- Page 1 Manual PDU SW-1081 PDU SM-1681 © 2013 – Inter-Tech Elektronik Handels GmbH – D-30855 Langenhagen – Germany www.inter-tech.de – vertrieb@inter-tech.de...
-
Page 2: Table Of Contents
Table of Contents 1. Introduction ......................2 2. PDU Package ......................3 3. Function ........................4 4. Installation ....................... 6 5. Web Interface ......................8 User Manual PDU SW-1081/ SM-1688... -
Page 3: Introduction
1. Introduction The PDU is an Internet ready device designed and is equipped with an intelligent current- meter (True RMS) that will indicate the total power consumption of a power strip. The PDU offers an easy set up and user-friendly communication software. This software provides the function that assistant manager to remotely monitor the multiple PDU power consumption to realize the total current power consumption and utilization for the enterprises. -
Page 4: Pdu Package
2. PDU Package The standard PDU package contains a Power Distribution Unit with supporting hardware and software. The components of the package are: Power Distribution Unit. Rack mount Brackets. CD-ROM, it contains: User Manual. PDU Software. MIB: Management Information Base for Network. (PDUMIB.mib) Adobe Acrobat Reader. -
Page 5: Function
3. Function Interface Single current bank Functions Description Ethernet RJ45 port for network communication port. Audible Alarm Warning- 1 beep in 1 second. Overload- 3 beeps in 1 second. Note: The audible alarm will keep beeping until the current gets back to normal and the current is lower than the threshold to 0.5 amps. - Page 6 RJ11 for ENV probe attached. Circuit Breaker Overload power protection. User Manual PDU SW-1081/ SM-1688...
-
Page 7: Installation
4. Installation This section will provide a quick instruction to install the PDU. Rack Mount Instructions A) Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient. - Page 8 Hardware Install mounting brackets. The PDU comes with brackets for mounting in a rack. To mount the PDU into a rack performs the following procedure: Attach the mounting brackets to the unit, using the four retaining screws provided for each of the brackets. Choose a location for the brackets.
-
Page 9: Web Interface
5. Web Interface Login: Input the PDU IP address in web browser. Default ID is snmp. Password is 1234. User Manual PDU SW-1081/ SM-1688... - Page 10 Information: PDU Display total PDU and each outlet power consumption. When plug the option device - ENV probe, it will display temperature and humidity information. User Manual PDU SW-1081/ SM-1688...
- Page 11 Information: System Indicate PDU system information, including: Model No. Firmware Version MAC Address System Name System Contact Location User Manual PDU SW-1081/ SM-1688...
- Page 12 Control: Outlet Indicate PDU outlet on/off status and control outlet. Select the outlet by checking the box and then click ON or OFF button to control output power for PDU Monitored PDU series does not support this function. ON: Press the icon to turn on the assigned outlets. OFF: Press the icon to turn off the assigned outlets.
- Page 13 Configuration: PDU Set the outlet name and delay time. Name: Rename the outlet. ON: Set delay time for power on sequential. OFF: Set delay time for power off sequential. Note: The maximum delay time is 255 seconds. Note： ： ： ： After PDU is plugged into main power, PDU system will start to sequentially turn on the output socket according to the pre-set delay time in PDU web interface.
- Page 14 Configuration: Threshold Set the warning and overload threshold for each circuit. Set lower and upper threshold for temperature and humidity. User Manual PDU SW-1081/ SM-1688...
- Page 15 Configuration: User Change ID and password. Default ID is snmp and password is 1234. User Manual PDU SW-1081/ SM-1688...
- Page 16 Configuration: Network PDU network information Enable DHCP: Change the way to get IP address for PDU. User Manual PDU SW-1081/ SM-1688...
- Page 17 Configuration: Mail When event occurs, PDU can send out email message to pre-defined account. Email Server: The Email Server only support to be input domain name, not IP address. Sender’s Email: Input the sender email address. Email Address: Input the recipient email address. The message in the email: Indicate OutletA~H-XXXXXXXX status in order X=0 : means the power off.
- Page 18 Configuration: SNMP When event occurs, PDU can send out trap message to pre-defined IP address. Trap Notification: Set receiver IP for trap. Community: Set SNMP community. Read Community is public and fixed. Default Write Community is “public” and can be modified by user. User Manual PDU SW-1081/ SM-1688...
- Page 19 Configuration: SSL Enable SSL for web communication. User must input the correct ID and password to enable SSL function. The ID and password must be the same with the setting in “User”. User Manual PDU SW-1081/ SM-1688...
