- Page 1 PDU SD-1021 Per outlet control User Manual © 2013 – Inter-Tech Elektronik Handels GmbH – D-30855 Langenhagen – Germany www.inter-tech.de – vertrieb@inter-tech.de...
-
Page 2: Safety Precau Ons
Safety Precau ons To avoid poten al problems when using PDU: If the building has 3-phase AC power, ensure that the server ● and monitor are on the same phase. For best results, they should be on the same circuit. To avoid poten ally fatal shock hazard and possible damage ●... - Page 3 breakers is disabled. WARNING: The PDU is intended for indoor use only. WARNING: To help protect the PDU from electrical power fluctua ons, use a surge suppressor, line condi oner or uninterrup ble power supply. WARNING: Be sure that nothing rests on the cables of the PDU and that it is not located where it may be stepped on or tripped over.
- Page 4 Reduced Air Flow: Installa on of the equipment in a rack should be such that the amount of air flow required for safe opera on of the equipment is not compromised. Mechanical Loading: Moun ng of the equipment in the rack should be such that a hazardous condi on is not created due to uneven mechanical loading.
-
Page 5: Features And Benefits
Features and Benefits The PDU is an Internet-ready power strip equipped with an intelligent current meter to indicate the total power consump on of the Power Distribu on Unit (PDU). Each PDU includes PDU U lity so ware to monitor and manage mul ple PDUs. FUNCTION POWER OUTLET... -
Page 6: Alarms And Monitoring
Alarms and monitoring The PDU delivers accurate, real- me global current monitoring of all connected devices via the onboard web interface or through the PDU U lity so ware. Users have the ability to set a current alarm threshold that, once exceeded, will cause the PDU to flash a LED or to send a no fica on message, or both. - Page 7 System Alarm No fica on via Email, SNMP, Syslog or LED SSLv3, TLS1.0,TLS1.1,TLS1.2 Support IP Address Filtering Max. of 100000 entries for each Power Consump on Data and Event Log Remote firmware Upgrade Support Alive of Heart Beat Trap Available. Definable Reset Bu on Fahrenheit and Celsius Switchable Export and Import PDU Configura on...
- Page 8 Ge ng Started Before installing your PDU, refer to the following list to ensure you have all items that shipped with the PDU, as well as other items necessary for proper installa on. The standard PDU package includes the following: •...
-
Page 9: Installa On Instruc Ons
Installa on Instruc ons This sec on will provide a quick instruc on to install the PDU. A) Elevated Opera ng Ambient - If installed in a closed or mul -unit rack assembly, the opera ng ambient temperature of the rack environment may be greater than room ambient. Therefore, considera on should be given to installing the equipment in an environment compa ble with the maximum ambient temperature specified by the manufacturer. - Page 10 Hardware Unpack the product and place it to a proper place Put the power cord of the computers into the sockets A and B Connect the KVM to internet using the Ethernet socket Connect the KVM to the power grid...
-
Page 11: Web Interface
Web interface: The default se ng for the way to get IP address is DHCP. If PDU can not get the IP from DHCP server, the IP address will 192.168.0.200 stay at snmp Default ID: 1234 Default Password: A er login to web, user can check all opera on instruc on in web page of “Info.”... - Page 12 Informa on Overview Display current, temperature and humidity informa on, event log and outlet status. Current Monitor ENV Monitor Event List Outlet Status Note:...
-
Page 13: Event Log
Se ng column S: Schedule is set. PDU will execute the pre -set outlet ac on in specified me automa cally. P: Ping func on is ac ve. If the specified device stops ping response, PDU will execute the pre-set outlets ac on E: PDU will execute the pre-set outlets' ac on according to event happen. - Page 14 Management Control 1. Directly control outlet. 2. Set a number of outlets as a group to control them by one func on bu on.
- Page 15 Schedule Pre-set me to turn on or off the specified outlet 1. Outlet A is scheduled to off at 10:00 on 2022/03/29. 2. Outlet B executes off/on at 12:00 every Sunday. 3. Outlet C executes on at 14:00 every day.
- Page 16 Event Ac on Pre-set outlet ac on once the current, temperature or humidity over threshold 1. Receive Trap message 1.3.6.1.4.1.17420.1.6, IP is 192.168.0.1; a er 10 seconds, Outlet C will OFF/ON. 2. When ENV(1) the temperature exceeds the upper limit, a er 5 seconds, Outlet A will “OFF”...
- Page 17 Ping Ac on Ping-No-Answer power ac on 1. Ping 192.168.0.1, if there is no response within 5 minutes, Outlet A will OFF/ON 2. Ping 192.168.0.100, if there is no response within 15 minutes, Outlet D will OFF. Automa cally reboot the locked device by ping its IP 17 1...
- Page 18 Receive Trap OID equal to: User can input the private OID to trigger the specified outlet ac on. Device Outlets and circuits name, sequence on/off and outlet owner configura on The max. length of outlet name is 36 characters The max. me for delay on/off is 9999 seconds A er Restart: Define the outlet ac on a er power restart Last Status: A er power restart, outlets remain the same power...
- Page 19 OFF: Turn off outlets a er power restart. Note: A er PDU is plugged into main power, PDU system will start to sequen ally turn on the output socket according to the pre-set delay me in PDU web interface. The factory default se ng for delay me is one second for each outlet;...
- Page 20 Threshold Set threshold of current, temperature and humidity. Set total current and voltage threshold Set outlets threshold Set temperature and humidity threshold...
- Page 21 Configura on Network IP address related configura on The default se ng for the way to get IP address is DHCP. If PDU can not get the IP from DHCP server, the IP address will stay at 192.168.0.200 The max. length of host name is 36 characters Security Access setup for web, SSL, SSH and Telnet Default login ID is snmp and password is 1234 for SSH and Telnet.
- Page 22 SNMP Set the SNMP parameter Support SNMPv1,v2 and v3 Time Time by NTP or manually for schedule and log record Time must be set properly; otherwise the schedule se ng will not be performed correctly. Radius Advanced authen ca on System supports the Remote Authen ca on Dial-in User Service protocol.
- Page 23 Environment: Display temperature and humidity informa on. ATS: Display ATS informa on. Network: Display network informa on. About PDU: PDU system informa on. User Mul ple users configura on Note: Please set the email address to receive alert events. Users can add up to 8 accounts. Admin: Full authority to monitor, control and configure PDU...
- Page 24 func ons. System Export system configura on. Import system configura on from export file. Firmware Upgrade Update: Keep all configura ons a er complete firmware upgrade. Update and Reset: Reset all configura ons back to default a er complete firmware upgrade.
