Index Part No. Description Index Part No. Description 1894-60 Front Cover Kit 1895-23 Rotor Blade Grease Fitting 1894-25 Spacer Front Cover 1894-24 Rear End Plate Anvil Bushing (1/2") 1894-23 Screw (M4*P0.7*L16) 1895-2 Anvil Kit (1/2") 1894-22 Ball Bearing (6001ZZ)
