AIR EXCHANGE EQUIPMENT
INSTALLATION AND USER
MANUAL
THE QUALITY GOALS OF AIR CONDITIONING COME TRUE
WITH THE RECOVERY SYSTEM
TALTERI removes used air from interior and brings in fresh air.
Humidity and impurities are exhausted through thermal recovery
unit that heats the filtered ambient air cost-effectively. The fresh
warm air is channelled draught-free and noise-free into the
premises in necessary quantities.
ENSURE THE QUALITY OF AIR EXCHANGE!
DEEKAX Air Oy
R
TALTERI
DIVK-C 91 CD
Patruunapolku 4
79100 LEPPÄVIRTA
Puh. 0207 912550
www.deekaxair.fi
Advertisement
Related Manuals for Deekax TALTERI DIVK-C 91 CD
Summary of Contents for Deekax TALTERI DIVK-C 91 CD
- Page 1 The fresh warm air is channelled draught-free and noise-free into the premises in necessary quantities. ENSURE THE QUALITY OF AIR EXCHANGE! Patruunapolku 4 Puh. 0207 912550 DEEKAX Air Oy 79100 LEPPÄVIRTA www.deekaxair.fi...
- Page 2 MACHINE PARTS AND TECHNICAL INFORMATION MACHINE PARTS AND TECHNICAL INFORMATION 1 Exhaust air ..... 125 mm 2 Outdoor air ..... 125 mm 3 Extract air ..... 125 mm 4 Supply air ... .. 125 mm 5 Kitchen exhaust ..125 mm 6 Door switch 7 Supply fan, adjustable 118W 8 Extract fan, adjustable 118W...
- Page 3 TALTERI DIVK-C91 INSTALLATION The air exchange unit is meant fo r warm inner facilities. Suitable installation spots are, among others, office, dressing or household facilities and technical or warm storages. In case the temperature of the installation location is lower than ro om temperature, the factory settings of the appliance must be changed to obtain faultless functioning.
- Page 4 DIVK-C 91 INSTALLATION TO A SUSPENDED CEILING The ceiling-mounting plate is attached to the roof with M8, thread bars (not included in the LEAVE A 40-50MM GAP delivery). M8 THREADED BAR BETWEEN THE CEILING AND THE FRONT EDGE OF THE BACKUP NUT MOUNTING PLATE 40-50...
-
Page 5: Electrical Connections
ELECTRICAL CONNECTIONS Electrical connections must be done following the installation manual The following can be connected as accessories: and wiring diagram. ELECTRICAL CONNECTIONS CAN BE DONE ONLY BY - Carbon dioxide transmitter; AN ENTREPRENEUR WITH RESPECTIVE INSTALLATION RIGHTS. - Humidity transmitter; - Separate Overpressure or Extended The external connections of the machine are connected to the time switch (pulse switch);... - Page 6 C91 CD Input 230V, 50 Hz 10 A ( IU ) -power cord (plug) EXTRACT SUPPLY TRIAC PREH. TRIAC POSTH. Blue A/D+ Pink B/D- O O O ON OFF BIAS B O O O ON OFF Term O O O ON OFF BIAS A Wh-ye Ye-br...
-
Page 7: Service Menu
INTRODUCTION OF THE AIR EXCHANGE SYSTEM BEFORE OPERATING YOUR AIR EXCHANGE SYSTEM, USAGE AND CORRECT LEVEL OF AIR EXCHANGE MAKE SURE THAT: The air exchange level is regulated by changing the - There are no loose objects within the unit or the air impeller; working speed of the air impeller from the operating panel. - Page 8 INTRODUCTION OF THE AHU CONTROL PANEL SPEED CONTROL WITH A COOKER HOOD (0-10V) 0-10V external control (0-10V hood,remote monitoring) select the deployment SENSOR 1 "EXT" or SENSOR 2 "EXT" External control controls the basic speed , replaces the fan speed set in the menu. Out-of-home, overpressure and boost are in use normally.
- Page 9 THRESHOLDS FOR FREEZING PROTECTION The preheater and freezing protection are enabled, changes are only if needed. Factory setting IN USE Temperature measurements of the preheater and WASTE AIR COLD are measured from the waste air temperature The preheater is switched onfrom the service menu. Factory setting The limit value of the preheater can be changed from the service menu if necessary.
-
Page 10: Removing The Fan
INTEGRATED HUMIDY TRANSMITTER (optional) If the unit is eqipped with a factory-fitted extract air humidity trasmitter. The fan speed is automatically enchanced when the humidity exceeds the limit value. The humidity transmitter is active when SENSOR 2 RH is selected in the service menu The limit value, the adjustment interval and ON/OFF can be selected in the SETTINGS menu under CO2 and %RH The humidity transmitter also has an on / off switch... - Page 11 The channels must be checked if the impeller works but the air exchange is inadequate or the temperature changes in the channels between the interior and the machine. Temperature changes and humidity concentration in channels must be prevented by improving the isolation. DEEKAX Air Oy Patruunapolku 4 Puh. 0207 912550 79100 LEPPÄVIRTA...
