- Page 1 Business Networking Solution Installation Guide JetStream L2/L2+ Managed Switch...
- Page 3 Remind to take notice. The note contains the helpful information for a better use of the product. Related Document The User Guide and CLI Reference Guide of the product are provided on Download Center. To obtain the latest product information, visit the official website: https://www.tp-link.com.
-
Page 4: Table Of Contents
Contents Chapter 1 Introduction ——————————— 01 Product Overview ............01 Appearance ...............01 Chapter 2 Installation ——————————— 15 Package Contents ............15 Safety Precautions ............15 Installation Tools ..............17 Product Installation ............17 Chapter 3 Connection ——————————— 19 Ethernet Port ..............19 SFP/SFP+ Slot ..............19 Console Port ..............19 Verify Installation .............20 Power On ................21 Initialization ................21... -
Page 5: Chapter 1 Introduction
JetStream L2/L2+ Managed Switch Chapter 1 Introduction Product Overview Designed for workgroups and departments, TP-Link JetStream L2/L2+ Managed Switch provides wire- speed performance and abundant L2 management features. It provides a variety of service features and multiple powerful functions with high security. - Page 6 JetStream L2/L2+ Managed Switch The front panel of TL-SG3210 is shown as the following figure. 1000Mbps 1000Mbps 10/100/1000M 10/100Mbps 100Mbps Activity Activity TL-SG3210 10/100/1000M L2+ Managed Switch Console Port 1G RJ45 Port SFP Slot (RJ45/USB) The front panel of TL-SG3210XHP-M2 is shown as the following figure.
- Page 7 The front panel of TL-SG3428X-M2 is shown as the following figure. Console Port 2.5G SFP+ Slot (USB/RJ45) RJ45 Port The front panel of TL-SG3428XPP-M2 is shown as the following figure. Console Port 2.5G SFP+ Slot (RJ45/USB) RJ45 Port The front panel of TL-SG3452 is shown as the following figure.
- Page 8 JetStream L2/L2+ Managed Switch The front panel of TL-SG3452X is shown as the following figure. TL-SG3452X L2+ Managed Switch Console(USB) Console 1000Mbps 10Gbps 1Gbps activity SFP+ 10/100Mbps Console Port 1G RJ45 Port SFP+ Slot (RJ45/USB) The front panel of TL-SG3452XP is shown as the following figure. PoE Max TL-SG3452XP Speed...
- Page 9 JetStream L2/L2+ Managed Switch LEDs For TL-SX3206HPP Indication On: The switch is powered on. Off: The switch is powered off or power supply is abnormal. Flashing: Power supply is abnormal. Flashing: The switch works properly. On or Off: The switch works improperly. On: The remaining PoE power is ≤...
- Page 10 JetStream L2/L2+ Managed Switch Indication Green On: Running at 10 Gbps, but no activity. Green Flashing: Running at 10 Gbps and transmitting or receiving data. – Port 1 Yellow On: Running at 1 Gbps, but no activity. Yellow Flashing: Running at 1 Gbps and transmitting or receiving data. Off: No device is linked to the corresponding port.
- Page 11 JetStream L2/L2+ Managed Switch Indication On: The remaining PoE power is ≤ 7 W. PoE Max Flashing: The remaining PoE power keeps ≤ 7 W after this LED is on for 2 minutes. Off: The remaining PoE power is > 7 W. Green: All the fans work properly.
- Page 12 JetStream L2/L2+ Managed Switch Indication Green On: Running at 10 Gbps, but no activity. Green Flashing: Running at 10 Gbps and transmitting or receiving data. Yellow On: Running at 1 Gbps, but no activity. SFP+ Yellow Flashing: Running at 1 Gbps and transmitting or receiving data. Off: No device is linked to the corresponding port.
- Page 13 JetStream L2/L2+ Managed Switch Indication Green On: Running at 10 Gbps, but no activity. Green Flashing: Running at 10 Gbps and transmitting or receiving data. Port 25–28 Yellow On: Running at 1 Gbps, but no activity. Yellow Flashing: Running at 1 Gbps and transmitting or receiving data. Off: No device is linked to the corresponding port.
- Page 14 JetStream L2/L2+ Managed Switch PWR1* PWR2 Indication The switch is powered off or both PWR1 and PWR2 work improperly. Indication Flashing: The switch works properly. On or Off: The switch works improperly. Green: All the fans work properly. Yellow: Not all the fans work properly. On: A device is linked to the port but no activity.
- Page 15 Yellow On: Running at 1 Gbps, but no activity. Yellow Flashing: Running at 1 Gbps and transmitting or receiving data. Off: No device is linked to the corresponding port. For TL-SG3428XPP-M2 Indication On: The switch is powered on. Off: The switch is powered off or power supply is abnormal.
- Page 16 JetStream L2/L2+ Managed Switch For TL-SG3428MP, TL-SG3428XMP, TL-SG3452P and TL-SG3452XP Indication On: The switch is powered on. Off: The switch is powered off or power supply is abnormal. Flashing: Power supply is abnormal. Flashing: The switch works properly. On or Off: The switch works improperly. On: The remaining PoE power is ≤...
- Page 17 TL-SG3428MP TL-SG3428X TL-SG3428X-UPS TL-SG3428XF TL-SG3428XMP TL-SG3428X-M2 TL-SG3428XPP-M2 TL-SG3452 TL-SG3452P TL-SG3452X TL-SG3452XP The RJ45 ports of TL-SG3210XHP-M2 does not support 10 Mbps rate. The 4 RJ45 ports of TL-SG3428XF form combo ports with 4 SFP slots and they are not able to negotiate with a speed of 10 Mbps.
- Page 18 PE (Protecting Earth) cable of AC cord or with Ground Cable. For detailed lightning protection measures, go to https://www.tp-link.com/support, search the model number of your switch and go to the product Support web page, refer to the Lightning Protection Guide from the Related Documents: https://www.tp-link.com/us/configuration-guides/lightning_protection_guide/.
-
Page 19: Chapter 2 Installation
JetStream L2/L2+ Managed Switch Chapter 2 Installation Package Contents Make sure that the package contains the following items. Please contact your distributor, if any of the listed items is damaged or missing. The figures are for demonstration only. The actual items may differ in appearance and quantity from the depicted. - Page 20 JetStream L2/L2+ Managed Switch Keep the equipment room at an appropriate level of temperature and humidity. Too much or too little humidity may lead to bad insulation, leakage of electricity, mechanical property changes, and corrosion. High temperatures may accelerate aging of the insulation materials, significantly shortening the service life of the device.
-
Page 21: Installation Tools
Use the signal SPD (Surge Protective Device) when wiring outdoor. ■ Note: For detailed lightning protection measures, go to https://www.tp-link.com/support, search the model number of your switch and go to the product Support web page, refer to the Lightning Protection Guide from the Related Documents: https://www.tp-link.com/us/configuration-guides/lightning_protection_guide/. - Page 22 JetStream L2/L2+ Managed Switch Figure 2-1 Desktop Installation Feet Bottom of the Device Notch Rack Installation ■ To install the device in an EIA standard-sized, 19-inch rack, follow the instructions described below: 1. Check the efficiency of the grounding system and the stability of the rack. 2.
-
Page 23: Chapter 3 Connection
JetStream L2/L2+ Managed Switch Chapter 3 Connection Ethernet Port Connect an Ethernet port of the switch to the computer by RJ45 cable as the following figure shows. Figure 3-1 Connecting the RJ45 Port RJ45 Port RJ45 Cable SFP/SFP+ Slot The following figure demonstrates the connection of SFP/SFP+ slot to an SFP/SFP+ module. Figure 3-2 Inserting the SFP/SFP+ Module SFP/SFP+ Slot... -
Page 24: Verify Installation
JetStream L2/L2+ Managed Switch Connect the console (RJ45) port of the device with your computer by the console cable as the following figure shows. Figure 3-3 Connecting the Console (RJ45) Port Connect the console (USB) port of the device with your computer by the USB cable (not provided) as the following figure shows. -
Page 25: Power On
JetStream L2/L2+ Managed Switch Power On Plug the female connector of the provided power cord into the power socket of the device and plug the positive connector into a power outlet as the following figure shows. Make sure that the voltage of the power supply meets the requirement of the input voltage (100-240 V~ 50/60 Hz). -
Page 26: Chapter 4 Configuration
3. After a successful login, the main page will appear. You can click the menus on the top side and left side to configure the corresponding functions. For the detailed configurations, refer to the User Guide and CLI Guide. The guides can be found on the download center of our official website: https://www.tp-link.com/support/download/. Using the CLI ■... -
Page 27: Controller Mode
None For the detailed configurations, refer to the User Guide and CLI Guide. The guides can be found on the download center of our official website: https://www.tp-link.com/download-center.html Note: For certain devices, you may need to change the password the first time you log in, which will better protect your network and devices. - Page 28 Launch a web browser and enter https://omada.tplinkcloud.com in the address bar. Enter your TP-Link ID and password to log in. Click + Add Controller and choose Hardware Controller to add your controller. Then you can further configure the controller.
- Page 29 Make sure that Cloud Access is enabled on your controller and your controller has been bound with your TP-Link ID. On the Omada Controller’s web page, go to Settings > Cloud Access to enable Cloud Access and bind your TP-Link ID. If you have set it up in the quick setup, skip this step.
-
Page 30: Appendix A Troubleshooting
Appendix A Troubleshooting Q1. What could I do if I forgot the username and password of the switch? Connect the console port of the PC to the console port of the switch and open a terminal emulation program. Power off and restart the switch. Perform the action indicated by the terminal emulation program to reach the bootUtil menu. -
Page 31: Appendix B Specifications
(Except TL-SG3210XHP-M2, TL-SX3206HPP) IEEE 802.3ae (For TL-SX3206HPP, TL-SG3210XHP-M2, TL-SG3428X, TL-SG3428X-UPS, TL-SG3428XF, TL-SG3428XMP, TL-SG3428X-M2, TL-SG3428XPP-M2, TL- SG3452X, TL-SG3452XP) IEEE 802.3bz ( F o r T L- S X 3 2 0 6 H P P, T L- S G 3 2 10 X H P - M 2 , T L- S G 3 42 8 X- M 2 , T L- SG3428XPP-M2) IEEE 802.3an... - Page 32 TL-SG3428XMP: PWR, SYS, PoE Max, FAN, Speed or PoE, SFP+, Speed, PoE TL-SG3428X-M2: PWR, SYS, FAN, Link/Act, SFP+, TL-SG3428XPP-M2: PWR, SYS, PoE Max, FAN, Speed or PoE, SFP+, Speed, PoE TL-SG3452: PWR, SYS, 10/100/1000Mbps, Port 49-52 TL-SG3452X: PWR, SYS, 10/100/1000Mbps, SFP+...
- Page 33 EU Declaration of Conformity TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/30/EU, 2014/35/EU, 2011/65/EU and (EU)2015/863. The original EU Declaration of Conformity may be found at https://www.tp-link.com/en/support/ce/...
- Page 34 UK Declaration of Conformity TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of the Electromagnetic Compatibility Regulations 2016 and Electrical Equipment (Safety) Regulations 2016. The original UK Declaration of Conformity may be found at https://www.tp-link.com/support/ukca/ Продукт...
- Page 36 To ask questions, find answers, and communicate with TP-Link users or engineers, please visit https://community.tp-link.com to join TP-Link Community. For technical support, the user guide and other information, please visit https://www.tp-link.com/support, or simply scan the QR code. © 2023 TP-Link 7106510238 REV3.6.1...
