PCB Piezotronics ICP 105C12/NC Installation And Operating Manual page 10

Model Number
105C12
Performance
Measurement Range(for ±5V output)
Sensitivity(± 15 %)
Maximum Pressure(Total)
Resolution
Resonant Frequency
Rise Time(Reflected)
Low Frequency Response(- 5 %)
Non-Linearity
Environmental
Acceleration Sensitivity
Temperature Range(Operating)
Temperature Coefficient of Sensitivity
Maximum Flash Temperature
Maximum Shock
Electrical
Output Polarity(Positive Pressure)
Discharge Time Constant(at room temp)
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Physical
Sensing Geometry
Sensing Element
Housing Material
Diaphragm 17-4 Stainless Steel
Sealing
Electrical Connector
Weight
[3]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Piezotronics, Inc.
ICP® PRESSURE SENSOR
EN GLISH SI
1,000 psi 6,895 kPa
5.0 mV/psi 0.73 mV/kPa
7,500 psi 51,713 kPa
0.02 psi 0.14 kPa
≥ 250 kHz ≥ 250 kHz
≤ 2.0 µ sec ≤ 2.0 µ sec
0.5 Hz 0.5 Hz
≤ 2.0 % FS ≤ 2.0 % FS
≤ 0.04 psi/g ≤ 0.028 kPa/(m/s²)
-100 to +250 °F -73 to +121 °C
≤ 0.09 %/°F ≤ 0.162 %/°C
3,000 °F 1,649 °C
5,000 g pk 49,035 m/s² pk
Positive Positive
≥ 1.0 sec ≥ 1.0 sec
22 to 30 VDC 22 to 30 VDC
2 to 20 mA 2 to 20 mA
< 100 Ohm < 100 Ohm
8 to 14 VDC 8 to 14 VDC
Compression Compression
Quartz Quartz
Stainless Steel Stainless Steel
17-4 Stainless Steel
Welded Hermetic Welded Hermetic
5-44 Coaxial 5-44 Coaxial
0.055 oz 1.56 gm
Optional versions have identical specifications and accessories as listed for the standard model except
where noted below. More than one option may be used.
- Metric Mount
M
[1]
N - Negative Output Polarity
- Water Resistant Cable
W
[2]
N OTES:
[1]Typical.
[2]Zero-based, least-squares, straight line method.
[3]See PCB Declaration of Conformance PS023 for details.
SUPPLIED ACCESSORIES:
Model 018C10 Miniature coaxial cable, vinyl insulation jacket, 10-ft, 5-44 coaxial plug to BNC plug
(1)
Model 040A37 Hex nut driver (1)
Model 065A10 Seal ring 0.138" OD x 0.101" ID x 0.022" thk brass (3)
Model 065A38 Seal & Sleeve 0.138" OD x 0.101" ID x 0.105" thk., brass. (3)
Entered: ND Engineer: RPF
Date: 09/07/2022 Date: 09/07/2022 Date: 09/07/2022 Date: 09/07/2022 11321
3425 Walden Avenue, Depew, NY 14043
Revision: E
ECN #: 53159
OPTION AL VERSION S
Sales: MV Approved: BAM Spec Number:
Phone: 716-684-0001
Fax: 716-684-0987
E-M ail: info@ pcb.com
