  • Page 1 CPT 100 Digital Piezo Transmitter Operating Instructions...
  • Page 2: Table Of Contents

    6.2 Configuring the data exchange ........11 6.3 Pfeiffer Vacuum Protocol for "RS-485" ......13 6.4 Adjusting the transmitter .
  • Page 3: About This Manual

    Up-to-date operating instructions can also be downloaded from www.pfeiffer-vacu- um.com. 1.2 Conventions The safety instructions in Pfeiffer Vacuum operating manuals are the result of risk eval- Safety instructions uations and hazard analyses and are oriented on international certification standards as specified by UL, CSA, ANSI Z-535, SEMI S1, ISO 3864 and DIN 4844.
  • Page 4: Safety

     The operator is obligated to make operating personnel aware of dangers originating from the unit or the entire system. The transmitter CPT 100 has been tested and accepted in compliance with EN 61010/ VDE 0411 “Safety Equipment for Electrical Components”.
  • Page 5: Product Description

    (see Accessories). The transmitter responds to measurement value queries, type queries and setting com- mands. 3.3 Range of application The unit CPT 100 must be installed and operated in the following ambient conditions: Installation location weather protected (indoor) Protection class...
  • Page 6: Transport And Storage

    Transport and storage 4 Transport and storage Units without external protection must not come into contact with electrostatically charge- able materials and must not be moved within electrical or magnetic fields.  In rooms with moist or aggressive atmospheres, the unit must be airproof shrink- wrapped in a plastic bag together with a bag of desiccant.
  • Page 7: Installation

    Installation 5 Installation 5.1 Vacuum connection CAUTION Vacuum component! Dirt and damage impair the function of the vacuum component.  When handling vacuum components, ensure that they are kept clean and are protect- ed against damage.  Ensure that the connection flange is clean, dry and free of grease. CAUTION Excess pressure in the vacuum system 1.5 to 4 bar Damage to health through emission of process media, because elastomer washers...
  • Page 8 Installation Setting the address selection switch ------------------ ------------------ ------------------ ------------------ Fig. 2: Setting the address selection switch  Remove the rubber plugs (not shown in the illustration) from the address selector switch, and set the required address according to the relevant connection situation. ...
  • Page 9 Installation  Set the address selector switch on the transmitter to RS-232 mode (basic factory-set- Connecting the trans- ting). mitter to the DPS 101  Connect the transmitter to the power supply unit and to the RS-232 interface on the power supply PC using the connection cable.
  • Page 10: Removal Of Components For Their Maintenance

    Installation Connecting the trans- mitter to the level TIC 002 converter TIC 002 Transmitter 24 V DC Fig. 6: Connections diagram transmitter - TIC 002  Set address selector switch S on the transmitter to RS-485 mode with the relevant ad- dress.
  • Page 11: Operation

    Operation 6 Operation 6.1 Before switching on After switching on the power supply, the transmitter is ready for operation. However, it is advisable to wait for a stabilization period of 5-10 minutes before measurement, and to operate the transmitter without interruption during the measurement process. The pressure measured is independent of the type of gas.
  • Page 12 Parameter 349 contains a logogram for the component name in accordance with the fol- Reading component lowing table: names [P:349] Value Transmitter "..A1" CPT 100 "..A2" RPT 100 "..A3" PPT 100 "..A4" HPT 100 "..A5"...
  • Page 13: Pfeiffer Vacuum Protocol For "Rs-485

    Operation 6.3 Pfeiffer Vacuum Protocol for "RS-485" The telegram frame of the Pfeiffer Vacuum protocol contains only ASCII code characters Telegram frame [32; 127], the exception being the end character of the message . Basically, a master  (e.g. a PC) sends a telegram, which is answered by a slave  (e.g. electronic drive unit or transmitter).
  • Page 14: Adjusting The Transmitter

    Operation Activate/send parameter for low pressure (control command) Low pressure adjustment (Parameter [P:741/740], Slave device address: "001") ? ASCII  ASCII Applied data types Data type Description Size l1 - l0 Example False / true 000000 / 111111 Positive integer number 000000 to 999999 Positive fixed comma number 001571 equal to 15.71...
  • Page 15: Malfunctions

    Malfunctions 7 Malfunctions 7.1 Rectifying malfunctions Problem Possible causes Remedy Transmitter does not respond ● No supply voltage  Connect cable or power supply. ● Wrong serial interface type  Set the address selector switch to or incorrect address set the serial interface to be used.
  • Page 16: Maintenance And Service

    Sending of units  Download the forms "Service Request" and "Declaration on Contamination".  Fill out the "Service Request" form and send it by fax or e-mail to your Pfeiffer Vacuum service address.  Include the confirmation on the service request from Pfeiffer Vacuum with your ship- ment.
  • Page 17: Accessories

    Accessories 9 Accessories Designation Digital Piezo transmitter TIC 251, Profibus converter for CPT, PPT, RPT PT 348 110 TIC 002, converter for DigiLine transmitter PM 051 519-T Centering ring with poral filter, Pore size: 20 μm, FPM/stainless PF 117 216-T steel, DN 16 ISO-KF Fine filter, pore size 4.0 μm, DN 16 ISO-KF PT 120 132-T...
  • Page 18: Technical Data And Dimensions

    Technical data and dimensions 10 Technical data and dimensions 10.1 Technical data Parameter Digital Piezo transmitter Digital Piezo transmitter Flange (in) DN 16 ISO-KF G 1/4" Protection category IP 40 IP 40 Seal Pressure max. 4 bar 4 bar Accuracy: % of measurement 1-1200 mbar: ±...
  • Page 19: Declaration Of Conformity

    We hereby certify, that the product specified below is in accordance with the provision of EU Electromagnetic Compatibility Directive 2004/108/EEC and EU Low Voltage Di- rective 2006/95/EEC. DigiLine CPT 100 Guidelines, harmonised standards and national standards and specifications which have been applied: DIN EN 61010-1: 2002...
