- Page 1 INSTRUCTIONS FOR USE ROLLS-ROYCE CONNECTED WALLBOX...
-
Page 2: Table Of Contents
Contents Information Overview Requirements Installation DIP switch se ings Connect Terminal Commissioning Operation LED information Troubleshooting Technical data Disposal... -
Page 3: Information
INFORMATION SYMBOLS USED Denotes instructions or warnings that you must observe. Denotes instructions that draw your a ention to special features. Denotes the end of the instruction. SAFETY INFORMATION Read the safety information carefully and familiarise yourself with the device before you a empt to install, operate or service it. - Page 4 Do not make any unauthorised changes or modi cations to the Rolls-Royce Connected Wallbox. Repair work to the Rolls-Royce Connected Wallbox is not permi ed and may only be completed by the manufacturer or a trained expert (Rolls-Royce Connected Wallbox replacement).
- Page 5 If any sealing is broken the security and safety can no longer be ensured and Rolls-Royce Motor Cars and its a liates are not liable for damages and/ or losses related to such disturbances, security breaches, unauthorised access, interface, intrusion, leakage and/or the of data or information.
- Page 6 Do not connect any other devices such as electric tools. The Rolls-Royce Connected Wallbox is designed for installation on a wall or a column. Comply with the relevant national regulations for installing and connecting the Rolls-Royce Connected Wallbox.
- Page 7 PACKAGE Mounting template Mounting bracket Cable holder Cosmetic cover No.8 wood screws (4x) F Torx T30 mounting bolts (4x) 1/4‘ expansion bolts (3x) Torx T20 anti-the screw Safety Guide...
- Page 8 Defects or damage caused by installation work which was not carried out as speci ed in the Rolls-Royce Connected Wallbox installation instructions. Defects or damage caused by the product not being used as speci ed in the Rolls-Royce Connected Wallbox operating manual.
-
Page 9: Overview
OVERVIEW DISPLAY AND CONTROLS 61 90 5A7A891 61 90 5A7A892 61 90 5A7A893 61 90 5A7A894 61 90 5A7A895 61 90 5A7A896 Cosmetic cover 2. Vehicle connector inlet 3. Vehicle connector (L) / Socket with shu er (R) 4. LED indicator 5. -
Page 10: Requirements
- At which the Rolls-Royce Connected Wallbox is exposed to ammonia or ammonia gases. - At which the Rolls-Royce Connected Wallbox may be damaged by falling objects. - At which the Rolls-Royce Connected Wallbox is on a direct personnel route and people could stumble over the connected vehicle connector. - Page 11 When selecting the supply cable, take into account the possible reduction factors and the increased ambient temperatures in the internal connection area of the Rolls-Royce Connected Wallbox , see the temperature rating of the supply terminals. In certain circumstances, this may require an increase...
- Page 12 Mains isolation device The Rolls-Royce Connected Wallbox does not have its own mains switch. The residual-current- operated circuit breaker and/or the circuit breaker in the supply cable are used as a mains isolation device.
-
Page 13: Installation
Ideally, the Rolls-Royce Connected Wallbox should be stored for a few hours in advance at the installation site. If this is not possible, the Rolls-Royce Connected Wallbox should not be stored in low temperatures (< 5 °C) overnight outdoors or in a vehicle. - Page 14 RECOMMENDED INSTALLATION POSITIONS When selecting the installation position, taken note of the position of the charge connector on your vehicle and the direction in which you normally park it. REQUIRED DISTANCE Follow applicable accessibility requirements for the mounting position. The unit must be mounted at a su cient height from ground such that the storage height is located between 1,000 mm (39 inch) and 1.2 m (4 ).
- Page 15 MOUNTING THE ROLLS-ROYCE CONNECTED WALLBOX 1. The product is a stationary equipment mounted on the wall. It includes a mounting template to mark the screw locations for the mounting bracket and cable holder (optional). 2. Secure the mounting bracket to the wall. The cable holder is optional and depicted in the gure for demonstration purposes.
- Page 16 REMOVING THE COVERS 5. Remove the cosmetic cover. 6. Use a T20 screw driver to remove the screws securing the middle cover. Torque: 1.4 Nm (12 lb·in) 7. Remove the middle cover. SECURE THE ANTI-THEFT SCREW 8. Secure the anti-the screw.
-
Page 17: Dip Switch Se Ings
DIP SWITCH SETTINGS GROUNDING SYSTEM SETTING TN system se ing (Default) IT/TT system se ing... - Page 18 CURRENT SETTING The factory current se ing for the Rolls-Royce Connected Wallbox is 6 A. To achieve top charging capacity, it is recommended to set the DIP switch se ing to 32 A. This se ing must only be made if the installation is safely designed and approved for this capacity.
- Page 19 AUTHORISATION SETTING The Rolls-Royce Connected Wallbox is set to start charging sessions with app authorisation. To “unlock” the Rolls-Royce Connected Wallbox and o er free access to users, con gure the switch to OFF. For the following model, the authorization se ing is by DIP Switch:...
-
Page 20: Connect Terminal
Connect the RS485 interface with the shielded and twisted connection cables ( > 0.5 mm², max. 30 m) 61 90 5A7A891 / 61 90 5A7A892 / 61 90 5A7A893 / 61 90 5A7A894 / 61 90 5A7A895 / 61 90 5A7A896... -
Page 21: Commissioning
COMMISSIONING Install the middle cover. Torque: 1.0 Nm (8.7 lb·in) Install and lock the cosmetic plate. An audible click sounds denotes a closed faceplate. -
Page 22: Operation
OPERATION The Rolls-Royce Connected Wallbox is supplied as standard with its access control by app enabled. Please adjust the DIP switch accordingly if you do not want to use access control via app. Please refer to section 5.3. START CHARGING WITH ENABLED ACCESS CONTROL 1. - Page 23 1. Stop charging cycle at the vehicle, via the app or charging card. 2. Disconnect the vehicle connection plug from the vehicle charging socket. 3. Place the vehicle connection plug back into the cable holder on the Rolls-Royce Connected Wallbox.
- Page 24 STARTING THE CHARGING CYCLE WITH ACCESS CONTROL DISABLED 1. Connect the vehicle connection plug to the vehicle charging socket. 2. The vehicle will start the charging cycle automatically.
- Page 25 1. Stop the charging cycle on the vehicle. 2. Disconnect the vehicle connection plug from the vehicle charging socket. 3. Place the vehicle connection plug back into the cable holder on the Rolls-Royce Connected Wallbox. Note: Further information about ending the charging cycle is available in your vehicle owner’s...
- Page 26 WALLBOX INSTALLER APP The installer or Rolls-Royce Motor Cars service partner may use the service and installation app in order to con gure the device, download charging history and diagnostics, update the rmware and trouble shoot for further operating instructions, please refer to operation manual. In order to use the Wallbox Installer App, the DIP switch must be set correctly (refer to section 5.4).
-
Page 27: Led Information
LED INFORMATION Check colours Status No display Rolls-Royce Connected Wallbox does not have power supply. Blue, ashing from le to Rolls-Royce Connected Wallbox initialization in progress. right Rolls-Royce Connected Wallbox is suspended temporarily. Blue Vehicle is not connected, standby. Blue, breathing Vehicle is charging. -
Page 28: Troubleshooting
1. No supply voltage – check the residual current breaker and power powered. circuit breaker and switch on if necessary. 2. Error on the Rolls-Royce Connected Wallbox – contact your local dealership. Charging session is not 1. The Vehicle connector has not been inserted correctly – remove started. -
Page 29: Technical Data
TECHNICAL DATA Electrical data Part number 61 90 5 A7A 891 / 61 90 5 A7A 892 / 61 90 5 A7A 893 / 61 90 5 A7A 894 / 61 90 5 A7A 895 / 61 90 5 A7A 896 Vehicle connector GB/T plug Input/output rating... - Page 30 Interfaces Charging connector GB/T AC Plug Indicator LED bar indicator (Blue, Yellow, Green, Red) Communication Bluetooth Ambient conditions Operating temperature -40 °C ~+50 °C Temperature properties This is not a safety device, it is just an operating function. The speci ed operating temperature range must not be exceeded. The device supplies the charging current continuously at the speci ed operating temperature ranges.
-
Page 31: Disposal
DISPOSAL A er correctly decommissioning the device, please have it disposed of by the service department in compliance with current waste disposal regulations. The electrical and electronic devices including accessories must be disposed of separately from general household waste. There are instructions on the product, in the instructions for use or on the packaging. - Page 32 01 29 5 B41 273 09/2023 sdfs...
