ROLLS-ROYCE WALLBOX
INSTRUCTIONS FOR USE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 61 90 5 A1E 1D1 and is the answer not in the manual?

Questions and answers

Related Manuals for Rolls-Royce 61 90 5 A1E 1D1

Summary of Contents for Rolls-Royce 61 90 5 A1E 1D1

  • Page 1 ROLLS-ROYCE WALLBOX INSTRUCTIONS FOR USE...

  • Page 2: Table Of Contents

    Contents Information Overview Requirements Installation Connecting the terminals DIP switch se ings Local load management Commissioning Operation LED display Troubleshooting Technical data Disposal...

  • Page 3: Information

    This device must not be used if the vehicle plug is broken or exhibits cracks or other damage. Danger from electricity. The Rolls-Royce Motor Cars Wallbox must be installed, commissioned and serviced by appropriately trained, quali ed and authorised electricians , who bear full responsibility for complying with the current standards and installation regulations.
  • Page 4 Do not make any unauthorised changes or modi cations to the Rolls-Royce Motor Cars Wallbox. You must not carry out any repair work on the Rolls-Royce Motor Cars Wallbox. This work may only be carried out by the manufacturer or a trained expert (for example replacing the Rolls-Royce Motor Cars Wallbox).
  • Page 5 DECLARATION OF CONFORMITY FOR ELECTROMAGNETIC COMPATIBILITY: FEDERAL COMMUNICATIONS COMMISSION PART 15 The Rolls-Royce Motor Cars Wallbox complies with all the speci cations from Part 15 of the Federal Communications Commission. Operating the Rolls-Royce Motor Cars Wallbox is subject to the following conditions: (1) This device must not cause any harmful interference, and (2) This device must accept all received interference, including interference which may cause it to malfunction.
  • Page 6 CORRECT USE - The Rolls-Royce Motor Cars Wallbox is a charging station for indoor and outdoor use for charging electric or plug-in hybrid vehicles. Do not connect any other devices to it, for example electric tools. - The Rolls-Royce Motor Cars Wallbox is designed for installation on a wall or column. You must comply with the relevant national regulations for installing and connecting the Rolls-Royce Motor Cars Wallbox.
  • Page 7 ABOUT THIS MANUAL This manual and the functions described in it are valid for devices of the following type: Rolls-Royce Motor Cars Wallbox: 61 90 5 A1E 1D1 61 90 5 A1E 1D2 61 90 5 A1E 1D3 61 90 5 A1E 1D4 61 90 5 A1E 1D5 The illustrations and explanations contained in this manual refer to a typical version of the device.
  • Page 8 PACKAGE Mounting template Mounting bracket Cable holder Housing cover Wood screws No. 8 (4 x) Torx T30 fastening screws (4 x) Stud bolts 1/4‘ (3 x) Torx T20 security screw Safety guide...
  • Page 9 Defects or damage caused by using the product for purposes other than those described in this document. Costs and damage caused by repair work not carried out by an authorised electrician, Rolls-Royce Motor Cars sales outlet or authorised service workshop.

  • Page 10: Overview

    OVERVIEW DISPLAYS AND CONTROLS 61 90 5 A1E 1D1 61 90 5 A1E 1D4 61 90 5 A1E 1D2 61 90 5 A1E 1D3 61 90 5 A1E 1D5 Housing cover Vehicle plug connector holder Vehicle plug connector (L)/Charging socket with shu er (R)

  • Page 11: Requirements

    - At which the Rolls-Royce Motor Cars Wallbox is exposed to ammonia or ammonia gases, - At which the Rolls-Royce Motor Cars Wallbox may be damaged by falling objects, - At which the Rolls-Royce Motor Cars Wallbox is on a footpath used by people who may trip over the connected vehicle connector plug,...
  • Page 12 61 90 5 A1E 1D1 61 90 5 A1E 1D4 Every Rolls-Royce Motor Cars Wallbox must be connected using its own residual-current- operated circuit breaker (RCCB). No other circuits may be connected to this RCCB. RCCB at least type A (30 mA trip current).
  • Page 13 MAINS ISOLATOR The Rolls-Royce Motor Cars Wallbox does not have its own mains switch. The RCCB and/or circuit breaker on the building installation are used as the mains isolator.
  • Page 14 The following installation requirements are applicable for Singapore only:...

  • Page 15: Installation

    Ideally, the Rolls-Royce Motor Cars Wallbox should be stored for several hours at the installation site before installation. If this is not possible, the Rolls-Royce Motor Cars Wallbox should not be stored in low temperatures (< 5 °C) overnight outdoors or in a vehicle.
  • Page 16 REQUIRED SPACING Refer to the illustration below for choosing the installation site.
  • Page 17 INSTALLATION OF ROLLS-ROYCE MOTOR CARS WALLBOX 1. The product is a stationary, wall-mounted device. It contains a mounting template to mark the screw positions for the mounting bracket and the optional cable holder. 2. Secure the mounting bracket to the wall.
  • Page 18 REMOVING THE COVERS 5. Remove the housing cover. 6. Use a T20 screwdriver to remove the screws which secure the terminal block cover. Tightening torque: 1.4 Nm (12 lb in) 7. Remove the terminal block cover. SECURING THE ANTI-THEFT SCREW 8.

  • Page 19: Connecting The Terminals

    CONNECTING THE TERMINALS Use a suitable cable with wire-end ferrules. 61 90 5 A1E 1D1 61 90 5 A1E 1D3 61 90 5 A1E 1D2 61 90 5 A1E 1D5 61 90 5 A1E 1D4 Connect each terminal to the correct connection on the input terminal strip.
  • Page 20 Connect the cable to connection X1. The enabling input is designed for use with a oating contact. The enabling input allows the Rolls-Royce Motor Cars Wallbox to be controlled by external components. Note: The safe isolation of dangerous voltages must be guaranteed.

  • Page 21: Dip Switch Se Ings

    DIP SWITCH SETTINGS SETTING THE EARTH SYSTEM TN system se ing (default) TT/IT system se ing POWER SETTINGS When it is delivered, the Rolls-Royce Motor Cars Wallbox is set to a maximum charging current of 6 A.
  • Page 22 To achieve top charging capacity, it is recommended to set the DIP switch se ing to 32 A. This se ing must only be made if the installation is safely designed and approved for this capacity. 61 90 5 A1E 1D1 61 90 5 A1E 1D2...
  • Page 23 The following se ings apply to these versions: 61 90 5 A1E 1D3 61 90 5 A1E 1D5 Con guration Max. rated current Con guration Max. rated current 20 A 24 A 12 A 32 A 16 A 40 A...
  • Page 24 AUTHORISATION SETTINGS The Rolls-Royce Motor Cars Wallbox is set at the factory to allow free access to the Rolls-Royce Motor Cars Wallbox at all times. If you wish to change this so that all charging cycles must be authorised using an app, the DIP switch must be set to “ON” (see gure on the le ).

  • Page 25: Local Load Management

    LOCAL LOAD MANAGEMENT CONNECTION OF EXTERNAL ENERGY METERS Connect the external energy meter to enable you to monitor your home connection. Connect the shielded, twisted connection cable (> 0.5 mm², max. 30 m) to the RS485 interface. Pin de nition: A (Rx/ Tx+): Pin 4 B (Rx/ Tx-): Pin 5 The following energy meters are compatible with the Wallbox:...
  • Page 26 61 90 5 A1E 1D1 61 90 5 A1E 1D3 61 90 5 A1E 1D2 61 90 5 A1E 1D5 61 90 5 A1E 1D4 Connect the meter to the power supply. Refer to the speci c instructions supplied in the meter’s operating...
  • Page 27 PHASE ASSIGNMENT The phase assignment between the Rolls-Royce Motor Cars Wallbox and household connection can be set using DIP switches. The phase assignment between the Rolls-Royce Motor Cars Wallbox and household connection/ meter can be set using DIP switches 2 and 3.
  • Page 28 FUNCTION TO MONITOR ASYMMETRIC LOADS The maximum current value for an asymmetric load can be de ned using DIP switches 4 and 5. DIP switch se ing Maximum current DIP switch se ing Maximum current Function to monitor 16 A asymmetric loads disabled (factory se ing)
  • Page 29 HOUSEHOLD CONNECTION MONITOR The limit value for the size of the household connection can be de ned using DIP switches 6 to 9. DIP switch se ing Maximum current DIP switch se ing Maximum current 0000 Local load 0110 80 A management disabled (factory se ing)

  • Page 30: Commissioning

    COMMISSIONING Install the terminal block cover. Tightening torque: 1.0 Nm (8.7 lb in) Install and lock the housing cover.

  • Page 31: Operation

    OPERATION The Rolls-Royce Motor Cars Wallbox is supplied as standard with its access control by app enabled. Please change the DIP switch se ing if you do not wish to use access control by app. For further information, see section 6.3 "Authorisation se...
  • Page 32 1. Stop the charging cycle on the vehicle or using the app. 2. Disconnect the vehicle connection plug from the vehicle charging socket. 3. Place the vehicle connection plug back into the cable holder on the Rolls-Royce Motor Cars Wallbox.
  • Page 33 1. Stop the charging cycle on the vehicle. 2. Disconnect the vehicle connection plug from the vehicle charging socket. 3. Place the vehicle connection plug back into the cable holder on the Rolls-Royce Motor Cars Wallbox. Note: Further information about ending the charging cycle is available in your vehicle owner’s...
  • Page 34 WALLBOX SERVICE APP Your installer or Rolls-Royce Motor Cars partner can use the service and installation app to con gure the device, download the charging history and diagnostic data, update the rmware and rectify errors. To use Wallbox service app, the DIP switch must be set correctly (see section 6 "DIP switch...

  • Page 35: Led Display

    LED DISPLAY LED display Status No display The Rolls-Royce Motor Cars Wallbox is not being powered with electricity. White, from le to right continuously Initialisation of Rolls-Royce Motor Cars Wallbox in process. White, steady Vehicle is not connected. Wallbox is ready to charge.

  • Page 36: Troubleshooting

    1. No supply voltage – check the RCCB and circuit breaker and supply. switch them on if necessary. 2. Error on the Rolls-Royce Motor Cars Wallbox – contact your local dealer. The charging cycle is not 1. The vehicle connection plug has not been inserted correctly –...

  • Page 37: Technical Data

    TECHNICAL DATA Part number 61 90 5 A1E 61 90 5 A1E 61 90 5 A1E 61 90 5 A1E 61 90 5 A1E Vehicle Type 2 plug GB/T plug SAE J1772 Type 2 SAE J1772 connection plug plug shu er plug Input/Output 220-240 V/...
  • Page 38 Part number 61 90 5 A1E 61 90 5 A1E 61 90 5 A1E 61 90 5 A1E 61 90 5 A1E Internal fault Alternating Alternating Alternating Alternating Alternating current detection current: current: current: current: current: 15~30 mA 15~30 mA 20 mA 15~30 mA 20 mA...
  • Page 39 Interfaces Display Communication Bluetooth Ambient conditions Operating temperature -40°C ~ +50°C Temperature properties This is not a safety device; it is only a function. The speci ed operating temperature range must not be exceeded. The device supplies the charging current continuously within the speci ed operating temperature ranges.

  • Page 40: Disposal

    DISPOSAL A er it has been decommissioned correctly, have the device disposed of by the Service Department in compliance with current waste disposal regulations. Electrical and electronic devices and the accessories must be disposed of separately from general household waste. Information about this is provided on the product, in the instructions for use or on the packaging.
  • Page 41 01 29 5 A8D 9D4 04/2023...
