Swann SW244-LMP Easy Setup Manual

A
Monitor and Remote 2 x Maxi-Brite Cameras
Extension Cables x 2 Monitor Input
Cables x 2
Camera Power
Monitor Power RCA to BNC
Supplies x 2
Supply Adapters x 2
B
Switching Between Cameras
Press the AV1/AV2
button to switch
camera views
Front Left Side Panel
Swann Communications • Toll Free Technical Support: USA - 1-800-627-2799, Australia - 1300 13 8324 • Email: tech@swannsecurity.com
8" LCD Monitor & 2 Maxi-Brite Cameras
C

Package Contents

1
LCD Manual
Camera QSG
Security Stickers
& Accessories
2
Connect the monitor input cables to
AV1 and AV2 on the side of the monitor
Not used
Not used
6
Connect the monitor power
supply to the LCD monitor
Easy Setup Guide
Connecting the Cameras to the LCD Monitor
Connect the BNC extension cable to the BNC
to RCA adapter to the yellow video input cable
3
Connect the cameras to the
extension cables
4
Connect the extension cables
to the camera power supply
www.swannsecurity.com
Power Connections
Video Connections
5
Connect the camera power
supply to the power outlet
.com
SR244-LMP-10006-180309
