Page 1 PDSBM-LN1 PDSBM-LN2 PDSBM-LN2+ USER’S MANUAL Revision 1.0b...
Page 2 Clara County in the State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
Page 3: About This Manual
Please refer to the motherboard speciﬁ cations pages on our website (http://www. supermicro.com/Products/) for updates on supported processors. This product is intended to be installed and serviced by professional technicians.
Page 4: Table Of Contents
Checklist ... 1-1 Contacting Supermicro ... 1-2 PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ Image ... 1-3 PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ Layout ... 1-4 PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ Quick Reference ... 1-5 Motherboard Features ... 1-6 Intel 946GZ Chipset: System Block Diagram ... 1-8 Chipset Overview ... 1-9 PC Health Monitoring ... 1-10 Power Conﬁ...
Page 5 Connecting Cables ... 2-12 ATX/Auxiliary Power Connectors ... 2-12 Universal Serial Bus (USB) ... 2-13 Chassis Intrusion ... 2-13 Fan Headers ... 2-14 ATX PS/2 Keyboard and PS/2 Mouse Ports ... 2-15 Serial Ports ... 2-15 Wake-On-Ring ... 2-16 Wake-On-LAN ... 2-16 GLAN1/GLAN2 Ports ...
Page 6 PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User’s Manual Chapter 4: BIOS Introduction ... 4-1 Running Setup ... 4-2 Main BIOS Setup ... 4-2 Advanced Setup ... 4-6 Security Setup ... 4-17 TPM State ... 4-19 Boot Setup ... 4-20 Exit ... 4-21 Appendices: Appendix A: BIOS POST Messages ... A-1 Appendix B: BIOS POST Codes ...
Page 7: Chapter 1 Introduction
Checklist Congratulations on purchasing your computer motherboard from an acknowledged leader in the industry. Supermicro boards are designed with the utmost attention to detail to provide you with the highest standards in quality and performance. Please check that the following items have all been included with your motherboard.
Page 8: Contacting Supermicro
PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User’s Manual Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.
Page 9: Pdsbm-Ln1/Pdsbm-Ln2/Pdsbm-Ln2+ Image
Chapter 1: Introduction PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ Image Note:All graphics shown in this manual were based upon the latest PCB Revision available at the time of publishing of the manual. The motherboard you've received may or may not look exactly the same as the graphics shown in this manual.
Page 10 PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User’s Manual Motherboard Layout (not drawn to scale) 24-Pin ATX PWR Super I/O Intel 946GZ LAN CTRL North Bridge JPL2 LAN CTRL Slot 6 PCI-E.x4 (in x8 slot) Slot 5 PCI-33 MHz JWOR Buzzer SPKR SPKR1 COM2 Important Notes to the User •...
Page 11: Pdsbm-Ln1/Pdsbm-Ln2/Pdsbm-Ln2+ Quick Reference
PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ Quick Reference Jumpers Description JBT1 CMOS Clear JI 2 C1/JI 2 C2 SMB to PCI Slots JP3 (*PDSBM-LN2+ Only)Trusted Platform Module Ena.Pins 1-2 (Enabled) JPL1/JPL2 Giga-bit LAN1/LAN2 Enable Pins 1-2 (Enabled) Watch Dog Timer Out Option Pins 1-2 (Reset)
Page 12: Motherboard Features
PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User’s Manual Motherboard Features Latest CPU technology! • Single Intel Xeon 3000 Series/Core 2 Duo Processor/Pentium D Processor/ Pentium 4 Processor with a system bus speed of up to 1066 MHz The Intel Xeon Core 2 Duo Processor supports: •...
Page 13 • Dual Intel 82573L Gigabit Ethernet Controllers support 2 Gigabit LAN ports (*For PDSBM-LN2/LN2+ only) • Single Intel 82573L Gigabit Ethernet Controllers support a Gigabit LAN port (*For PDSBM-LN1 only) • PS/2 mouse and PS/2 keyboard ports • One IDE hard drive supports single/dual channel(s) •...
Page 14 PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User’s Manual VRM V11.0 LGA775_PROCESSOR VRM 11.0 FSB: 1000/800/533MHz INTEGRATED GMCH/MCH GRAPHIC 946GZ PCI-E x4 PCI-Exp. x4 Riser Slot S-ATA/300 4x SATAII PORTS USB2.0/1.1 4x USB2.0 PORTS (*PDSBM -LN2+) W83627DHG LPC I/O PS2 KB/MS. SER.1/2 FDD. The 946GZ Chipset:...
Page 15: Chipset Overview
Chapter 1: Introduction Chipset Overview The Intel 82946GZ chipset, designed for use with the Intel Xeon 3000 Series/Core 2 Duo processor and Pentium D/Pentium 4 Processor in desktop platforms, contains two components: GMCH (North Bridge) and ICH7R (South Bridge). The GMCH is used for the host bridge, and the ICH7R, for the I/O subsystems.
Page 16: Pc Health Monitoring
PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User’s Manual PC Health Monitoring This section describes the PC health monitoring features of the PDSBM-LN1/ PDSBM-LN2/PDSBM-LN2+. The motherboard has an onboard System Hardware Monitor chip that supports PC health monitoring. Recovery from AC Power Loss BIOS provides a setting for you to determine how the system will respond when AC power is lost and then restored to the system.
Page 17: Bios Support For Usb Keyboard
It is even more important for processors that have high CPU clock rates of 1 GHz and faster. PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ accommodates 12V ATX power supplies. Although most power supplies generally meet the speciﬁ cations required by the CPU, some are inadequate. A 2-Amp of current supply on a 5V Standby rail is strongly recommended.
Page 18: Super I/O
PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User’s Manual Super I/O The disk drive adapter functions of the Super I/O chip include a ﬂ oppy disk drive controller that is compatible with industry standard 82077/765, a data separator, write pre-compensation circuitry, decode logic, data rate selection, a clock genera- tor, drive interface control logic and interrupt and DMA logic.
Page 19: Chapter 2 Installation
(Note: Be sure to mount the motherboard into the chassis before you install the CPU onto the motherboard.) All motherboards have standard mounting holes to ﬁ t different types of chassis. Make sure that the locations of all the mounting holes for both motherboard and chassis match.
Page 20: Processor And Heatsink Installation
PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual Processor and Heatsink Installation When handling the processor package, avoid placing direct pressure on the label area of the fan. Notes: 1. Always connect the power cord last and always remove it before adding, removing or changing any hardware components. Make sure that you install the processor into the CPU LGA 775 socket before you install the CPU heatsink.
Page 21 3. Use your thumb and your index ﬁ nger to hold the CPU at the North Center Edge and the South Center Edge of the CPU. 4. Align CPU Pin1 (the CPU corner marked with a triangle) against the socket corner marked with a triangle cutout.
Page 22: Installing Dimms
Repeat for all modules (see step 1 above). Memory Support The PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ supports up to 4 GB Unbuffered Non- ECC DDR2 533/667 in 2 DIMMs. Populating DIMM modules with a pair of memory modules that are of the same size and of the same type in DIMM A, and DIMM B will result in interleaved memory.
Page 23 Possible System Memory Allocation & Availability System Device Firmware Hub ﬂ ash memory (System BIOS) Local APIC Area Reserved for the chipset I/O APIC (4 Kbytes) PCI Enumeration Area 1 PCI Express (256 MB) PCI Enumeration Area 2 (if needed) -Aligned on 256-MB boundary- VGA Memory TSEG...
Page 24: Control Panel Connectors/Io Ports
PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual Control Panel Connectors/IO Ports The I/O ports are color coded in conformance with the PC 99 speciﬁ cation. See the ﬁ gure below for the colors and locations of the various I/O ports. A. Back Panel Connectors/IO Ports Back Panel I/O Port Locations and Deﬁ...
Page 25: Front Control Panel
These connectors are designed speciﬁ cally for use with Supermicro server chassis. See the ﬁ gure below for the descriptions of the various control panel buttons and LED indicators. Refer to the following section for descriptions and pin deﬁ...
Page 26: Front Control Panel Pin Deﬁ Nitions
PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual C. Front Control Panel Pin Deﬁ nitions NMI Button The non-maskable interrupt button header is located on pins 19 and 20 of JF1. Refer to the table on the right for pin deﬁ nitions. Power LED The Power LED connection is located on pins 15 and 16 of JF1.
Page 27: Hdd Led
HDD LED The HDD LED connection is located on pins 13 and 14 of JF1. Attach a hard drive LED cable here to display disk activity (for any hard drives on the system, including SAS and Serial ATA). See the table on the right for pin deﬁ...
Page 28: Overheat/Fan Fail Led (Oh)
PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual Overheat/Fan Fail LED (OH) Connect an LED to the OH/Fan Fail connection on pins 7 and 8 of JF1 to provide advanced warnings of chassis overheating or fan failure. Refer to the table on the right for pin deﬁ nitions.
Page 29: Reset Button
Reset Button The Reset Button connection is located on pins 3 and 4 of JF1. Attach it to the hardware reset switch on the computer case. Refer to the table on the right for pin deﬁ nitions. Power Button The Power Button connection is located on pins 1 and 2 of JF1.
Page 30: Connecting Cables
PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual Connecting Cables ATX/Auxiliary Power Connectors The 24-pin ATX main power connec- tor is located at J40, and a 12V 8-pin power connector is located at J41 on the motherboard. These power con- nectors meet the SSI EPS 12V speci- ﬁ...
Page 31: Universal Serial Bus (Usb)
Universal Serial Bus (USB) Four USB 2.0 (Universal Serial Bus) ports (Ports 1/2/3/4) are located on the I/O Backplane, and two USB headers: USB 7/8 (J44) can be ac- cessed from the front panel. In addi- tion, two USB Ports: USB 5 (J49) and USB 6 (J48) are designed for internal use only.
Page 32: Fan Headers
PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual Fan Headers The PDSBM-LN1/PDSBM-LN2/PDS- BM-LN2+ has ﬁ ve chassis/system fan headers (Fan1 to Fan5), including a CPU Fan (Fan 1). (Note: Pins 1-3 of 4-pin fan headers are backward com- patible with the traditional 3-pin fans). See the table on the right for pin deﬁ - nitions.
Page 33: Atx Ps/2 Keyboard And Ps/2 Mouse Ports
ATX PS/2 Keyboard and PS/2 Mouse Ports The ATX PS/2 keyboard and the PS/2 mouse are located at J28. See the table on the right for pin deﬁ nitions. (The mouse port is above the key- board port. See the table on the right for pin deﬁ...
Page 34: Wake-On-Ring
PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual Wake-On-Ring The Wake-On-Ring header is des- ignated JWOR. This function allows your computer to wake up when re- ceiving an incoming call to the modem when the system is in the suspend state. See the table on the right for pin definitions.
Page 35: Speaker Connector
LAN 1/LAN 2 (Giga-bit Ethernet Ports) Two G-bit Ethernet ports are lo- cated at JLAN1 and JLAN2 on the IO backplane. This port accepts RJ45 type cables. (Note: JLAN2 is for the PDSBM-LN2/LN2+ only.) Speaker A Speaker/Buzzer header (J9) is located on the motherboard.
Page 36: Jumper Settings
PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual Jumper Settings Explanation of Jumpers To modify the operation of the motherboard, jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to change the function of the connector. Pin 1 is identiﬁ ed with a square solder pad on the printed circuit board.
Page 37: Cmos Clear
CMOS Clear JBT1 is used to clear CMOS. Instead of pins, this "jumper" consists of contact pads to prevent the accidental clearing of CMOS. To clear CMOS, use a metal object such as a small screwdriver to touch both pads at the same time to short the connection. Always remove the AC power cord from the system before clearing CMOS.
Page 38: Tpm Enable
PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual PCI/PCI-E Slots to SMB Speeds Jumpers JI C1/JI C2 allow you to connect PCI/PCI-Express slots to the System Management Bus. The default setting is open to disable the connection. See the table on the right for jumper settings.
Page 39: Onboard Indicators
Onboard Indicators GLAN LEDs Two GLAN ports (LAN 1 and LAN 2) are located on the I/O backpanel on the moth- erboard. Each Gigabit Ethernet LAN port has two LEDs. The yellow LED indicates activity, and the Link LED may be green, amber or off to indicate the speed of the connection.
Page 40: Cpu Vrm Overheat Led
PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual CPU VRM Overheat LED Indicator (LE2) A CPU VRM Overheat LED is located at LE2 on the motherboard. When the tem- perature of CPU VRM is normal, the CPU VRM Overheat LED is off. When the CPU...
Page 41: Floppy Drive And Ide Hard Drive Connections
Floppy Drive and IDE Hard Drive Connections Note the following when connecting the ﬂ oppy and hard disk drive cables: • The ﬂ oppy disk drive cable has seven twisted wires. • A red mark on a wire typically designates the location of pin 1. •...
Page 42: Ide Connectors
PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual IDE Connector An IDE Connector is located at J4 on the motherboard. See the table on the right for pin deﬁ nitions. 24-Pin ATX PWR Super I/O Intel 946GZ LAN CTRL North Bridge DIMM A DIMM B...
Page 43: Chapter 3: Troubleshooting
Troubleshooting Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the ‘Technical Support Procedures’ and/or ‘Returning Merchandise for Service’ section(s) in this chapter. Always disconnect the AC power cord before adding, changing or removing any hardware components.
Page 44: Memory Errors
Technical Support Procedures Before contacting Technical Support, please take the following steps. Also, note that as a motherboard manufacturer, Supermicro does not sell directly to end-users, so it is best to ﬁ rst check with your distributor or reseller for troubleshooting services.
Page 45: Frequently Asked Questions
4. Distributors: For immediate assistance, please have your account number ready when placing a call to our technical support department. We can be reached by e-mail at support@supermicro.com, by phone at:(408) 503-8000, option 2, or by fax at (408)503-8019. Frequently Asked Questions...
Page 46: Returning Merchandise For Service
PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual BIOS without any prompts. Please note that this process may take a few minutes to complete. Do not be concerned if the screen is paused for a few minutes. Question: What's on the CD that came with my motherboard? Answer: The supplied compact disc has quite a few drivers and programs that will greatly enhance your system.
Page 47: Chapter 4: Bios
Introduction This chapter describes the Phoenix BIOS™ Setup utility for the PDSBM-LN1/ PDSBM-LN2/PDSBM-LN2+. The Phoenix ROM BIOS is stored in a ﬂ ash chip and can be easily upgraded using a ﬂ oppy disk-based program. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.
Page 48: Running Setup
PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual Running Setup *Default settings are in bold text unless otherwise noted. The BIOS setup options described in this section are selected by choosing the ap- propriate option from the main BIOS Setup screen. All displayed text is described in this section, although the screen display is often all you need to understand how to set the options (see the next page).
Page 49: Main Bios Setup Menu
Chapter 4: BIOS Main BIOS Setup Menu Main Setup Features System Time To set the system date and time, key in the correct information in the appropriate ﬁ elds. Then press the <Enter> key to save the data. System Date Using the arrow keys, highlight the month, day and year ﬁ...
Page 50 PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual Serial ATA This setting allows the user to enable or disable the function of the Serial ATA. The options are Disabled and Enabled. Native Mode Operation This setting allows the user to conﬁ gure the native ATA mode settings. The options are: Parallel ATA, Serial ATA, Both, and Auto.
Page 51 Type This option allows the user to select the type of SATA drives. Select Auto for the BIOS to automatically set the SATA drive's capacity, number of heads, etc.) Enter a number from 1-39 to select a predetermined type of the HDD drive. Select User to allow the user to enter the parameters of the HDD drive installed at this connection.
Page 52: Advanced Setup
PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual Advanced Setup Choose the Advanced Menu from the Phoenix BIOS Setup Utility with the arrow keys. You should see the following display. The items with a triangle beside them have sub- menus that can be accessed by highlighting the item and pressing <Enter>.
Page 53 Chapter 4: BIOS Enabling Multi-Media Timer Select Yes to activate a set of timers that are alternative to the traditional 8254 timers for OS use. The options are Yes and No. Power Button Behavior If set to Instant-Off, the system will power on or power off immediately as soon as the user presses the power button.
Page 54 PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual Core-Multi-Processing (Available when supported by the CPU.) Set to Enabled to use a processor's Second Core and beyond. (Please refer to Intel's website for more information.) The options are Disabled and Enabled. Hyper-threading (Available when supported by the CPU.) Set to Enabled to use the Hyper-Threading Technology, which will result in increased CPU performance.
Page 55 Echo TPR Set to Enabled to prevent xTPR messages from being sent to the system. The options are Disabled and Enabled. C1 Enhanced Mode (Available when supported by the CPU.) Set to Enabled to enable Enhanced Halt State to lower CPU voltage/frequency to prevent CPU overheating.
Page 56 PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual Clock Spectrum Feature If Enabled, the BIOS will monitor the level of Electromagnetic Interference caused by the components and will attempt to decrease the interference whenever needed. The options are Enabled and Disabled. Default Primary Video Adapter This feature allows the user to select the video device used by the BIOS during the POST routines.
Page 57: Cache System Bios Area
Chapter 4: BIOS Memory Cache Memory Cache This setting allows the user to enable or disable the functions of Memory Cache. The options are Enabled and Disabled. Cache System BIOS Area This setting allows you to designate a reserve area in the system memory to be used as a System BIOS buffer to allow the BIOS to write (cache) its data into this reserved memory area.
Page 58 PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual written into L1, L2, L3 cache inside the CPU to speed up CPU operations. Select Uncached to disable this function. Select Write Through to allow data to be cached into the buffer and written into the system memory at the same time. Select Write Protect to prevent data from being written into the extended memory area above 1 MB.
Page 59 Onboard PCI-Exp. x1 GNIC2 (*For PDSBM-LN2/LN2+ Only) Access the submenu for each of the settings above to make changes to the following: PCI Express Port#6 GNIC2 Select Enabled to always enable PCI-Ex1 Port#6 GNIC2. Select Disabled to disable PCI-Ex1 Port#6 GNIC2. The options are Auto, Enabled and Disabled. Option ROM Scan When enabled, this setting will initialize the device expansion ROM.
Page 60 PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual I/O Device Conﬁ guration Access the submenu to make changes to the following settings. KBC Clock Input This setting allows you to select the clock frequency for KBC. The options are 6MHz, 8MHz, 12MHz, and 16MHz. Serial Port A This setting allows you to conﬁ...
Page 61 Chapter 4: BIOS Console Redirection Access the submenu to make changes to the following settings. COM Port Address This item allows you to specify which COM port to direct the remote console to: Onboard COM A or Onboard COM B. This setting can also be Disabled. BAUD Rate This item allows you to set the BAUD rate for console redirection.
Page 62: Voltage Monitoring
PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual Hardware Monitoring CPU Overheat Temperature This option allows the user to set a CPU temperature overheat threshold that will activate the alarm system when the CPU temperature reaches this pre-set temperature threshold. The options are 75 C, 80...
Page 63: Security Settings
Chapter 4: BIOS Security Settings Choose the Security menu from the Phoenix BIOS Setup Utility with the arrow keys. You should see the following display. Security setting options are displayed by high- lighting the setting using the arrow keys and pressing <Enter>. All Security BIOS settings are described in this section.
Page 64: Fixed Disk Boot Sector
PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual Fixed Disk Boot Sector Select Normal to enable the function of Write-Protect to protect the boot sector on the hard drives against viruses. Password on Boot This setting allows you to determine if a password is required for a user to enter the system at system boot.
Page 65: Tpm (Trusted Platform Modules) State
TPM (Trusted Platform Modules) State LN2+ only. This option is available when TPM is enabled in the Security menu.) Choose the TPM State menu from the Phoenix BIOS Setup Utility with the arrow keys. You should see the following display. Current TPM State This item shows the current TPM State only.
Page 66: Boot Settings
PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual Boot Settings Choose the Boot menu from the Phoenix BIOS Setup Utility with the arrow keys. You should see the following display. See details on how to change the order and specs of boot devices in the Item Speciﬁ c Help window. All Boot BIOS settings are described in this section.
Page 67: Exit
Chapter 4: BIOS Exit Choose the Exit menu from the Phoenix BIOS Setup Utility main menu with the ar- row keys. You should see the following display. All Exit BIOS settings are described in this section. Exit Saving Changes Highlight this item and hit <Enter> to save any changes you have made and to exit the BIOS Setup utility.
Page 68 PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual Notes 4-22...
Page 69: Appendix Abios Post Messages
Appendix A: BIOS POST Messages Appendix A BIOS POST Messages During Power-On Self-Test (POST), the BIOS will check for problems. If a problem is found, the BIOS will activate an alarm or display a message. The following is a list of such BIOS messages.
Page 70 PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual System CMOS checksum bad - Default conﬁ guration used System CMOS has been corrupted or modiﬁ ed incorrectly, perhaps by an application program that changes data stored in CMOS. The BIOS installed Default Setup Values. If you do not want these values, enter Setup and enter your own values. If the error persists, check the system battery or contact your dealer.
Page 71 Appendix A: BIOS POST Messages CPU ID: CPU socket number for Multi-Processor error. EISA CMOS not writeable ServerBIOS2 test error: Cannot write to EISA CMOS. DMA Test Failed ServerBIOS2 test error: Cannot write to extended DMA (Direct Memory Access) registers. Software NMI Failed ServerBIOS2 test error: Cannot generate software NMI (Non-Maskable Interrupt).
Page 72 PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual PS/2 Mouse Boot Summary Screen: PS/2 Mouse installed. nnnn kB Extended RAM Passed Where nnnn is the amount of RAM in kilobytes successfully tested. nnnn Cache SRAM Passed Where nnnn is the amount of system cache in kilobytes successfully tested.
Page 73 Appendix A: BIOS POST Messages Press <F2> to enter Setup Optional message displayed during POST. Can be turned off in Setup. PS/2 Mouse: PS/2 mouse identiﬁ ed. Run the I2O Conﬁ guration Utility One or more unclaimed block storage devices have the Conﬁ guration Request bit set in the LCT.
Page 74 PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual Notes...
Page 75: Appendix Bbios Post Codes
Appendix B BIOS POST Codes This section lists the POST (Power On Self Test) codes for the Phoenix BIOS. POST codes are divided into two categories: recoverable and terminal. Recoverable POST Errors When a recoverable type of error occurs during POST, the BIOS will display an POST code that describes the problem.
Page 76 PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual POST Code Description 8254 timer initialization 8237 DMA controller initialization Reset Programmable Interrupt Controller 1-3-1-1 Test DRAM refresh 1-3-1-3 Test 8742 Keyboard Controller Set ES segment register to 4 GB Auto size DRAM Initialize POST Memory Manager...
Page 77 POST Code Description Test RAM between 512 and 640 kB Test extended memory Test extended memory address lines Jump to UserPatch1 Conﬁ gure advanced cache registers Initialize Multi Processor APIC Enable external and CPU caches Setup System Management Mode (SMM) area Display external L2 cache size Load custom defaults (optional) Display shadow-area message...
Page 78 PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual POST Code Description Check for SMART Drive (optional) Set up Power Management Initialize security engine (optional) Enable hardware interrupts Determine number of ATA and SCSI drives Set time of day Check key lock Initialize typematic rate Erase <ESC> prompt Scan for <ESC>...
Page 79: The Following Are For Boot Block In Flash Rom
POST Code Description Unknown interrupt Check Intel Branding string Alert Standard Format initialization Log error if micro-code not updated properly The following are for boot block in Flash ROM POST Code Description Initialize the chipset Initialize the bridge Initialize the CPU Initialize system timer Initialize system I/O Check force recovery boot...
Page 80 PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual Notes...
Page 81 RAID Utility program to conﬁ gure the RAID Level that you desire before installing the Windows XP/2000/2003 operating system and other software drivers. (The necessary drivers are all included on the Supermicro CD that came packaged with your motherboard.) Note: The current version of the ICH7R SATA RAID Utility can only support Windows XP/2000/2003 Operating Systems.
Page 82: Raid Configurations
PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual RAID Conﬁ gurations The following types of RAID conﬁ gurations are supported: RAID 0 (Data Striping): this writes data in parallel, interleaved ("striped") sections of two hard drives. Data transfer rate is doubled over using a single disk.
Page 83 Using the Intel ICH7R SATA RAID Utility Program 1. Creating, Deleting and Resetting RAID Volumes: a. After the system exits from the BIOS Setup Utility, the system will automatically reboot. The following screen appears after Power-On Self Test. b. When you see the above screen, press the <Ctrl> and the <I> keys simultane- ously to have the main menu of the SATA RAID Utility appear: (Note: All graphics and screen shots shown in the manual are for reference only.
Page 84: Creating A Raid 0 Volume
PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual Creating a RAID 0 Volume: a. Select "Create RAID Volume" from the main menu and press the <Enter> key. The following screen will appear: b. Specify a name for the RAID 0 set and press the <Tab> key or the <Enter> key to go to the next ﬁ...
Page 85: Creating A Raid 1 Volume
Appendix C: Intel HostRAID Installation Guidelines Creating a RAID 1 Volume: a. Select "Create RAID Volume" from the main menu and press the <Enter> key. The following screen will appear: b. Specify a name for the RAID 1 set and press the <Tab> key or the <Enter> key to go to the next ﬁ...
Page 86 PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual Creating a RAID 10 (RAID 1+ RAID 0): a. Select "Create RAID Volume" from the main menu and press the <Enter> key. The following screen will appear: b. Specify a name for the RAID 10 set and press <Enter>.
Page 87: Creating A Raid 5 Set (Parity)
Appendix C: Intel HostRAID Installation Guidelines Creating a RAID 5 Set (Parity): a. Select "Create RAID Volume" from the main menu and press the <Enter> key. The following screen will appear: b. Specify a name for the RAID 5 set and press <Enter>. c.
Page 88: Deleting Raid Volume
PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual Deleting RAID Volume: (Warning: Be sure to back up your data before deleting a RAID set. You will lose all data on the disk drives when deleting a RAID set.) a. From the main menu, select item2-Delete RAID Volume, and press <Enter>.
Page 89: Exiting The Intel Matrix Storage Manager Utility
Appendix C: Intel HostRAID Installation Guidelines Resetting to Non-RAID and Resetting a RAID HDD Warning: Be cautious when you reset a RAID volume HDD to non- RAID or Resetting a RAID HDD. Resetting a RAID volume HDD or Resetting a RAID HDD will reformat the HDD and delete all internal RAID structure on the drive.
Page 90: With Raid Functions
After the Windows XP/2000/2003 Installation is completed, the system will au- tomatically reboot. i. Insert the Supermicro Setup CD that came with the package into the CD Drive during system reboot, and the main screen will appear. Note: the current version of the ICH7R SATA RAID Utility can only support the Windows XP/2000/2003 Operating System.
Page 91: Appendix D: Software Installation Instructions
Appendix D: Software Installation Instructions Appendix D Software Installation Instructions Installing Drivers After you've installed the Windows Operating System, a screen as shown below will appear. You are ready to install software programs and drivers that have not yet been installed. To install these software programs and drivers, click the icons to the right of these items.
Page 92 PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual Conﬁ guring Supero Doctor III The Supero Doctor III program is a Web-base management tool that supports remote management capability. It includes Remote and Local Management tools. The local management is called the SD III Client. The Supero Doctor III program included on the CDROM that came with your motherboard allows you to monitor the environment and operations of your system.
Page 93 Supero Doctor III Interface Display Screen-II (Remote Control) (Note: SD III Software Revision 1.0 can be downloaded from our Website at: ftp:// ftp.supermicro.com/utility/Supero_Doctor_III/. You can also download SDIII User's Guide at: http://www.supermicro.com/PRODUCT/Manuals/SDIII/UserGuide.pdf. For Linux, we will still recommend that you use Supero Doctor II.)
Page 94 PDSBM-LN1/PDSBM-LN2/PDSBM-LN2+ User's Manual Notes...
Page 95 (Disclaimer Continued) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in signiﬁ cant injury or loss of life or catastrophic property damage.
