King Tony 9DS11-16 Quick Start Manual

Intelligent battery clamp specifications
Step 1.
Connect the clamps to car battery, red to "+", black to "-".
Step 2.
Connect with jump starter.
Step 3.
Confirm the jump starter is ready to use by checking the indicator light.
Error
Functions of intelligent battery clamp:
Function Indication
The clamp and jump starter are connected but without connection
Standby
RED light
with car battery. It changes to blue light after connecting to car battery.
Automatic When blue light is on, if the car hasn't been started after 30s,
Power off the output will be shut off.
Low Voltage
When jump starter's voltage VBAT＜10.5V，the clamp will be in
Protection
Low Voltage Protection mode, the output will be shut off.
RED light &
When the clamps are reversely connected to the car battery,
Reverse Polarity
buzzer
the battery clamp will be in Reverse Polarity Protection mode,
Protection
the output will be shut off.
Short Circuit
When the two clamps are connected, the battery clamp will be in
Protection
Short Circuit Protection mode, the output will be shut off.
Reverse Charging
If there is any reverse current, the output will be shut off.
Protection
Ready
Details Description
1
MULTI-FUNCTION MULTI-FUNCTION
JUMP STARTER JUMP STARTER
Enjoy your work
16000mAh 16000mAh
9DS11-16 9DS11-16
NO. NO.
