olympia electronics DLD-28/CBS/w Quick Start Manual

CBS EDGE ILLUMINATION SIGNS WITH WHITE LEDs
TECHNICAL CHARACTERISTICS
Mains voltage
Maximum power consumption
Light source intensity
Degrees of cover protection
Produced in accordance with
Operation temperature range
Relative humidity
External panel's dimensions
External dimensions
Typical weight
Guarantee
GENERAL
These new illumination signs use a new
technology, friendly to the environment ,
with high illuminated L.E.D.s. L.E.D.
technology has very low power consumption.
The edge illumination sign is used as a
mains lighting with indications symbols for
central battery systems (CBS).
In this type of marking panels, the PVC
overlay is mounted on the marking panel
with 4 plastic screws, and it can be changed
by change the PVC overlay in accordance
with the marking code.
Each model combines modern, aesthetics,
t o g e t h e r w i t h f u n c t i o n a l i t y. T h e e x i t
illumination signs are used in every public
area where clear direction and good
appearance are important. All models must
be permanently connected to the mains
power supply as shown on page 2.
The legend is screened on to a clear acrylic
sheet which has the marking on the marking
panel with the light that comes from the top
of the luminaire and diffracts, giving light to
the marking panel.
The unit must be mounted in a clearly visible
area and can either be hung on a ceiling or
mounted on a wall depending on the
requirements of the installation. The
package includes all the required materials
for mounting on the wall or on the ceiling.
Pages 2, 3 and 4 show
methods.
Page 1 from 5
DLD-28/CBS/w
305x25x155mm
Thank you for your trust in our products.
Olympia Electronics - European manufacturer.
the mounting
(for LED MODULE Specs. see page 5)
DLD-34/CBS/w
40-250V DC-AC/50-60Hz
100lm
EN 60598-1, EN 60598-2-22, ΕΝ 55015, ΕΝ 61547, ΕΝ 61000-3-2, ΕΝ 61000-3-3
280x100mm
365x25x225mm
465gr.
WARNING !!
1 . T h e u n i t m u s t b e c o n n e c t e d t o a
dedicated fused power line, for example 16A
rating.
NOTE: LED= Light Emitting Diode
LABELING EXPLANATION:
Z: Central supply
1: Maintained
G: Internally illuminated
The light source contained in this
luminaire shall only be replaced by the
manufacturer, or his agent, or a similar
qualified person.
NOTE! The light source is non-user
replaceable.
DLD-44/CBS/w
1.5W/4.5VA
125lm
IP42
-30 to 50 ºC
up to 95%
340x170mm 440x220mm
465x25x275mm
795gr.
3 years
922604410_09_029
1270gr.
