Midea Mini VRF MDV-V105W/DN1 Technical & Service Manual page 43

R410A All DC Inverter Mini VRF
MDV-V120W/DN1
Cooling
Combination
Outdoor
DB:20.8,WB:14
(%)
temperature
(Capacity
(° C DB)
index)
-5
-2
0
2
4
6
8
10
12
14
16
18
50% 20
21
23
25
27
29
31
33
35
37
39
41
43
Note:
1． is tested under our standard condition.
2．Avoid running the outdoor unit when outdoor air temperature is above 43 degrees in cooling mode.
3．The above table shows the average value of conditions may operate.
4．It is recommended to connect less than 130%.
40
DB:23.3,WB:16
TC PI TC PI
kW kW kW kW
4.15 0.53 4.96 0.61
4.15 0.53 4.96 0.62
4.15 0.54 4.96 0.63
4.15 0.55 4.96 0.64
4.15 0.55 4.96 0.65
4.15 0.56 4.96 0.66
4.15 0.58 4.96 0.67
4.15 0.59 4.96 0.68
4.15 0.59 4.96 0.69
4.15 0.6 4.96 0.7
4.15 0.61 4.96 0.71
4.15 0.62 4.96 0.72
4.15 0.63 4.96 0.73
4.15 0.63 4.96 0.74
4.15 0.64 4.96 0.74
4.15 0.65 4.96 0.76
4.15 0.66 4.96 0.79
4.15 0.7 4.96 0.83
4.15 0.74 4.96 0.88
4.15 0.78 4.96 0.93
4.15 0.82 4.96 0.99
4.15 0.87 4.96 1.04
4.15 0.92 4.96 1.1
4.15 0.95 4.96 1.15
4.15 1.02 4.96 1.23
Indoor temperature(°C DB/WB)
DB:25.8,WB:18 DB:27,WB:19
TC PI TC PI
kW kW kW kW
5.75 0.7 6.15 0.73
5.75 0.71 6.15 0.74
5.75 0.72 6.15 0.75
5.75 0.73 6.15 0.76
5.75 0.74 6.15 0.77
5.75 0.75 6.15 0.79
5.75 0.76 6.15 0.81
5.75 0.78 6.15 0.82
5.75 0.79 6.15 0.84
5.75 0.8 6.15 0.85
5.75 0.81 6.15 0.87
5.75 0.82 6.15 0.88
5.75 0.84 6.15 0.89
5.75 0.85 6.15 0.9
5.75 0.86 6.15 0.92
5.75 0.88 6.15 0.94
5.75 0.92 6.15 1
5.75 0.98 6.15 1.06
5.75 1.04 6.15 1.13
5.75 1.1 6.15 1.19
5.75 1.16 6.15 1.26
5.75 1.24 6.15 1.34
5.75 1.31 6.15 1.41
5.75 1.35 6.15 1.48
5.75 1.4 6.15 1.55
MCAC-VTSM-2016-10
DB:28.2,WB:20 DB:30.7,WB:22
TC PI TC PI
kW kW kW kW
6.55 0.77 7.34 0.88
6.55 0.79 7.34 0.89
6.55 0.79 7.34 0.9
6.55 0.81 7.34 0.91
6.55 0.82 7.34 0.93
6.55 0.84 7.34 0.95
6.55 0.85 7.34 0.96
6.55 0.88 7.34 0.99
6.55 0.89 7.34 1
6.55 0.91 7.34 1.02
6.55 0.92 7.34 1.04
6.55 0.94 7.34 1.06
6.55 0.95 7.34 1.07
6.55 0.96 7.34 1.09
6.55 0.98 7.34 1.1
6.55 1.01 7.34 1.16
6.55 1.07 7.34 1.24
6.55 1.14 7.34 1.31
6.55 1.21 7.34 1.4
6.55 1.29 7.34 1.48
6.55 1.36 7.34 1.58
6.55 1.45 7.34 1.67
6.55 1.53 7.34 1.77
6.55 1.6 7.34 1.87
6.55 1.64 7.34 1.96
Specifications & Performance
DB:32,WB:24
TC PI
kW kW
8.17 0.95
8.17 0.96
8.17 0.98
8.17 0.99
8.17 1.02
8.17 1.05
8.17 1.08
8.17 1.1
8.17 1.12
8.17 1.14
8.17 1.16
8.17 1.18
8.17 1.2
8.17 1.21
8.17 1.24
8.17 1.32
8.17 1.41
8.17 1.5
8.17 1.6
8.17 1.7
8.17 1.8
8.17 1.92
8.17 2.04
8.17 2.13
8.17 2.23
