R410A All DC Inverter Mini VRF
1. Product Lineup
Outdoor Units
80/105 Model
Model name
MDV-V80W/DN1
MDV-V105W/DN1
MDV-V120W/DN1
MDV-V140W/DN1
MDV-V160W/DN1(B)
2
Dimension body(mm)
Width:1075
Height:966
Depth:336
Width:1075
Height: 966
Depth:336
Width:900
Height:1327
Depth:400
Width:900
Height:1327
Depth:400
Width:900
Height:1327
Depth:400
120~160 Model
Net/Gross weight (kg)
62/67
74/81
95/106
95/106
100/111
MCAC-VTSM-2016-10
Power supply
220~240V-1ph 50Hz
220~240V-1ph 50Hz
220~240V-1ph 50Hz
220~240V-1ph 50Hz
220~240V-1ph 50Hz
General Information
